Side 1/132

HDMI over Cat6 Extender Kits

and Repeater, 4K/60 Hz

Extender Kit Models: B127A-1A1-BHBH,

B127A-1A1-BHPH, B127A-111-BHTH, B127A-110-BH

Repeater Model: B127A-010-H

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Owner's Manual

WARRANTY REGISTRATION

win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 27 • Français 53 • Русский 79 • Deutsch 105

20-10-008-933D27-Book.indb 120-10-008-933D27-Book.indb 1 4/21/2021 4:00:29 PM4/21/2021 4:00:29 PM

B127A-1A1-BHBH

B127A-1A1-BHPH

B127A-111-BHTH

B127A-110-BH

B127A-010-H

Local and Remote Units (LR),

Remote Unit (R), Repeater Unit (RT)

LR LR LR R RT

External Power Supplies (0 or 1) 1 1 1 1 0

Mounting Hardware Y Y Y Y N

Package Contents

Product Features

All

• Support video resolutions up to 4K x 2K (3840 x 2160) @

60 Hz, as speciﬁed in HDMI 2.0, with 4:4:4 Chroma

Subsampling

• Support up to 7.1-channel surround sound audio

• HDCP 2.2- and HDR-compatible

• USB 1.1 standard

• Plug and play—no software or drivers required

Note: USB 1.1 standard and bi-directional IR applies only to the extender

kits, not the repeater.

20-10-008-933D27-Book.indb 220-10-008-933D27-Book.indb 2 4/21/2021 4:00:29 PM4/21/2021 4:00:29 PM

Product Features

B127A-1A1-BHBH

• HDMI over Cat6 Power over Cable (PoC) Extender Kit

• Extends a 4K x 2K (3840 x 2160) @ 60 Hz signal, as speciﬁed

in HDMI 2.0, up to 230 ft. (70 m) from the source

• Built-in local HDMI port supports 4K @ 60 Hz signal

• Remote receiver unit features built-in equalization (EQ) control

and auto EDID image adjustment

• Supports up to 7.1-channel surround sound audio

• Receiver features built-in Toslink port for audio extraction

function

• HDCP 2.2-compatible

• Plug and play—no software or drivers required

• Support bi-directional IR and USB 1.1 function by dip switch

selection

• Includes mounting hardware that enables both the local

transmitter and remote receiver units to be wall-mounted,

rack-mounted or pole-mounted

• Power over Cable (PoC) function allows external power supply

to be plugged in at either transmitter or receiver side and

provide power to both units

20-10-008-933D27-Book.indb 320-10-008-933D27-Book.indb 3 4/21/2021 4:00:29 PM4/21/2021 4:00:29 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Mottaker
Modell:	B127A-1A1-BHPH
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	660 g
Maksimal oppdateringshastighet:	60 Hz
3D:	Ja
Materiale:	Metal, Plastic
Fargedybde:	36 bit
Utgangsstrøm:	1 A
HDMI inn:	1
Antall HDMI-utganger:	2
Driftsspenning:	24 V
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50-60 Hz
Produktfarge:	Sort
Pakkedybde:	164.1 mm
Pakkehøyde:	55.1 mm
Monteringssett:	Ja
Pakkebredde:	260.1 mm
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	CE, REACH, RoHS
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	1
DC-inngangskontakt:	Ja
Kan monteres på vegg:	Ja
Lydsystem:	Flerkanal
Inkluderte kraftpluggtyper:	AU, EU, NA, UK
Relativ luftfuktighet under drift (H-H):	0 - 85
Rack-montering:	Ja
Lyd-utgang kanaler:	7.1 kanaler
Fjern (IR)-utgang:	1
AC-adapter bunt:	Ja
Bærekraftsamsvar:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332258639
Masterkassens (ytterkassens) bruttovekt:	6900 g
Masterkassens (ytterkassens) lengde:	273 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	573 mm
Masterkassens (ytterkassens) høyde:	175 mm
Innput-strøm:	0.6 A
Fjerninngang (IR):	1
Maksimal overføring avstand:	70.1 m
Kabeltyper som støttes:	Cat5, Cat5e, Cat6, HDMI
Trådløs mottaker (B x D x H):	47 x 75 x 18.6 mm
Senderdimensjoner (BxDxH):	115 x 62.4 x 27 mm
RJ-45-utgangsporter:	1
Consumer Electronics Control (CEC)-støtte:	Ja
Extended display identification data (EDID):	Ja
