Tripp Lite PDU3MV6L2120 Bruksanvisning

Tripp Lite grenuttak PDU3MV6L2120

Les nedenfor 📖 manual på norsk for Tripp Lite PDU3MV6L2120 (36 sider) i kategorien grenuttak. Denne guiden var nyttig for 10 personer og ble vurdert med 4.7 stjerner i gjennomsnitt av 5.5 brukere

Last ned PDF

Side 1/36

Owner’s Manual

3-Phase Metered

Power Distribution Units

Important Safety Insructions 2

Installation 3

Digital Load Meter 6

Features 7

Service 8

Warranty and Product Registration 9

Español 10

Français 19

 28

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PDU3MV6L2120

(Series Number: AGPD8414)

PDU3MV6L2120LV

(Series Number: AGPD8414)

PDU3MV6L2120B

(Series Number: AGPD8414)

PDU3MV6L2130

(Series Number: AGPD8415)

PDU3MV6H50

(Series Number: AGPD8416)

PDU3MV6H50A

(Series Number: AGPD8417)

PDU3XMV6G20

(Series Number: AGPD8420)

PDU3XMV6L2220

(Series Number: AGPD8420)

PDU3MV6L2130A

(Series Number: AG-00E3)

15-07-049-933145.indb 1 8/7/2015 1:58:11 PM

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during

the installation, operation, and storage of this product. Failure to heed these

instructions and warnings may affect the product warranty.

• The PDU provides convenient multiple outlets, but it DOES NOT provide surge or line noise

protection for connected equipment.

• The PDU is designed for indoor use only in a controlled environment away from excess

moisture, temperature extremes, conductive contaminants, dust or direct sunlight.

• Do not connect the PDU to an ungrounded outlet or to extension cords or adapters that

eliminate the connection to ground.

• The power requirement for each piece of equipment connected to the PDU must not exceed

the individual outlet’s load rating.

• The total power requirement for equipment connected to the PDU must not exceed the

maximum load rating for the PDU.

• Do not drill into or attempt to open any part of the PDU housing. There are no user-serviceable

parts inside.

• Do not attempt to modify the PDU, including the input plugs and power cables.

• Do not attempt to use the PDU if any part of it becomes damaged.

• Do not attempt to mount the PDU to an insecure or unstable surface.

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to signiﬁcantly

affect its safety or effectiveness is not recommended. Do not use this equipment in the

presence of a ﬂammable anesthetic mixture with air, oxygen or nitrous oxide.

• Never attempt to install electrical equipment during a thunderstorm.

• Keep indoor ambient temperature between 32°F and 104°F (0°C and 40°C).

• Connect the PDU to an outlet that is in accordance with your local building codes and that is

adequately protected against excess currents, short circuits and earth faults.

• Do not attempt to open the PDU; there are no user-serviceable parts inside.

• The PDU must be installed by a qualiﬁed technician only.

• Install in accordance with National Electrical Codes. Be sure to use the proper over current

protection for the installation, in accordance with the plug rating/equipment rating.

• The electrical sockets supplying power to the equipment shall be installed near the equipment

and be easily accessible.

15-07-049-933145.indb 2 8/7/2015 1:58:11 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	grenuttak
Modell:	PDU3MV6L2120
Vekt:	5730 g
Bredde:	55.9 mm
Dybde:	49 mm
Høyde:	1778 mm
Opprinnelsesland:	Taiwan
Pakkevekt:	6990 g
Sertifisering:	UL60950-1, NOM
AC-inngangsfrekvens:	60 Hz
Overvåking:	Strøm (el)
Kabellengde:	1.83 m
Produktfarge:	Sort
Pakkedybde:	1935.5 mm
Pakkehøyde:	137.2 mm
Pakkebredde:	172.7 mm
Bærekraftsertifikater:	RoHS
Kroppsmateriale:	Stål
Montering:	Vertikal
Rack-kapasitet:	0U
Relativ luftfuktighet under drift (H-H):	0 - 95
Antall AC outlets:	48 AC-utganger
Produkter per masterkasse (ytterkasse):	1 stykker
Strøm (maks.):	16 A
Strømuttak:	NEMA L21-20P
Nominell innputspenning:	208 V
PDU types:	Målte
Nominell outputspenning:	120 V
Maksimal totalt strømforbruk per fase:	9.2 A
Belastningskapasitet:	5700 VA
