Side 1/32

Table of Contents

1. Important Safety Instructions 2

2. Overview 2

3. Feature Identification 3

4. Enclosure Installation 4

4.1 Preparation 4

4.2 Unpacking 4

4.3 Ground Connection 5

5. Enclosure Configuration 5

5.1 Door Locks 5

5.2 Cable Access and Management 5

5.3 Mounting Rails 6

5.4 Adjusting Mounting Rail Depth 6

6. Wall Mounting the Enclosure 7

7. Equipment Installation 9

8. Specifications 9

8.1 Unit Dimensions 9

8.2 Package Dimensions 9

9. Storage and Service 10

10. Warranty and Product Registration 10

Español 11

Francais 21

SmartRack

NEMA 4

Wall-Mount Static Cabinet

General-Use Industrial Control

Models: SRN4G6U, SRN4G6UDP, SRN4G12U

(Series Number: AG-0605)

Owner’s Manual

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

is a registered trademark of Tripp Lite.

• The enclosure is extremely heavy. Use caution when handling the enclosure. Do not attempt to unpack, move or install it

unassisted. Use a mechanical device such as a forklift or pallet jack to move the enclosure in the shipping container.

• Do not place any object on the enclosure, especially containers of liquid, and do not attempt to stack the enclosures.

• Inspect the shipping container and the enclosure for shipping damage. Do not use the enclosure if it is damaged.

• Leave the enclosure in the shipping container until it has been moved as close to the ﬁnal installation location as possible.

• Install the enclosure in a structurally sound area capable of handling the load, or on a level ﬂoor that is able to bear the

weight of the enclosure, all equipment that will be installed in the enclosure and any other enclosures and/or equipment that

will be installed nearby.

• This enclosure supports a maximum Conduit Trade Size 2 with a 2.5 inch hole.

• Use only NEMA 4 (or higher) rated conduit/ﬁttings to maintain the enclosure’s environmental protection rating.

• For permanent wall mounting, be sure to securely fasten the enclosure to the building structure before operation.

• Use caution when cutting packing materials. The enclosure could be scratched, causing damage not covered by the

warranty.

• Save all packing materials for later use. Repacking and shipping the enclosure without the original packing materials may

cause product damage that will void the warranty.

• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the

failure of the life support equipment or to signiﬁcantly affect its safety or effectiveness is not recommended. Do not use this

equipment in the presence of a ﬂammable anesthetic mixture with air, oxygen or nitrous oxide.

Wall-mounted NEMA 4 enclosures accommodate all standard 19-inch rack-mount equipment, regardless of vendor, and ship

fully assembled for quick and easy deployment. They have a NEMA 4 rating for protection against falling dirt, rain, sleet, snow,

windblown dust, splashing water, hose-directed water and external formation of ice. They feature adaptable cabinets in

various heights.

The wall-mounted NEMA 4 enclosures have variable mounting depths, ideal for servers. The cabinets include a lockable,

removable front door.

1. Important Safety Instructions

2. Overview

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that must be followed during the installation and operation of

the product described in this manual. Failure to comply may invalidate the warranty and cause property damage

or personal injury.

Model SRN4G12U is shown. The other models have similar features, with the only differences being rack height and depth.

Front Door

Horizontal Rails

Vertical Mounting Rails

Removable Cable Access Hole Covers

3. Feature Identification

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Server
Modell:	SRN4G12U
Vekt:	43670 g
Bredde:	609.6 mm
Dybde:	639.1 mm
Høyde:	611.6 mm
Opprinnelsesland:	China
Pakkevekt:	68040 g
Materiale:	Stål
Pakkedybde:	762 mm
Pakkehøyde:	762 mm
Pakkebredde:	711.2 mm
Bærekraftsertifikater:	REACH, RoHS
Bærekraftsamsvar:	Ja
Produkter per masterkasse (ytterkasse):	1 stykker
Installasjonsalternativer:	Vegg-montert
NEMA-rangering:	4
