Side 1/8

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Owner’s Manual

IMPORTANT SAFETY INSTRUCTIONS.

SAVE THESE INSTRUCTIONS.

WARNING!

1. Only use the Specialty Purpose Relocatable Power Tap (SPRPT) for supplying power to

equipment that is intended to form part of the medical system.

2. The SPRPT shall be permanently attached to the medical system by a means such that it is

only removable with the use of a tool. It shall not be located or positioned on the ﬂoor.

3. Do not use with any device that is not part of the medical system in which the SPRPT is

installed. Do not connect equipment that is not part of the medical system to any unused

SPRPT outlets. Do not touch parts of the SPRPT and the patient simultaneously. To remove

power from the unit, disconnect using the plug cap. Do not pull on the supply cord.

The use of this SPRPT does not ensure that a medical system compliant with any standard

or speciﬁcations (such as local codes) will result. Only those qualiﬁed to assemble a medical

system shall attempt to do so. The UL 60601-1 standard is used to determine the suitability

of a medical electrical system. In accordance with UL 60601-1, in a medical system the

medical equipment connections to the SPRPT shall only be accessible with the use of a tool.

If you are not familiar with this standard and/or medical systems, do not use this device.

5. Do not connect non-medical equipment that has been supplied Risk of Electric Shock:

as part of the medical system directly to a wall outlet when said non-medical equipment is

intended to be supplied via a SPRPT with a separating transformer.

6. Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to signiﬁcantly

affect its safety or effectiveness is not recommended. Do not use this equipment within

oxygen-enriched atmospheres, or within 0.3 m of a point at which an oxygen-enriched

atmosphere is intentionally vented.

7. The SPRPT shall be used within its marked load rating.

8. Short circuit backup protection is to be provided through the building installation.

Specialty Purpose

Relocatable Power Taps

(Power Strips for Medical Systems)

Series Numbers: AGIB6758, AGIB8422

Español 3 • Français 5

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

17-06-030-933705.indb 1 6/9/2017 12:24:25 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	grenuttak
Modell:	PS-415-HG-OEMRA
Vekt:	1170 g
Bredde:	63.5 mm
Dybde:	43.9 mm
Høyde:	216.9 mm
Opprinnelsesland:	Vietnam
Pakkevekt:	1270 g
Sertifisering:	TUV tested to UL 1363A
Materiale:	Metall
Toppeffekt:	1800 W
AC-inngangsfrekvens:	50 - 60 Hz
Kabellengde:	4.57 m
Produktfarge:	Hvit
Pakkedybde:	62 mm
Pakkehøyde:	251 mm
Pakkebredde:	158 mm
Antall medfølgende produkter:	1 stykker
Antall AC outlets:	4 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332239386
Masterkassens (ytterkassens) bruttovekt:	13360 g
Masterkassens (ytterkassens) lengde:	326.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	332 mm
Masterkassens (ytterkassens) høyde:	270 mm
AC-utgangstyper:	NEMA 5–15R
Strømuttak:	NEMA 1–15P
Nominell innputspenning:	120 V
Strømstøt energivurdering:	- J
Nominell strømoutput:	15 A
