Side 1/25

Owner’s Manual

Industrial-Grade USB to

RS-422/485 Serial Adapter

Models: U208-001-IND (1-Port), U208-002-IND (2-Port),

U208-004-IND (4-Port)

Español 8 • Français 14 • Русский 20

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

17-10-300-93375A.indb 1 11/10/2017 9:59:35 AM

Important Safety Instructions

Product Features

System Requirements

• Always read the safety instructions carefully

• Keep this Owner’s Manual for future reference

• If any of the following situations arise, schedule an appointment to have your

equipment inspected by a service technician:

o The equipment has been exposed to moisture

o The equipment has been dropped and damaged

o The equipment shows obvious signs of breakage

o The equipment is not functioning properly or is not functioning according to the

Owner’s Manual instructions

• Add up to four RS-422 or RS-485 serial devices via the USB port on your desktop or

notebook computer

• Integrated FTDI chipset with COM retention automatically reassigns COM values to

ports in the event of a disconnection or reboot

• Rugged all-metal enclosure designed for industrial applications

• DIP switch controls provide easy port conﬁguration with minimal software requirements

• Features auto-detect and auto-switching of RS-422 and RS-485 devices

• RS-485 mode supports Auto Transceiver Turn Around (ATTA)

• Supports USB 2.0 speciﬁcations and earlier

• Supports serial communications speeds up to 1 Mbps

• Transmission Echo for RS-485 collision detection

• Wall-mount option provides a secure installation

• ESD protection to +/- 15 kV

• LED for indicate TxD or RxD activity

• USB-powered—no external power adapter required

• Computer with an available USB port

• Windows™ XP or later

• Mac

OS X 10.4 or later

• Linux 2.6.31 or later

17-10-300-93375A.indb 2 11/10/2017 9:59:35 AM

Package Includes

DIP Switch Settings

• Industrial-Grade USB to Serial Adapter

• USB A to B Cable (M/M), 3 ft. (1 m)

• Jumper Connectors (2 per port)

• Driver CD

• Owner’s Manual

The U280-00X-IND USB to Serial Adapter features an independent DIP switch for each

serial port. See below for DIP switch settings:

Auto RS-422/485 Detection (Default): Automatically detects the RS-422 or

RS-485 mode and sets the port accordingly.

RS-422 (4-Wire) or RS-485 (4-Wire): Sets the port speciﬁcally for use in 4-Wire

mode.

17-10-300-93375A.indb 3 11/10/2017 9:59:35 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	interface hub
Modell:	U208-004-IND
Vekt:	280 g
Bredde:	172 mm
Dybde:	59.9 mm
Høyde:	23.1 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	DC
Opprinnelsesland:	Malaysia
Pakkevekt:	500 g
Sertifisering:	CE, FCC, RoHS, REACH
Antall per pakke:	1 stykker
Inngangsspenning:	100 - 240 V
Utgangsstrøm:	5 V
Vertsgrensesnitt:	USB 2.0 Type-B
AC-inngangsfrekvens:	50 - 60 Hz
Antall porter:	4
Produktfarge:	Sort
Pakkedybde:	226.1 mm
Pakkehøyde:	55.9 mm
Pakkebredde:	149.9 mm
Kabler inkludert:	USB
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 55 °C
Harmonisert system (HS)-kode:	8471.80.1000
Kroppsmateriale:	Stål
DC-inngangskontakt:	Ja
Støttede Windows operativsystemer:	Ja
Relativ luftfuktighet under drift (H-H):	5 - 90
Drivere medfølger:	Ja
AC-adapter bunt:	Ja
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Grensesnitt (hub):	Seriell
Overføringshastighet (Mbps):	480 Mbit/s
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332205985
Masterkassens (ytterkassens) bruttovekt:	5400 g
Masterkassens (ytterkassens) lengde:	581.7 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	241.3 mm
Masterkassens (ytterkassens) høyde:	172.7 mm
Innput-strøm:	0.6 A
