Owner’s Manual

Este manual esta disponible en español en la página de Tripp Lite:

www.tripplite.com

Ce manuel est disponible en français sur le site Web de Tripp Lite :

www.tripplite.com

Русскоязычная версия настоящего руководства представлена на

веб-сайте компании Tripp Lite по адресу: www.tripplite.com

Audio/Video with RS-232

and IR Control over IP Extenders

Extender Kit Models:

B160-101-DPSI, B160-101-HDSI, B160-201-HSI

Transmitter Models:

B160-001-CSI, B160-001-DPSI,

B160-001-HDSI, B160-001-VSI

Receiver Models:

B160-100-CSI, B160-100-DPSI, B160-100-HDSI,

B160-100-VSI, B160-200-HSI

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

All trademarks are the sole property of their respective owners.

17-02-096-93360B-EN.indd 1 2/13/2017 4:55:59 PM

Package Contents

B160-001-CSI

B160-001-DPSI

B160-001-HDSI

B160-001-VSI

B160-100-CSI

B160-100-DPSI

B160-100-HDSI

B160-100-VSI

B160-200-HSI

B160-101-DPSI

B160-101-HDSI

B160-201-HSI

Transmitter (T), Receiver (R), Kit (K) T T T T R R R R R K K K

External Power Supply 1 1 1 1 1 1 1 1 1 2 2 2

IR-In Cable 0 0 0 0 1 1 1 1 1 1 1 1

IR-Out Cable 1 1 1 1 0 0 0 0 0 1 1 1

3.5 mm to DB9 M/F Adapter Cable 1 1 0 1 0 0 0 0 0 1 0 0

3.5 mm to DB9 M/M Adapter Cable 0 0 0 0 1 1 0 1 1 1 0 1

HDMI to DVI Adapter Cable 0 0 1 0 0 0 1 0 0 0 2 0

Mounting Hardware Y Y Y Y Y Y Y Y Y Y Y Y

Owner’s Manual Y Y Y Y Y Y Y Y Y Y Y Y

17-02-096-93360B-EN.indd 2 2/13/2017 4:55:59 PM

Optional Accessories

• A008-006 Component Video Gold Cable – 6 ft.

• N202-Series Cat6, 24 AWG, Solid-Wire Patch Cables

• NSS-G16D2 16-Port Gigabit L2 Managed Switch with 8-Outlet PDU

• NSS-G24D2 24-Port Gigabit L2 Managed Switch with 12-Outlet PDU

• P502-Series VGA Cables with RGB Coax

• P520-006 RS-232 Serial Extension Cable – 6 ft.

• P561-Series DVI-D Single-Link Cables

• P566-Series HDMI to DVI Adapter Cables

• P568-Series High Speed HDMI Cables

• P569-XXX-LOCK* High Speed HDMI Cables with Ethernet and Locking

Connectors

• P580-Series DisplayPort™ Cables

• P583-Series Mini DisplayPort to DisplayPort Cables

*XXX refers to the length, with cables available in 6 ft. (006), 10 ft. (010) and

15 ft. (015) lengths.

Product Features

• Extend and distribute audio/video, serial and IR control signals over

Cat5/Cat6 cabling.

• Models available with Component Video + Stereo Audio, DisplayPort,

HDMI*, and VGA + Stereo Audio.

• Converts source video to an IP-based signal that can be transmitted to

and distributed through a network switch.

• Transmitters can be located up to 328 ft. (100 m) from the switch,

with an additional 328 ft. (100 m) between the switch and the receiver,

for a total distance of 656 ft. (200 m).

*Connect a DVI source and/or monitor using an HDMI to DVI adapter (select models

include an HDMI to DVI adapter). HDMI to DVI adapter cables (Tripp Lite P566-Series)

are available, sold separately.

17-02-096-93360B-EN.indd 3 2/13/2017 4:55:59 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Mottaker
Modell:	B160-101-DPSI
LED-indikatorer:	LAN, Power
Bruksanvisning:	Ja
Maksimal oppløsning:	1920 x 1080 piksler
Videokomprimeringsformater:	H.264
Pakkevekt:	1320 g
Sertifisering:	TAA
HDCP:	Ja
3D:	Ja
Utgangsstrøm:	2 A
Antall HDMI-utganger:	1
Driftsspenning:	5 V
AC-inngangsspenning:	100-240 V
AC-inngangsfrekvens:	50 - 60 Hz
Bærefrekvens:	60 kHz
Produktfarge:	Sort
Pakkedybde:	287 mm
Pakkehøyde:	78.7 mm
Monteringssett:	Ja
Pakkebredde:	147.3 mm
Støttede grafikkoppløsninger:	640 x 480 (VGA),800 x 600 (SVGA),1024 x 768 (XGA),1400 x 900,1600 x 1200 (UXGA),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),1920 x 1440
Kabler inkludert:	Audio (3.5mm), IR
Støttede videofunksjoner:	480i, 480p, 720p, 1080i, 1080p
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	1
Ekstern strømadapter:	Ja
DC-inngangskontakt:	Ja
Kan monteres på vegg:	Ja
Fjern (IR)-utgang:	1
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) bruttovekt:	14240 g
Masterkassens (ytterkassens) lengde:	322.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	439.9 mm
Masterkassens (ytterkassens) høyde:	320 mm
Innput-strøm:	0.5 A
Maksimal overføring avstand:	200 m
Kabeltyper som støttes:	Cat5, Cat6
