Owner’s Manual

Automatic Transfer Switch PDU

Models:

PDUMH30AT, PDUMH30ATNET, PDUMNH30AT2, PDUMH30HVAT,

PDUMH30HVATNET, PDUMNH30HVAT2, PDUMH32HVAT,

PDUMH32HVATNET, PDUMNH32HVAT2

Agency Model Numbers:

AGAC8033 • AGAC8034 • AGAC8110 • AGAC8073 • AG-0150 • AG-0151

Important Safety Instructions 2

Feature Set Overview 4

Installation 4

Mounting the PDU 4

Connecting the PDU 7

Features 8

LED Diagrams 15

Configuration and Operation 19

Automatic Transfer Switch 19

Service 21

Warranty and Product Registration 22

Español 23

Français 45

Русский 67

Deutsch 89

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

TrippLite.Eaton.com/support

Important Safety Instructions

This manual contains information concerning the proper installation

and use of Tripp Lite’s Rackmount Power Strips.

SAVE THESE INSTRUCTIONS.

Do not connect your power strip to an ungrounded outlet. Do not use it

with extension cords or adapters that eliminate its connection to

ground. Your power strip is designed for indoor use only. Install it away

from heat emitting devices such as radiators and heat registers. Do not

install where excessive moisture or other conductive contaminants are

present. Never install

electrical wiring during a lightning storm.

The power requirement of each device connected to an outlet of your

power strip must not exceed the Outlet Power Rating of your power

strip (see Specifications). The total power requirements of all devices

connected to your power strip must not exceed the Maximum Load

Rating of your power strip (see Specifications).

CAUTION Only those who are properly trained or qualified to use this

device should do so. Anyone who is not trained or qualified should not

use this device unless it is under the supervision of someone who is

properly trained or qualified to do so.

Children must be supervised to ensure that they do not use the device

as a toy.

Never use the device if the cord and plug are damaged; if it is not

working properly, or if it has been dropped or damaged, take it to an

authorized service center for inspection and repair.

If the power cord is damaged, it must be replaced by the manufacturer,

its authorized service agent, or by qualified personnel in order to avoid

a danger.

• The PDU provides the convenience of multiple outlets, but DOES NOT provide surge

or line noise protection for connected equipment.

• The PDU is designed for indoor use only, in a controlled environment, away from

excess moisture, temperature extremes, conductive contaminants, dust or direct

sunlight.

• Keep indoor ambient temperature between 32°F and 104°F (0°C and 40°C).

• The PDU must be installed by a qualified technician only.

• Only those who are properly trained or qualified to use this device should do so.

Anyone who is not trained or qualified should not use this device unless it is under

the supervision of someone who is properly trained or qualified to do so.

• Do not attempt to mount the PDU to an insecure or unstable surface.

• Install in accordance with National Electrical Code standards. Be sure to use the

proper overcurrent protection for the installation, in accordance with the plug/

equipment rating.

Important Safety Instructions

• Connect the PDU to an outlet that is in accordance with your local building codes

and that is adequately protected against excess currents, short circuits and earth

faults.

• The electrical outlets supplying power to the equipment should be installed near the

equipment and easily accessible.

• Do not connect the PDU to an ungrounded outlet or to extension cords or adapters

that eliminate the connection to ground.

• Be sure to provide a local disconnect device on any models that are permanently

installed without a plug that is easily accessible.

• Never attempt to install electrical equipment during a thunderstorm.

• Individual equipment connected to the PDU should not draw more current than the

individual PDU’s outlet’s rating.

• The total load connected to the PDU must not exceed the maximum load rating for

the PDU.

• Do not attempt to modify the PDU, input plugs or power cables.

• Do not drill into or attempt to open any part of the PDU housing. There are no user-

serviceable parts inside.

• Do not attempt to use the PDU if any part of it becomes damaged.

• This equipment is not suitable for use in locations where children are likely to be

present.

• Use of this equipment in life support applications where failure of this equipment

can reasonably be expected to cause the failure of the life support equipment or to

significantly affect its safety or effectiveness is not recommended.

• The AC Main tolerance of this equipment is +6/-10%.
