Metered Rack PDU

Important Safety Instructions 2

Important Warnings 2

Installation 3

Features 4

Warranty & Warranty Registration 4

Español 5

Français 9

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

14-02-330-932567.indb 1 4/23/2014 3:58:20 PM

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be

followed during the installation, operation and storage of this

product. Failure to heed these instructions and warnings will void the

product warranty.

Important Warnings

• ThePDUprovidesconvenientmultipleoutletsbutitDOESNOTprovidesurgeor  

linenoiseprotectionforconnectedequipment.

• ThePDUisdesignedforindooruseonlyinacontrolledenvironmentawayfromexcessmoisture,

temperatureextremes,conductivecontaminants,dustordirectsunlight.

• DonotconnectthePDUtoanungroundedoutletorextensioncordsoradaptersthateliminate

theconnectiontoground.

• ThepowerrequirementforeachpieceofequipmentconnectedtothePDUmustnotexceedthe

individualoutlet’sloadrating.

• ThetotalpowerrequirementforequipmentconnectedtothePDUmustnotexceedthe

maximumloadratingforthePDU.

• DonotdrillintoorattempttoopenanypartofthePDUhousing.Therearenouser-serviceable

partsinside.

• DonotattempttomodifythePDU,includingtheinputplugsandpowercables.

• DonotattempttousethePDUifanypartofitbecomesdamaged.

• DonotattempttomountthePDUtoaninsecureorunstablesurface.

• Neverattempttoinstallelectricalequipmentduringathunderstorm.

• Useofthisequipmentinlifesupportapplicationswherefailureofthisequipmentcan

reasonablybeexpectedtocausethefailureofthelifesupportequipmentortosignificantly

affectitssafetyoreffectivenessisnotrecommended.Donotusethisequipmentinthe

presenceofaflammableanestheticmixturewithair,oxygenornitrousoxide.

14-02-330-932567.indb 2 4/23/2014 3:58:20 PM

Installation

Note: The illustrations may differ somewhat from your PDU

model.

Determine Installation Configuration.ThePDU

supportsfourprimaryinstallationconfigurations:1U

Rack,0URack,WallandUnder-Counter.Choosea

configurationandfollowtheinstallationinstructions

intheappropriatesectionofStep1before

proceedingtoStep2.

Note: Regardless of installation configuration, the

user must determine the fitness of hardware and

procedures before mounting. The PDU and included

hardware are designed for common rack and rack

enclosure types and may not be appropriate for all

applications. Exact mounting configurations may vary.

1-1

1U Rack Installation.AttachthePDUtotherackby

insertingfouruser-suppliedscrews(A)throughthe

PDUmountingbrackets(B)andintothemounting

holesoftherackrailasshown.

1-2

0U Rack Installation. Part 1:Removethescrews

(C)attachingthemountingbracketstothePDU,

changetheorientationofthebracketsasshownand

reattachthebrackets.Useonlythescrewssupplied

bythemanufacturerortheirexactequivalent(#6-

32,1/4”flathead). Part 2:AttachthePDUvertically

byinsertingtwoormoreuser-suppliedscrews(A)

throughthePDUmountingbrackets(B)andinto

mountingpointsintherackorrackenclosure.

1-3

Wall Installation. AfterrepeatingPart1above,

attachthePDUtoastablemountingsurfaceby

insertingtwoormoreuser-suppliedscrews(A)

throughthePDUmountingbrackets(B)andinto

securemountingpointsonthemountingsurface.

1-4

Under-Counter Installation. AfterrepeatingPart1

above,attachthePDUtoastablemountingsurface

byinsertingfouruser-suppliedscrews(A)throughthe

PDUmountingbrackets(B)andintosecuremounting

pointsonthemountingsurface.

Attach the input plug of the PDU to a grounded

outlet. Inserttheplugdirectlyintoagroundedoutlet

thatdoesnotshareacircuitwithaheavyelectrical

load(suchasanairconditionerorrefrigerator).

1-1

1-2

1-3

1-4

Note: Select models include an input plug adapter that converts the twist-lock input plug to a

straight-blade input plug. Attach the input plug adapter to the input plug if you wish to plug

the PDU into a compatible straight-blade outlet.

Attach equipment to the PDU. DonotexceedtheloadratingofthePDU.Thetotalelectrical

currentusedbythePDUwillbedisplayedonthedigitalmeterinamperes.

14-02-330-932567.indb 3 4/23/2014 3:58:22 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	grenuttak
Modell:	Metered PDUMH20-ISO
Vekt:	2090 g
Bredde:	508 mm
Dybde:	114.3 mm
Høyde:	50.8 mm
LED-indikatorer:	Ja
Opprinnelsesland:	China
Pakkevekt:	3220 g
Sertifisering:	UL1449\r\nCSA
Kabellengde:	4.57 m
Produktfarge:	Sort
Pakkedybde:	254 mm
Pakkehøyde:	57.2 mm
Pakkebredde:	520.7 mm
Driftstemperatur (T-T):	-15 - 50 °C
Bærekraftsertifikater:	RoHS
Kroppsmateriale:	Metall
Montering:	Horisontal
Driftshøyde:	0 - 3000 m
Rack-kapasitet:	1U
Relativ luftfuktighet under drift (H-H):	5 - 95
Display:	LED
Antall AC outlets:	14 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332185706
Masterkassens (ytterkassens) bruttovekt:	10070 g
Masterkassens (ytterkassens) lengde:	349.2 mm
Produkter per masterkasse (ytterkasse):	6 stykker
Masterkassens (ytterkassens) bredde:	527 mm
Masterkassens (ytterkassens) høyde:	247.6 mm
Strøm (maks.):	20 A
AC-utgangstyper:	NEMA 5–15R, NEMA 5–20R
Strømuttak:	NEMA 5–20P
Nominell innputspenning:	100-127 V
PDU types:	Målte
Nominell outputspenning:	100-127 V
