Side 1/20

Owner’s Manual

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Important Safety Instructions

2- or 4-Post Mounting (LCR2400 Model Only) 3

Quick Installation

Basic Operation 4

Service 5

Warranty and Product Registration 5

Ultimate Lifetime Insurance Policy 6

Español 7

Français 13

Line Conditioners

(120V, 60Hz Input/Output)

Models: LC1200, LC1800, LC2400, LCR2400

15-12-402-933510.indb 1 1/18/2016 12:45:53 PM

Important Safety Instructions

Line Conditioner Location Warnings

• Install your line conditioner indoors, away from excess moisture and heat, direct

sunlight, and dust and other conductive contaminants.

• For best performance, keep the indoor temperature between 32° F and 104° F

(between 0° C and 40° C).

• Leave adequate space around all sides of the line conditioner for proper ventilation.

Line Conditioner Connection Warnings

• Connect your line conditioner directly to a three-wire, grounded AC power outlet. Do

not remove or modify the ground pin of the line conditioner's plug. Do not use

adapters that would eliminate the line conditioner’s connection to ground.

• Do not use extension cords between the line conditioner and the AC outlet. If

necessary, a Tripp Lite surge protector may be used between the line conditioner and

the AC outlet.

• If you are connecting your line conditioner to a motor-powered AC generator, the

generator must provide clean, filtered computer-grade output. Connecting your line

conditioner to a generator will void its Ultimate Lifetime Insurance.

Equipment Connection Warning

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to

significantly affect its safety or effectiveness is not recommended. Do not use this

equipment in the presence of a flammable anesthetic mixture with air, oxygen or

nitrous oxide.

Line Conditioner Maintenance Warning

• Tripp Lite line conditioners require no maintenance. Keep the line conditioner dry at all

times. DO NOT open the unit for any reason.

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during

the installation, operation and storage of all Tripp Lite line conditioners.

Failure to heed these warnings will void your warranty.

15-12-402-933510.indb 2 1/18/2016 12:45:53 PM

2- or 4-Post Mounting (LCR2400 Model Only)

When mounting the LCR2400 line conditioner in a 2-post or 4-post rack, the user must

determine the fitness of hardware and procedures prior to installation. The procedures

described in this section are for common rack and rack enclosure types and may not be

appropriate for all applications.

Connect your line conditioner to an electrical

outlet.

Quick Installation

Plug your computer and electronics into your

line conditioner’s outlets.

Turn your line conditioner’s power switch on.

To install the line conditioner to a rack, insert

the included or user-supplied screws and

washers through the LCR2400’s mounting

ears and into the rack rails. Secure the unit

to the rack by tightening the screws with the

included or user-supplied nuts.

15-12-402-933510.indb 3 1/18/2016 12:45:54 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	grenuttak
Modell:	LC1800
Vekt:	4350 g
Bredde:	152.4 mm
Dybde:	177.8 mm
Høyde:	177.8 mm
LED-indikatorer:	Ja
Opprinnelsesland:	Taiwan
Pakkevekt:	4960 g
Utgangseffekt:	1800 W
Kabellengde:	7 m
Produktfarge:	Sort
Pakkedybde:	259.1 mm
Pakkehøyde:	195.6 mm
Pakkebredde:	218.4 mm
Bærekraftsertifikater:	RoHS
Kroppsmateriale:	Plast
Antall AC outlets:	6 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332040036
Masterkassens (ytterkassens) bruttovekt:	19230 g
Masterkassens (ytterkassens) lengde:	459.7 mm
Produkter per masterkasse (ytterkasse):	4 stykker
Masterkassens (ytterkassens) bredde:	269.2 mm
Masterkassens (ytterkassens) høyde:	421.6 mm
AC utløp type:	NEMA 5-15R
UPS AV-suppresjonsrangering:	1200 J
