Side 1/44

Owner’s Manual

Purchased product

may differ from image.

Model:

B127E-1A1-HH

4K HDMI Over Cat6

Extender Kit

Español 9

Français 18

Deutsch 27

Italiano 36

Package Contents

• Transmitter and Receiver Units

• External Power Supply Plug Adapters: AS/NZS 3112 Australia;

BS 1363 U.K.; CEE 7/16 Schuko; NEMA 1-15P North America

• IR-Out Cable

• IR-In Cable

• (x2) RS-232 Adapters

• Mounting Hardware

• Owner’s Manual

Optional Accessories:

• N202-Series Cat6 24 AWG Solid-Wire Patch Cables

• P569-XXX-CERT or P568-XXX-2A Series High-Speed HDMI 2.0 Cables

Product Features

• Extends a 4K (3840 x 2160) @ 60 Hz 4:4:4 signal up to 328 ft.

(100 m) from the source

• Power over Cable (PoC) technology provides power to the receiver via

Cat6 cable

• Additional HDMI port on the transmitter unit features multi-resolution

support and allows the connection of a local monitor.

• Remote receiver unit features built-in equalization (EQ) control and

auto EDID image adjustment

•

Includes mounting hardware that allows both the local transmitter and

remote receiver units to be wall-mounted, rack-mounted or pole-

mounted

• Supports up to 7.1-channel surround sound audio

• HDMI 2.0 and HDCP 2.2 compatible

• Plug and play—no software or drivers required

Disclaimer

Before installation, please check the following settings of your source(s)

and TV/monitor(s):

1. Set to display 60 Hz. Double-check factory settings, as default can

be set to a lower frequency (Hz) than advertised.

2. Ensure the input setting of your monitor is set at HDMI 2.0. Some

displays may have default setting at HDMI 1.4.

3. Check if the Ultra HD (UHD) Deep Color setting is enabled on your TV/

monitor. Conrm with your TV/monitor manufacturer which HDMI

ports support UHD Deep Color.

Note: If you wish to connect a local monitor to your installation, depending on your

TV/monitor make/model, the UHD Deep Color setting may need to be disabled on

your local TV/monitor to achieve 4K 60 Hz resolution.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Mottaker
Modell:	B127E-1A1-HH
LED-indikatorer:	Ja
Bruksanvisning:	Ja
USB-kontakttype:	Micro-USB B, USB Type-A
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Opprinnelsesland:	Taiwan
Pakkevekt:	1290 g
Sertifisering:	CE, FCC, REACH
HDCP:	Ja
Maksimal oppdateringshastighet:	60 Hz
Materiale:	Metall
HDMI-versjon:	2.0
Utgangsstrøm:	1 A
HDMI inn:	3
RS-232 inngangsporter:	1
RS-232 utgangsporter:	1
HDCP-versjon:	2.2
Antall HDMI-utganger:	1
Driftsspenning:	24 V
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Sort
Antall USB-porter:	3
Pakkedybde:	149.9 mm
Pakkehøyde:	83.1 mm
Monteringssett:	Ja
Pakkebredde:	343.9 mm
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	0 - 85
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	1
Ekstern strømadapter:	Ja
Lydsystem:	Flerkanal
Inkluderte kraftpluggtyper:	AU, EU, NA, UK
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 85
Rack-montering:	Ja
Lyd-utgang kanaler:	7.1 kanaler
Fjern (IR)-utgang:	2
AC-adapter bunt:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332239133
Masterkassens (ytterkassens) bruttovekt:	13570 g
Masterkassens (ytterkassens) lengde:	363 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	438.9 mm
Masterkassens (ytterkassens) høyde:	324.1 mm
Innput-strøm:	0.6 A
Fjerninngang (IR):	2
Maksimal overføring avstand:	100 m
Kabeltyper som støttes:	Cat5, Cat5e, Cat6, Cat6a, HDMI
RJ-45-utgangsporter:	1
Extended display identification data (EDID):	Ja
