Side 1/20

Owner’s Manual

VGA Over Cat5 Extenders

and Extender/Splitters

Extender Kit Models:

B130-101A-MR and B130-101A-SR

Transmitter Unit Models:

B132-002A-2 and B132-004A-2

Receiver Unit Models:

B132-100A-MR, B132-100A-SR and B132-200A-SR

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

All trademarks are the sole property of their respective owners.

15-04-118-9333BE.indd 1 4/8/2015 10:35:08 AM

Package Contents

B130-101A-MR

B130-101A-SR

B132-002A-2

B132-004A-2

B132-100A-MR

B132-100A-SR

B132-200A-SR

Local Unit (L), Remote Unit (R) or Both (B) B B L L R R R

External Power Supply (P) or Micro USB Cable (U) U U P P U U P

Number of Power Supplies / Micro USB Cables 2 2 1 1 1 1 1

Mounting Hardware Y Y

Screwdriver Y Y Y Y Y

1-ft. VGA + Audio Daisy Chain Cable Y

Table of Contents

Package Contents 2

Product Features 3

All 3

B130-101A-MR 3

B130-101A-SR 3

B132-002A-2 3

B132-004A-2 4

B132-100A-MR 4

B132-100A-SR 5

B132-200A-SR 5

Optional Accessories 5

Mounting Hardware 6

Instructions

Installation 7

EDID Copy 7

Extender Kit Installation 9

Non-Kit Standard Installation 11

Non-Kit Daisy Chain Installation 13

Troubleshooting 16

Warranty and Product 18

Registration

Additional Warnings and 19

Notices

15-04-118-9333BE.indd 2 4/8/2015 10:35:09 AM

Product Features

All

• Transmits both VGA video and mono audio.

• All operating systems supported.

• Plug and play; no software or drivers required.

• HDCP compliant.

B130-101A-MR

• Extends a 1920 x 1080 video signal up to 300 ft. or a 1024 x 768

video signal up to 750 ft.

• Receiver unit features built-in equalization and gain controls to adjust

the video image.

• Power is supplied via the Micro USB ports on the transmitter and

receiver units. No external power supplies required.

• EDID copy feature ensures optimal display compatibility.

B130-101A-SR

• Extends a 1440 x 900 video signal up to 150 ft. or a 1024 x 768 video

signal up to 300 ft.

• Receiver unit features built-in equalization and gain controls to adjust

the video image.

• Power is supplied via the Micro USB ports on the transmitter and

receiver units. No external power supplies required.

• EDID copy feature ensures optimal display compatibility.

B132-002A-2

• Works with the B132-100A-MR, B132-100A-SR and B132-200A-SR

remote units to extend both the VGA video and audio signal.

• Transmits a single VGA video and audio signal to 2 sets of monitors and

speakers.

• Includes mounting hardware that allows unit to be wall-mounted, rack

mounted or pole mounted.

• EDID copy feature ensures optimal display compatibility.

15-04-118-9333BE.indd 3 4/8/2015 10:35:09 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Mottaker
Modell:	B132-100A-SR
Bruksanvisning:	Ja
USB-kontakttype:	Micro-USB B
Maksimal oppløsning:	1440 x 900 piksler
Pakkevekt:	170 g
Sertifisering:	CE, FCC, REACH
Produktfarge:	Black, White
Antall USB-porter:	1
Pakkedybde:	33 mm
Pakkehøyde:	156 mm
Pakkebredde:	121.9 mm
Støttede grafikkoppløsninger:	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1440 x 900 (WXGA+)
Kabler inkludert:	Micro-USB
Støttede videofunksjoner:	480i, 480p, 720p
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-mottaker
RJ-45-inngangsporter:	1
Inngangsporter for VGA (D-Sub):	1
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) bruttovekt:	1910 g
Masterkassens (ytterkassens) lengde:	135.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	163.1 mm
Masterkassens (ytterkassens) høyde:	342.9 mm
Maksimal overføring avstand:	90 m
Kabeltyper som støttes:	Cat5e, Cat6
3,5 mm inn:	Ja
HDCP & EDID bypass:	Ja
