Owner’s Manual

WARRANTY

REGISTRATION

chance to win a FREE Tripp Lite

product! www.tripplite.com/warranty

Fixed Flat Screen

Wall Mount

MODEL: DWF3770L

CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR

PROPERTY DAMAGE MAY OCCUR!

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

300x300/400x200

400x400/600x400

800x400

70”

MAX

65kg

(143lbs)

MAX

Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com

Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com

Русскоязычная версия настоящего руководства представлена на веб-сайте компании

Tripp Lite по адресу: www.tripplite.com

Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: www.tripplite.com

13-10-123-9332E2-EN.indd 1 11/12/2013 5:03:14 PM

NOTE: Read the entire instruction manual before you start installation and assembly.

Warranty & Warranty Registration

WARNING

• Do not begin the installation until you have read and understood the instructions

and warnings contained in this manual. If you have any question regarding any of

the instructions or warnings, please visit www.tripplite.com/support.

• This mounting bracket was designed to be installed and utilized ONLY as

speciﬁed in this manual. Improper installation of this product may cause damage

or serious injury.

• This product should only be installed by someone of good mechanical ability, with

basic building experience and a full understanding of this manual.

• Make sure that the supporting surface will safely support the combined load of

the equipment and all attached hardware and components.

• If mounting to wood wall studs, make sure that mounting screws are anchored

into the center of the studs. The use of a stud ﬁnder is highly recommended.

• Always use an assistant or mechanical lifting equipment to safely lift and position

equipment.

• Tighten screws rmly, but do not over tighten. Over tightening can damage the

items, greatly reducing their holding power.

• This product is intended for indoor use only. Using this product outdoors could

lead to product failure and personal injury.

5-Year Limited Warrant

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects

in material and workmanship for a period of 5 years from the date of initial purchase. If the product should

prove defective in material or workmanship within that period, Seller will repair or replace the product, in its sole

discretion.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE,

ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY

SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES,

INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY

PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL

DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not

allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions

may not apply to you. This warranty gives you speciﬁc legal rights, and you may have other rights which vary from

jurisdiction to jurisdiction).

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate

or safe for the use intended. Since individual applications are subject to great variation, the manufacturer makes

no representation or warranty as to the suitability or ﬁtness of these devices for any speciﬁc application.

WARRANTY REGISTRATION

Visit www.tripplite.com/warranty today to register the warranty for your new Tripp Lite product. You’ll be

automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Tripp Lite has a policy of continuous improvement. Speciﬁcations are subject to change without notice.

13-10-123-9332E2-EN.indd 2 11/12/2013 5:03:14 PM

Component Checklist

IMPORTANT: Ensure that you have received all parts according to the component checklist prior to

installing. If any parts are missing or faulty, visit www.tripplite.com/support for service.

Wall Plate (x1)

Adapter Bracket (x2)

Safety Bar (x1)

M5X14 (x4)

M8X30 (x4)

Anchor Bolt (x4) Concrete Anchor (x4) D6 Washer (x4)

M6X14 (x4)

Washer (x4)

M8X20 (x4)

Small Spacer (x8)

M6X30 (x4)

Big Spacer (x4)

Package M

Package W

13-10-123-9332E2-EN.indd 3 11/12/2013 5:03:15 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	veggfeste
Modell:	DWF3770L
Vekt:	1540 g
Bredde:	870 mm
Dybde:	19.3 mm
Høyde:	439.9 mm
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	2270 g
Antall skjermer som støttes:	1
Maksimal skjermstørrelse:	70 "
Minimum skjermstørrelse:	37 "
Produktfarge:	Sort
Pakkedybde:	901.7 mm
Pakkehøyde:	160 mm
Monteringssett:	Ja
Pakkebredde:	44.4 mm
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	85299097
Kroppsmateriale:	Metall
Panelmonterbart grensesnitt:	300 x 300,400 x 200,400 x 400,600 x 400,800 x 400 mm
Montasjetype:	Vegg
Maksimalvekt (kapasitet):	65 kg
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332181708
Masterkassens (ytterkassens) bruttovekt:	18600 g
Masterkassens (ytterkassens) lengde:	914.4 mm
Produkter per masterkasse (ytterkasse):	8 stykker
Masterkassens (ytterkassens) bredde:	350.5 mm
Masterkassens (ytterkassens) høyde:	185.4 mm
Monteringsgrensesnitt, kompatibilitet (min):	300 x 300 mm
Monteringsgrensesnitt, kompatibilitet (maks):	800 x 400 mm
Distanse til vegg (min.):	1.95 mm
