Side 1/16

Owner’s Manual

HDBaseT HDMI Over Cat5/Cat6

Extenders

Extender Kit Models:

BHDBT-K-SI, BHDBT-K-SI-ER, BHDBT-K-SI-LR

Matrix Transmitter Models:

BHDBT-T-SI-4X2, BHDBT-T-SI-4X4

Transceiver Models:

BHDBT-TR-SI, BHDBT-TR-SI-ER, BHDBT-TR-SI-LR

Receiver Models:

BHDBT-R-SI, BHDBT-R-SI-ER, BHDBT-R-SI-LR

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $50 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

All trademarks are the sole property of their respective owners.

15-01-181-933418.indd 1 2/6/2015 3:33:55 PM

Table of Contents

Package Contents

Package Contents 2

Product Features 3

Optional Accessories 5

Mounting Instructions 5

Installation 6

Standard Extender Kit Installation 6

Extender Kit with Transceiver Installation 8

Matrix Transmitter Installation 10

RS-232 Serial Control (Matrix Transmitter Units Only) 13

Troubleshooting 14

Warranty and Product Registration 15

Regulatory Compliance 16

BHDBT-K-SI

BHDBT-K-SI-ER

BHDBT-K-SI-LR

BHDBT-T-SI-4X4

BHDBT-T-SI-4X2

BHDBT-TR-SI

BHDBT-TR-SI-ER

BHDBT-TR-SI-LR

BHDBT-R-SI

BHDBT-R-SI-ER

BHDBT-R-SI-LR

Transmitter (T), Transceiver (TR),

Receiver (R), Kit (K)

K K K T T TR TR TR R R R

External Power Supply (1, 2) 2 2 2 1 1 1 1 1 1 1 1

IR-In Cables (0, 1, 2) 1 1 1 0 0 0 0 0 1 1 1

IR-Out Cables (0, 1, 2) 1 1 1 0 0 0 0 0 1 1 1

Remote Control N N N Y Y N N N N N N

IR Extension Cable 0 0 0 1 1 0 0 0 0 0 0

3.5 mm to DB9 M/F Adapter Cable 1 1 1 1 1 0 0 0 1 1 1

3.5 mm to DB9 M/M Adapter Cable 1 1 1 0 0 0 0 0 1 1 1

Mounting Hardware Y Y Y Y Y Y Y Y Y Y Y

Owner’s Manual Y Y Y Y Y Y Y Y Y Y Y

15-01-181-933418.indd 2 2/6/2015 3:33:56 PM

Product Features

• Extends HDMI audio/video, RS-232 Serial and IR Control Signals over Cat5/6

cabling.

• Supports 7.1-channel surround sound, DTS-HD and Dolby True HD audio.

• Uses a 39 KHz IR frequency.

• Supports RS-232 Serial full-duplex baud rates up to 3 Mbps.

• EDID, HDCP and 3D compatible.

• Includes mounting hardware that allows unit to be wall-mounted, rack mounted or

pole mounted.

• Matrix transmitter units allow multiple HDMI inputs to be connected and distributed

among multiple outputs.

• Transceiver units extend and expand your installation, allowing for multiple monitor

connections at different points in a chain. Up to ﬁve (5) transceivers and one

(1) receiver can be connected in a chain, with each unit being able to extend

its maximum distance from the previous unit (see the table below for details on

maximum distances supported).

• Plug and play; no software or drivers required.

15-01-181-933418.indd 3 2/6/2015 3:33:56 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Mottaker
Modell:	BHDBT-R-SI
Vekt:	249.5 g
Bruksanvisning:	Ja
Maksimal oppløsning:	3840 x 2160 piksler
Sertifisering:	CE, FCC, REACH, TAA
HDCP:	Ja
Fargedybde:	36 bit
Utgangsstrøm:	3 A
HDMI inn:	1
Dimensjoner (B x D x H):	114.3 x 63.5 x 27.94 mm
Driftsspenning:	5 V
AC-inngangsspenning:	100-240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Sort
Monteringssett:	Ja
Støttede grafikkoppløsninger:	640 x 480 (VGA),800 x 600 (SVGA),1440 x 900 (WXGA+),1600 x 1200 (UXGA),1920 x 1200 (WUXGA),1920 x 1440,2048 x 1536 (QXGA),2560 x 1600 (WQXGA),3840 x 2160
Kabler inkludert:	AC, Audio (3.5mm)
Støttede videofunksjoner:	480i, 480p, 720p, 1080i, 1080p
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Bærekraftsertifikater:	RoHS
Modell/Type:	AV-mottaker
RJ-45-inngangsporter:	1
Kan monteres på vegg:	Ja
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 90
Lyd-utgang kanaler:	7.1 kanaler
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Antall:	1
Innput-strøm:	0.5 A
Maksimal overføring avstand:	70 m
Kabeltyper som støttes:	Cat5e, Cat6, Cat6a
Consumer Electronics Control (CEC)-støtte:	Ja
HDCP & EDID bypass:	Ja
