Tripp Lite B320-4X1-HH-K2 Bruksanvisning
Tripp Lite
Mottaker
B320-4X1-HH-K2
Les nedenfor 📖 manual på norsk for Tripp Lite B320-4X1-HH-K2 (72 sider) i kategorien Mottaker. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/72
1
4-Port
Presentation Switch
Model: B320-4X1-HH-K1, B320-4X1-HH-K2,
B320-4X1-MH, B320-4X1-MHB-K,
B320-4X1-MHE-K
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
Owner’s Manual
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
Español 19 • Français 37 • Русский 55
20-05-025-933CA4.indb 120-05-025-933CA4.indb 1 10/21/2020 9:26:37 AM10/21/2020 9:26:37 AM
2
• B320-4X1-Series Presentation Switch
• IR Remote Control
• IR Receiver Cable, 5 ft.
• International Power Supply (Input: 100–240V; Output: 24V 1A)
• (x4) International Plug Adapters (North America, U.K., Europe,
Australia)
• Mounting Hardware
• Owner’s Manual
Package Contents
• N202-Series Cat6 24 AWG Solid-Wire Patch Cables
• P569-XXX-CERT Series High-Speed HDMI 2.0 Cables
• P580-Series DisplayPort Cables with Latches
• P502-XXX-SM 15-Pin Low-Profile VGA Coaxial Cables
• U420-Series USB-C 3.1 Gen 1/2 Cables
• P312-Series 3.5 mm Audio Cables
Optional Accessories
20-05-025-933CA4.indb 220-05-025-933CA4.indb 2 10/21/2020 9:26:37 AM10/21/2020 9:26:37 AM
3
B320-4X1-HH-K1
4-Port 4K @ 60 Hz HDMI over Cat6 PoC Presentation Switch/Extender Kit, 50 ft.
• Connects up to 4 HDMI sources to a single HDMI display up to 50 ft.
away via Cat6 cabling.
• Switches between 4 sources using the front-panel pushbuttons, IR
remote control or RS-232 commands.
• Power over Cable (PoC) technology provides power to the receiver via
Cat6 cable.
• Remote receiver unit features built-in equalization (EQ) control and auto
EDID image adjustment.
• Supports true 4K resolutions up to 3840 x 2160 @ 60 Hz with 4:4:4
chroma subsampling.
• HDMI 2.0 and HDCP 2.2 compliant.
• Plug-and-play operation with no software required for easy, immediate
installation.
B320-4X1-HH-K2
4-Port 4K @ 60 Hz HDMI over Cat6 PoC Presentation Switch/Extender Kit, 125 ft.
• Connects up to 4 HDMI sources to a single HDMI display up to 125 ft.
away via Cat6 cabling.
• Switches between 4 sources using the front-panel pushbuttons, IR
remote control or RS-232 commands.
• Power over Cable (PoC) technology provides power to the receiver via
Cat6 cable.
• Remote receiver unit features built-in equalization (EQ) control and auto
EDID image adjustment.
• Supports true 4K resolutions up to 3840 x 2160 @ 60 Hz with 4:4:4
chroma subsampling.
• HDMI 2.0 and HDCP 2.2 compliant.
• Plug-and-play operation with no software required for easy, immediate
installation.
Product Features
20-05-025-933CA4.indb 320-05-025-933CA4.indb 3 10/21/2020 9:26:37 AM10/21/2020 9:26:37 AM
Produkspesifikasjoner
| Merke: | Tripp Lite |
| Kategori: | Mottaker |
| Modell: | B320-4X1-HH-K2 |
| LED-indikatorer: | Ja |
| Bruksanvisning: | Ja |
| Tilkoblingsteknologi: | Koblet med ledninger (ikke trådløs) |
| Maksimal oppløsning: | 3840 x 2160 piksler |
| Opprinnelsesland: | Taiwan |
| Pakkevekt: | 1540 g |
| Sertifisering: | TAA, CE, FCC, REACH |
| HDCP: | Ja |
| Maksimal oppdateringshastighet: | 60 Hz |
| 3D: | Ja |
| Materiale: | Metall |
| HDMI-versjon: | 2.0 |
| HDMI inn: | 4 |
| RS-232 inngangsporter: | 1 |
| HDCP-versjon: | 2.2 |
| Antall HDMI-utganger: | 1 |
| AC-inngangsspenning: | 100 - 240 V |
| AC-inngangsfrekvens: | 50 - 60 Hz |
| Produktfarge: | Sort |
| Pakkedybde: | 105.9 mm |
| Pakkehøyde: | 348 mm |
| Monteringssett: | Ja |
| Pakkebredde: | 160 mm |
| Kabler inkludert: | IR |
| Pakketype: | Boks |
| Driftstemperatur (T-T): | 0 - 40 °C |
| Oppbevaringstemperaturomåde (Celsius): | -15 - 50 °C |
| Bærekraftsertifikater: | RoHS |
| Fjernkontroll medfølger: | Ja |
| Modell/Type: | AV-forsterker |
| RJ-45-inngangsporter: | 1 |
| Ekstern strømadapter: | Ja |
| Inkluderte kraftpluggtyper: | AU, EU, NA, UK |
| Ethernet/bredbåndsforbindelse: | Ja |
| Relativ luftfuktighet under drift (H-H): | 0 - 85 |
| AC-adapter bunt: | Ja |
| Masterkassens (ytterkassens) GTIN (EAN/UPC): | 10037332256291 |
| Masterkassens (ytterkassens) bruttovekt: | 8430 g |
| Masterkassens (ytterkassens) lengde: | 182.9 mm |
| Produkter per masterkasse (ytterkasse): | 5 stykker |
| Masterkassens (ytterkassens) bredde: | 385.1 mm |
| Masterkassens (ytterkassens) høyde: | 588 mm |
| Innput-strøm: | 0.6 A |
| Fjerninngang (IR): | 1 |
| Maksimal overføring avstand: | 38 m |
| Kabeltyper som støttes: | Cat5, Cat5e, Cat6, HDMI |
| RJ-45-utgangsporter: | 1 |
| 3,5 mm inn: | Ja |
