Protect It!
®
Surge
Protectors with Dedicated
USB Charging Ports
Models: TLP606USB, TLP606DMUSB
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2018. All rights reserved. Protect It!
®
is a registered trademark of Tripp Lite.
Owner’s Manual
Important Safety Instructions 2
Installation 2
Lifetime Limited Warranty 3
Product Registration 3
Ultimate Lifetime Insurance Policy 4
Español 5
Français 9
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an
ISOBAR6ULTRA surge protector—
a $100 value!
www.tripplite.com/warranty
18-08-295-9332C8.indb 1 9/10/2018 10:27:55 AM
2
SAVE THESE INSTRUCTIONS
CAUTION! DO NOT connect to an ungrounded outlet. DO NOT use with 2-wire extension
cords or adapters. This surge protector is designed for indoor use only. Install the surge
protector away from heat-emitting appliances such as radiators or heat registers. Do
not install where excessive moisture is present. Do not plug extension cords into it.
Never install electrical, telephone, network or coaxial wiring during a lightning storm. Do
not drill into any part of the housing or open the housing for any reason. There are no
user-serviceable parts inside.
Important Safety Instructions
• Use of this equipment in life support applications where failure of this equipment can
reasonably be expected to cause the failure of the life support equipment or to significantly
affect its safety or effectiveness is not recommended. Do not use this equipment in the
presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide.
Installation
Mount Your Surge Protector
(Optional Installation, TLP606USB Only): If desired, mount your surge protector on a wall
or other sturdy, vertical surface. However, you must mount the surge protector prior to
connecting your equipment. Place a sheet of paper over the surge protector’s mounting
holes and mark their centers with a push pin. Next, place this template over the desired
area and mark with the push pins. Install screws (user supplied) into the marks until ¼ in.
(0.6 cm) of the screw heads are exposed. Mount the surge protector over the screw heads
and slide into place.
(Installation, TLP606DMUSB
Only): This protector features a
built-in clamping system for
attaching the unit to desks,
tables and work benches. To
install, loosen the two mounting
clamps, then slide the protector
firmly onto the edge of an
appropriate surface. Retighten
the mounting clamps.
Connect Your Surge Protector to
the AC Power Line: Plug the surge
protector’s power cord into a
standard, 3-wire grounded 120V AC
outlet.
Turn Your Surge Protector ON:
Press the surge protector’s power
switch to “ON” or “RESET”
(depending on model). Select
models feature an illuminated switch.
Installation, TLP606DMUSB Only
18-08-295-9332C8.indb 2 9/10/2018 10:27:55 AM
3
Installation
Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and
workmanship for its lifetime. If the product should prove defective in material or workmanship within that period, Seller will repair
or replace the product, in its sole discretion. Service under this Warranty can only be obtained by your delivering or shipping the
product (with all shipping or delivery charges prepaid) to: Tripp Lite, 1111 W. 35th St., Chicago, IL 60609. Seller will pay return
shipping charges.
The warranties of all TRIPP LITE surge protectors are null and void if they have been connected to the output of any UPS system.
The warranties of all TRIPP LITE UPS Systems are null and void if a surge protector has been connected to its output receptacles.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR
NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO
THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY
OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY
EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied
warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you. This Warranty gives you specific legal rights, and you may have other rights which
vary from jurisdiction to jurisdiction.)
WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the
use intended. Since individual applications are subject to great variation, the manufacturer makes no representation or warranty
as to the suitability or fitness of these devices for any specific application.
The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.
Regulatory Compliance Identification Numbers
For the purpose of regulatory compliance certifications and identification, your Tripp Lite product has been assigned a unique
series number. The series number can be found on the product nameplate label, along with all required approval markings and
information. When requesting compliance information for this product, always refer to the series number. The series number
should not be confused with the marketing name or model number of the product.
Lifetime Limited Warranty
Product Registration
Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a
chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
Check Your Surge Protector’s Diagnostic Indicator Lights: If your surge protector features
diagnostic LEDs, check them prior to connecting your equipment. They will indicate various
operating conditions when the surge protector is plugged into a live 120V AC outlet and the
surge protector’s power switch is on.
“PROTECTED” LED: Indicates the surge protection components are intact and providing
complete protection against surges. If this LED does not illuminate, some of the surge
protecton components are not functioning, and the unit should be replaced. Visit
www.tripplite.com/support.
“GROUNDED” LED: Indicates wall outlet is grounded and surge protection can properly
function. If this light DOES NOT illuminate and power is present, consult a qualified
electrician to examine your outlet’s wiring.
Connect Your Equipment to the Surge Protector’s AC Outlets: Plug your equipment’s power
cords (including 2-wire devices) into the surge protector’s AC outlets. Models feature special
widely-spaced outlets to accommodate transformers without covering other outlets. DO NOT plug
in extension cords. DO NOT OVERLOAD the surge protector’s outlets. The surge protector can
accommodate a total equipment load of up to 15 amps (whether plugged into a single outlet or
spread out over multiple outlets). If the load on the surge protector exceeds 15 amps, the circuit
breaker will trip and the outlets will stop providing power. If the circuit breaker trips, reduce the
load by unplugging some devices.
USB Charging Ports: Two USB charging ports are capable of delivering up to 2.4A total. This
will provide enough power to charge the most demanding devices, including smartphones,
tablets and MP3 players.
Note: The charging ports are controlled by the master power switch on the unit.
18-08-295-9332C8.indb 3 9/10/2018 10:27:55 AM
