Side 1/32

Basic, Metered and Metered with

Isobar

Surge Protection Vertical

Rack PDUs

Models:

PDUMV30, PDUMV30HV, PDUV30HV, PDUV30-36,

PDUMV30-ISO, PDUMV20HV, PDUMV20HVL6,

PDUMV20HV-36, PDUV20HVL6-72

(Series Numbers: AGIB6672, AGPD6673, AGPD6674)

Important Safety Instructions 2

Important Warnings 2

Installation 4

Features 4

Warranty & Product Registration 6

Español 7

Français 13

Русский 19

Deutsch 25

TrippLite.Eaton.com/support

Owner’s Manual

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be

followed during the installation, operation and storage of this

product. Failure to heed these instructions and warnings will

void the product warranty.

CAUTION Only those who are properly trained or qualified to use this device

should do so. Anyone who is not trained or qualified should not use this device

unless it is under the supervision of someone who is properly trained or qualified

to do so. Children must be supervised to ensure that they do not use the device

as a toy.

Do not install this device if there is not at least 10 meters (30 feet) or more of wire

between the electrical outlet and the electrical service panel.

Never use the device if the cord and plug are damaged; if it is not working

properly, or if it has been dropped or damaged, take it to an authorized service

center for inspection and repair.

If the power cord is damaged, it must be replaced by the manufacturer, its

authorized service agent, or by qualified personnel in order to avoid a danger.

• The PDUMV30-ISO PDU model provides surge and line noise protection to connected

equipment through its outlets.

• Non-ISO PDUs do not provide surge and line protection to connected equipment.

• The PDU is designed for indoor use only in a controlled environment away from excess

moisture, temperature extremes, conductive contaminants, dust or direct sunlight.

• The PDU must be installed by a qualified technician only.

• Install in accordance with National Electrical Code standards. Be sure to use the proper

overcurrent protection for the installation, in accordance with the plug/equipment rating.

• Connect the PDU to an outlet that is in accordance with your local building codes and

adequately protected against excess currents, short circuits, and earth faults.

• Keep indoor ambient temperatures between 32°F and 77°F (0°C and 25°C).

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to

significantly affect its safety or effectiveness is not recommended. Do not use this

equipment in the presence of a flammable anesthetic mixture with air, oxygen or nitrous

oxide.

• Do not connect the PDU to an ungrounded outlet or extension cords or adapters that

eliminate the connection to ground.

• The power requirement for each piece of equipment connected to the PDU must not

exceed the individual outlet’s load rating.

• The plug on the power supply cord serves as the disconnect device.

Important Safety Instructions

Important Warnings

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	grenuttak
Modell:	PDUMV20HV-36
Vekt:	2360 g
Bredde:	57.2 mm
Dybde:	1009.6 mm
Høyde:	95.2 mm
LED-indikatorer:	Ja
Opprinnelsesland:	China
Pakkevekt:	4310 g
Overvåking:	Strøm (el)
Kabellengde:	3.05 m
Produktfarge:	Sort
Pakkedybde:	1054.1 mm
Pakkehøyde:	127 mm
Pakkebredde:	88.9 mm
Oppbevaringstemperaturomåde (Celsius):	-30 - 50 °C
Lagringsrelativ fuktighet:	0 - 95
Modell/Type:	Enkelfaset
Kroppsmateriale:	Aluminium
Montering:	Vertikal
Rack-kapasitet:	0U
Relativ luftfuktighet under drift (H-H):	0 - 95
Display:	LCD
Maksimal styrke:	3840 W
Antall AC outlets:	20 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332255928
Masterkassens (ytterkassens) bruttovekt:	27580 g
Masterkassens (ytterkassens) lengde:	1066.8 mm
Produkter per masterkasse (ytterkasse):	6 stykker
Masterkassens (ytterkassens) bredde:	406.4 mm
Masterkassens (ytterkassens) høyde:	177.8 mm
Strøm (maks.):	20 A
AC-utgangstyper:	C13 coupler, C19 coupler
Strømuttak:	NEMA L6-20P
Nominell innputspenning:	200 - 240 V
PDU types:	Målte
Nominell outputspenning:	200 - 240 V
