Side 1/4

Owner’s Manual

Protect It!

Desktop Grommet

Surge Protector with

USB Charging

3-Outlet Model: TLP310DMUSB

4-Outlet Model: TLP410DMUSB

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

is a registered trademark of Tripp Lite.

Important Safety Instructions 2

Installation 2

Product Registration 4

Lifetime Limited Warranty 4

Ultimate Lifetime 4

Insurance Policy

16-09-096-933648-EN.indd 1 9/21/2016 5:09:21 PM

Important Safety Instructions

Installation

SAVE THESE INSTRUCTIONS

CAUTION! DO NOT connect to an ungrounded outlet. DO NOT use with 2-wire extension cords

or adapters. This surge protector is designed for indoor use only. Install the surge protector away

from heat-emitting appliances such as radiators or heat registers. Do not install where excessive

moisture is present. Do not plug extension cords into it. Never install electrical, telephone,

network or coaxial wiring during a lightning storm. Do not drill into any part of the housing or

open the housing for any reason. There are no user-serviceable parts inside.

• Use of this equipment in life support applications where failure of this equipment can reasonably

be expected to cause the failure of the life support equipment or to signiﬁcantly affect its safety

or effectiveness is not recommended. Do not use this equipment in the presence of a ﬂammable

anesthetic mixture with air, oxygen or nitrous oxide.

Determine/drill the desktop hole size.

For desktops with pre-installed grommet holes, measure the hole diameter. Drill a larger hole,

if necessary. For desktops without pre-installed grommet holes, drill the appropriately sized

hole for the model.

Install clips.

Snap in the included clips into the two slots located on the sides of the surge protector

grommet.

2 ½” (64 mm)

2 ” (60 mm)

TLP310DMUSB (3-Outlet Model) TLP410DMUSB (4-Outlet Model)

16-09-096-933648-EN.indd 2 9/21/2016 5:09:23 PM

Installation

Insert the surge protector into the desktop’s grommet hole.

TLP410DMUSB model shown in illustration.

Product appearance will vary by model.

TLP310DMUSB TLP410DMUSB (3-Outlet Model) (4-Outlet Model)

Plug the surge protector’s power cord into a standard, 3-wire grounded 120V

AC outlet.

Pull the unit out of the grommet completely

, then fold the surge protector

down onto the desktop

Connect equipment to the surge protector’s AC outlets, USB charging ports

and RJ45 Ethernet port (TLP310DMUSB only).

When not in use, disconnect equipment, pull the surge protector up to a

straight, vertical position, then push the surge protector into the grommet

for unobstructed storage.

16-09-096-933648-EN.indd 3 9/21/2016 5:09:25 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	grenuttak
Modell:	Protect It! TLP410DMUSB
Vekt:	790 g
Bredde:	57.2 mm
Dybde:	59.9 mm
Høyde:	293.1 mm
Opprinnelsesland:	China
Pakkevekt:	910 g
Materiale:	Plast
AC-inngangsfrekvens:	60 Hz
Klemmespenning:	400 V
Toppstrøm, normal modus:	15 A
Kabellengde:	3.05 m
Produktfarge:	Sort
Antall USB-porter:	2
Pakkedybde:	304.8 mm
Pakkehøyde:	106.7 mm
Pakkebredde:	76.2 mm
Bærekraftsertifikater:	RoHS
Oppdateringsresponstid:	0.00006 ms
Antall AC outlets:	4 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332199635
Masterkassens (ytterkassens) bruttovekt:	9250 g
Masterkassens (ytterkassens) lengde:	406.4 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	238.8 mm
Masterkassens (ytterkassens) høyde:	345.4 mm
AC-utgangstyper:	NEMA 5–15R
Strømuttak:	NEMA 5–15P
Nominell innputspenning:	120 V
Strømstøt energivurdering:	1500 J
