Side 1/16

Rack PDU

Important Safety Instructions 2

Important Warnings 2

Installation 3

Features 4

Warranty & Product Registration 5

Español 6

Français 11

Metered Models:

PDUMV15

(Series Number: AGIB6098)

PDUMV20

(Series Number: AGIB6099)

Basic Models:

PDUV15

(Series Number: AGIB6098)

PDUV20

(Series Number: AGIB6099)

PDUV20-60

(Series Number: AGIB6099)

PDUV15-48

(Series Number: AGIB6098)

Owner’s Manual

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

20-09-044-93364D.indb 120-09-044-93364D.indb 1 10/8/2020 11:08:33 AM10/8/2020 11:08:33 AM

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be

followed during the installation, operation and storage of this

product. Failure to heed these instructions and warnings will

void the product warranty.

• The PDU provides the convenience of multiple outlets, but DOES NOT provide surge or line

noise protection for connected equipment.

• The PDU is designed for indoor use only, in a controlled environment, away from excess

moisture, temperature extremes, conductive contaminants, dust or direct sunlight.

• Keep indoor ambient temperature between 32°F and 77°F (0°C and 25°C).

• The PDU must be installed by a qualified technician only.

• Do not attempt to mount the PDU to an insecure or unstable surface.

• Install in accordance with National Electrical Code standards. Be sure to use the proper

overcurrent protection for the installation, in accordance with the plug/equipment rating.

• Connect the PDU to an outlet that is in accordance with your local building codes and that

is adequately protected against excess currents, short circuits and earth faults.

• The electrical outlets supplying power to the equipment should be installed near the

equipment and easily accessible.

• Do not connect the PDU to an ungrounded outlet or to extension cords or adapters that

eliminate the connection to ground.

• Be sure to provide a local disconnect device on any models that are permanently installed

without a plug that is easily accessible.

• Never attempt to install electrical equipment during a thunderstorm.

• Individual equipment connected to the PDU should not draw more current than the

individual PDU’s outlet’s rating.

• The total load connected to the PDU must not exceed the maximum load rating for the

PDU.

• Do not attempt to modify the PDU, input plugs or power cables.

• Do not drill into or attempt to open any part of the PDU housing. There are no user-

serviceable parts inside.

• Do not attempt to use the PDU if any part of it becomes damaged.

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to significantly

affect its safety or effectiveness is not recommended.

Important Safety Instructions

Important Warnings

20-09-044-93364D.indb 220-09-044-93364D.indb 2 10/8/2020 11:08:33 AM10/8/2020 11:08:33 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	grenuttak
Modell:	PDUV15-48
Vekt:	1700 g
Bredde:	38.1 mm
Dybde:	41.7 mm
Høyde:	1231.1 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	2010 g
Sertifisering:	UL60950-1 (USA) and CAN/CSA C22.2 No. 60950-1-03 (Canada)
AC-inngangsfrekvens:	50 - 60 Hz
Kabellengde:	4.57 m
Produktfarge:	Sort
Pakkedybde:	61 mm
Pakkehøyde:	1315 mm
Pakkebredde:	87.1 mm
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	RoHS
Kroppsmateriale:	Metall
Montering:	Vertikal
Driftshøyde:	0 - 3000 m
Rack-kapasitet:	0U
Antall AC outlets:	16 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332255812
Masterkassens (ytterkassens) bruttovekt:	12830 g
Masterkassens (ytterkassens) lengde:	1335 mm
Produkter per masterkasse (ytterkasse):	6 stykker
Masterkassens (ytterkassens) bredde:	195.1 mm
Masterkassens (ytterkassens) høyde:	214.9 mm
Strøm (maks.):	15 A
AC-utgangstyper:	NEMA 5–15R
Strømuttak:	NEMA L5-15P
Nominell innputspenning:	100-127 V
PDU types:	Grunnleggende
Rack-montert sett:	Ja
Nominell outputspenning:	100-127 V
