Side 1/12

Power Strips

Models: PS120406, PS120420, PS240406, PS2408RA,

PS240810, PS3612RA, PS361206, PS361220 and

PS480806

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Owner’s Manual

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $50 value!

www.tripplite.com/warranty

PS-Series Power Strips are designed to provide convenient access to multiple AC outlets.

Note: The Power Strip models listed above DO NOT provide your connected equipment with surge or line-noise

protection.

Important Safety Instructions 2

Equipment Connection 2

Wall Mounting 2

Speciﬁcations 3

Warranty and 4

Product Registration

Español 5

Français 9

15-02-180-933408.indb 1 2/18/2015 10:41:57 AM

Equipment Connection

Plug your equipment into the Power Strip’s AC receptacles. DO NOT plug in equipment that draws

more total amps than your Power Strip’s amperage rating (see label on Power Strip for amperage

rating), or you will trip the circuit breaker. If the circuit breaker trips, remove overload and depress

breaker to reset. Leave enough clearance at the end of the Power Strip to allow the circuit

breaker to operate normally.

Note: Select models with a power switch feature a protective switch cover. To access the switch, ﬂip open the

attached cover.

Wall Mounting

All Power Strip models feature clips for horizontal or vertical mounting on a variety of surfaces.

The user must supply other mounting hardware (screws, etc.) and determine its suitability for use

with the chosen mounting surface.

Mark a straight horizontal or vertical line where

you want to mount the Power Strip. At each end

of the line, mark where the edges of the Power

Strip will be located. Place a mounting clip on

the mounting surface 1” (2.54 cm) in from

these edges and mark where the screws must

be driven into the wall. For strips longer than

48” (120 cm), also mark a screw hole for a third

mounting clip midway between the other two.

Keyhole Mounting: Drive #8 screws directly

into the mounting surface. Snap the mounting

clips onto the Power Strip

, then hang the

Power Strip on the screws by the keyhole slots

on its mounting clips

Important Safety Instructions

SAVE THESE INSTRUCTIONS

• DO NOT connect the power strip to an ungrounded outlet.

• DO NOT use the power strip with 2-wire extension cords or adapters.

• This power strip is designed for indoor use only. Install the power strip away from heat-emitting

appliances such as radiators or heat registers.

• Do not install where excessive moisture is present.

• Do not plug extension cords into the power strip.

• Never install electrical, telephone, network or coaxial wiring during a lightning storm.

• Do not drill into any part of the housing or open the housing for any reason. There are no

user-serviceable parts inside.

15-02-180-933408.indb 2 2/18/2015 10:41:58 AM

Speciﬁcations

Model

Amperage

Rating

Outlet

Qty. x Type

Input

Plug

Cord

Length

Overall

Length Breaker

PS120406

15A 4 x 5-15R 5-15P 6 ft. 12 in. 15A

PS120420

20A 2 x 5-20R, 2 x 5-15R 5-20P 15 ft. 12 in. 20A

PS240406

15A 4 x 5-15R 5-15P 6 ft. 24 in. 15A

PS2408RA

15A 8 x 5-15R* 5-15P* 15 ft. 24 in. 15A

PS240810

15A 8 x 5-15R 5-15P 10 ft. 24 in. 15A

PS3612RA

15A 12 x 5-15R* 5-15P* 15 ft. 36 in. 15A

PS361206

15A 12 x 5-15R 5-15P 6 ft. 36 in. 15A

PS361220

20A 2 x 5-20R, 10 x 5-15R 5-20P 15 ft. 36 in. 20A

PS480806

15A 8 x 5-15R 5-15P 6 ft. 48 in. 15A

*Right-angle

Wall Mounting (Continued)

3a 3b

Clip Mounting: Drive #10 screws through

washers, through the centers of the mounting

clips and into the mounting surface

. Place

the Power Strip inside one edge of the mounting

clips, then snap the Power Strip into place

15-02-180-933408.indb 3 2/18/2015 10:41:58 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	grenuttak
Modell:	PS120406
Vekt:	580 g
Bredde:	41.1 mm
Dybde:	304.8 mm
Høyde:	31.8 mm
Opprinnelsesland:	China
Pakkevekt:	810 g
Sertifisering:	UL1363\r\ncUL\r\nRoHS
Materiale:	Aluminium
Kabelfarge:	Sort
AC-inngangsspenning:	120 V
Kabellengde:	1.83 m
Produktfarge:	Black, Grey
Pakkedybde:	395 mm
Pakkehøyde:	77 mm
Pakkebredde:	90.9 mm
Av/på-bryter:	Ja
Antall medfølgende produkter:	1 stykker
Antall AC outlets:	4 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332186116
Masterkassens (ytterkassens) bruttovekt:	10320 g
Masterkassens (ytterkassens) lengde:	424.9 mm
Produkter per masterkasse (ytterkasse):	12 stykker
Masterkassens (ytterkassens) bredde:	293.9 mm
Masterkassens (ytterkassens) høyde:	309.9 mm
Strøm (maks.):	15 A
AC-utgangstyper:	NEMA 5–15R
