Side 1/20

PRODUCT

REGISTRATION

chance to win an ISOBAR

surge

protector in our monthly drawing!

Tripplite.Eaton.com/warranty

Important Safety Instructions 2

Installation 3

Features 4

Specifications 5

Warranty & Product Registration 5

Ultimate Lifetime Insurance Policy 6

Rack-mount Power Strips & Isobar

Rack-mount Surge Protectors/

Line-Noise Filters

Español 7

Français 13

Models:

DRS-1215

IBAR12

IBAR12-20T

ISOBAR12ULTRA

ISOBAR12/20ULTRA

RS-0615-F

RS-0615-R

RS-1215

RS-1215-20

RS-1215-20T

RS1215-HG

RS-1215-RA

Designed to Occupy One Standard

(1U) 19" Rack Space

(IBAR12, ISOBAR12ULTRA, RS-1215, RS-1215-RA, RS-1215-HG, DRS-1215): DO

NOT exceed the MAXIMUM LOAD of 15 amps that can be drawn from each

AC outlet. DO NOT exceed the MAXIMUM LOAD of 15 amps that can be

drawn from all the outlets combined.

(IBAR12/20ULTRA, IBAR12-20T, RS-1215-20): DO NOT exceed the MAXIMUM

LOAD of 15 amps that can be drawn from each AC outlet located on the

front of the IBAR12/20ULTRA and IBAR12-20T. DO NOT exceed the

MAXIMUM LOAD of 20 amps that can be drawn from each AC outlet on the

RS-1215-20, or each AC outlet located on the rear of the IBAR12/20ULTRA

and IBAR12-20T. DO NOT exceed the MAXIMUM LOAD of 20 amps that can

be drawn from all the outlets combined.

Use of this equipment in life support applications where failure of this

equipment can reasonably be expected to cause the failure of the life

support equipment or to significantly affect its safety or effectiveness is

not recommended. Do not use this equipment in the presence of a

flammable anesthetic mixture with air, oxygen or nitrous oxide.

Important Safety Instructions

IMPORTANT SAFETY INSTRUCTIONS. This manual contains information concerning the proper

installation and use of Eaton Tripp Lite series Rack-Mount Power Strips and Isobar Surge

Protectors. SAVE THESE INSTRUCTIONS.

The Surge Protector features an internal protection that will disconnect the surge-

protective component at the end of its useful life but will maintain power to the

load—now unprotected.

Installation

Rackmount Installation

To Mount Unit in Rack: Put four user-

supplied rack-mount screws a through the

unit’s mounting ears b and into the rack

rails as shown. The user must determine the

fitness of the rack-mount screws to hold the

unit in the rack before installation.

Wallmount/Under

Counter Installation

Detach Mounting Ears: Unscrew the

screws a holding the unit’s mounting

ears b to the sides of the unit.

Reorient Mounting Ears: Use the

screws from Step 1 a to reattach the

mounting ears b to the unit as shown.

Use only the manufacturer-supplied

screws or their equivalent (#6-32, ¼" flat

head) to reattach the mounting ears. The

screws should be put through diagonally

opposite holes on the ear.

Mount Unit on Surface: Put four user-

supplied screws c or similar mounting

hardware through the unit’s mounting

ears b and into the mounting surface

as shown. The user must determine the

fitness of the user-supplied mounting

hardware to support the unit before

mounting.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	grenuttak
Modell:	RS1215-RA
Vekt:	2090 g
Bredde:	444.5 mm
Dybde:	114 mm
Høyde:	44.45 mm
Materiale:	Metall
Kabelfarge:	Sort
AC-inngangsfrekvens:	50 - 60 Hz
Kabellengde:	4.572 m
Produktfarge:	Sort
Montering:	1U
Av/på-bryter:	Ja
Rack-montering:	Ja
Antall medfølgende produkter:	1 stykker
Antall AC outlets:	12 AC-utganger
AC-utgangstyper:	NEMA 5–15R
Strømuttak:	NEMA 5–15P
Nominell innputspenning:	120 V
Strømstøt energivurdering:	- J
Nominell strømoutput:	15 A
