Side 1/12

Owner’s Manual

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed

during the installation, operation and storage of this product. Failure to

heed these instructions and warnings may affect the product warranty.

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Important Safety Instructions

• ThePDUprovidesconvenientmultipleoutletsbutitDOESNOTprovidesurgeorlinenoise

protectionforconnectedequipment.

• ThePDUisdesignedforindooruseonlyinacontrolledenvironmentawayfromexcessmoisture,

temperatureextremes,conductivecontaminants,dustordirectsunlight.

• DonotconnectthePDUtoanungroundedoutletorextensioncordsoradaptersthateliminatethe

connectiontoground.

• Useofthisequipmentinlifesupportapplicationswherefailureofthisequipmentcanreasonablybe

expectedtocausethefailureofthelifesupportequipmentortosignificantlyaffectitssafetyor

effectivenessisnotrecommended.Donotusethisequipmentinthepresenceofaflammable

anestheticmixturewithair,oxygenornitrousoxide.

• ThepowerrequirementforeachpieceofequipmentconnectedtothePDUmustnotexceedthe

individualoutlet'sloadrating.

• ThetotalpowerrequirementforequipmentconnectedtothePDUmustnotexceedthemaximum

loadratingforthePDU.

• DonotdrillintoorattempttoopenanypartofthePDUhousing.Therearenouser-serviceableparts

inside.

• DonotattempttomodifythePDU,includingtheinputplugsandpowercables.

• DonotattempttousethePDUifanypartofitbecomesdamaged.

• DonotattempttomountthePDUtoaninsecureorunstablesurface.

• Neverattempttoinstallelectricalequipmentduringathunderstorm.

Rack PDU

Metered Models: PDUMV15 and PDUMV20

Basic Models: PDUV15 and PDUV20

Español – p. 5 • Français – p. 9

©2014TrippLite.Allrightsreserved.

14-02-334-933043.indd 1 3/26/2014 11:52:06 AM

PDUMV15 and

PDUV15

PDUV20 and PDUMV20

Installation

Zero U Rack Configuration.Attachthethreemountingclips

suppliedwiththePDUtotherackenclosureusingtheincluded

hardware.Themountingclipsshouldbeattachedalonga

verticalplaneatequidistantpointswhichroughlycorrespond

tothecenterandendsofthePDU.Theexactmounting

configurationmayvarydependingontherackandenclosure.If

possible,usepre-existingmountingpointswithinthe

enclosure.

Wall or Under-Counter Configuration.Attachthethree

mountingclipssuppliedwiththePDUtoawallorsimilarflat,

securesurfaceusingtheincludedhardware.Themounting

clipsshouldbeattachedalongaverticalorhorizontalplaneat

equidistantpointswhichroughlycorrespondtothecenterand

endsofthePDU.Ifpossible,usepre-existingmountingpoints.

WARNING: Do not attempt to mount the PDU with the

outlets facing downward; the mounting clips are not

designed to support the weight of the PDU in that manner.

Zero U Rack Configuration (Mounting Buttons). Attachthe

includedmountingbuttonstothePDU.PositionthePDUas

desiredintherackenclosure,alignthebuttonswiththerack

mountingslots,andslidethePDUintoposition.

Note: Regardless of configuration, the user must determine the

fitness of hardware and procedures before mounting. The PDU

and included hardware are designed for common rack and rack

enclosure types and may not be appropriate for all

applications.

Attach the PDU to the mounting clips.Usinganassistant,

placearearcornerofthePDUontheinsideedgeofthe

mountingclips,pivotthePDUtowardthealternateinsideedge

andsnapintoplace.

Attach the input plug of the PDU to a grounded outlet.

Inserttheplugdirectlyintoagroundedoutletthatdoesnot

shareacircuitwithaheavyelectricalload(suchasanair

conditionerorrefrigerator).

Attach equipment to the PDU.Donotexceedtheloadrating

ofthePDU.ThetotalelectricalcurrentusedbythePDUwill

bedisplayedonthedigitalmeterinamperes.

Optional Installation (Models PDUV20 & PDUMV20).The

PDUincludesanadapterthatconvertstheL5-20Pinputplug

toa5-20Pinputplug.Theadapterisoptional;thePDUwill

workproperlywithoutconnectingtheadapter.

14-02-334-933043.indd 2 3/26/2014 11:52:08 AM

1 2

Features

NEMA 5-15P Input Plug (Models PDUV15 & PDUMV15)

NEMA 5-15R Outlets (Models PDUV15 & PDUMV15)

NEMA L5-20P Input Plug (Models PDUV20 & PDUMV20)

NEMA 5-15/20R Outlets (Models PDUMV20 and PDUV20)

NEMA 5-20P Plug Adapter (Models PDUV20 & PDUMV20): Theadapterconvertstheinput

plugfromNEMAL5-20PtoNEMA5-20P.

Circuit Breaker: IfthecurrentdrawnbytheequipmentconnectedtothePDUexceeds

theMaximumLoadRating,thecircuitbreakerwilltriptopreventpossibledamage.Whenthe

circuitbreakertrips,itsplungerwillpopup.Disconnectexcessequipmentandallowthebreakerto

coolatleastoneminutebeforedepressingtheplungertoresetthebreaker.

Ammeter (Models PDUMV15 and PDUMV20 only): Thetotalelectricalcurrentusedbythe

PDUwillbedisplayedonthedigitalmeterinamperes.

Illuminated Power Switch with Cover (Models PDUMV15 and PDUMV20 only)

14-02-334-933043.indd 3 3/26/2014 11:52:09 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	grenuttak
Modell:	PDUMV20
Vekt:	2440 g
Bredde:	38.1 mm
Dybde:	41.7 mm
Høyde:	1535.9 mm
LED-indikatorer:	Ja
Opprinnelsesland:	China
Pakkevekt:	3180 g
Sertifisering:	UL60950-1 (USA) and CAN/CSA C22.2 No. 60950-1-03 (Canada)
AC-inngangsfrekvens:	50 - 60 Hz
Kabellengde:	4.6 m
Produktfarge:	Sort
Pakkedybde:	1605.3 mm
Pakkehøyde:	61 mm
Pakkebredde:	88.9 mm
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	RoHS
Kroppsmateriale:	Aluminium
Montering:	Vertikal
Driftshøyde:	0 - 3000 m
Rack-kapasitet:	0U
Antall AC outlets:	28 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332132540
Masterkassens (ytterkassens) bruttovekt:	19960 g
Masterkassens (ytterkassens) lengde:	1625.6 mm
Produkter per masterkasse (ytterkasse):	6 stykker
Masterkassens (ytterkassens) bredde:	210.8 mm
Masterkassens (ytterkassens) høyde:	200.7 mm
Innput-forbindelsestype:	NEMA 5-20P, NEMA L5-20P
Strøm (maks.):	20 A
AC-utgangstyper:	NEMA 5–15, NEMA 5–20R
Nominell innputspenning:	100-127 V
PDU types:	Målte
Nominell outputspenning:	100-127 V
