Side 1/20

Owner’s Manual

Keyspan 4-Port RS232

Serial to USB Adapter Hub

Model: USA-49WG v2

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $50 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

trademarks are the sole property of their respective owners.

14-07-250-93339A.indd 1 8/6/2014 10:11:48 AM

Package Contents

System Requirements

Features

• USA-49WG v2

• USB A/B Device Cable – 6 ft.

• Driver CD

• Owner’s Manual

Optional Accessories

• U022-Series USB 2.0 A/B Device Cables

• UR022-Series Reversible USB 2.0 A/B Device Cables

• P520-006 RS232 Serial Straight-through Extension Cable – 6 ft.

• An available USB port

• A PC running Windows

XP or later

• A Mac computer running OS X

10.6.8 or later

• Add up to four RS232 serial ports via a single USB port on your

computer

• Supports data transfer rates up to 460Kbps

• LEDs show adapter status and data activity

• RS232 serial ports appear as standard COM ports; COM port numbers

are assigned based on what is available (e.g. If COM ports 1 and 2 are

occupied on your computer, the ﬁrst COM port to be assigned will be 3).

• Bus Powered: No external power adapter required

• Analytic Tools: Includes Windows line monitor and data trace software

• Easy Expansion: Supports use of multiple adapters on one PC

14-07-250-93339A.indd 2 8/6/2014 10:11:48 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	interface hub
Modell:	USA-49WG
Vekt:	160 g
Bredde:	152.4 mm
Dybde:	76.2 mm
Høyde:	45.7 mm
Tilkobling:	USB A, DB9
Opprinnelsesland:	Taiwan
Pakkevekt:	360 g
Antall USB 2.0-porter:	1
Vertsgrensesnitt:	USB
Utgangsgrensesnitt:	Seriell
Produktfarge:	Sort
Pakkedybde:	198.1 mm
Pakkehøyde:	61 mm
Pakkebredde:	160 mm
Kabler inkludert:	USB
Seriell grensesnittype:	RS-232
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	8536.69.8000
Støttede Windows operativsystemer:	Ja
Kommunikasjonsserieporter:	4
Drivere medfølger:	Ja
Intern:	Nei
Støttede Mac operativsystemer:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332144314
Masterkassens (ytterkassens) bruttovekt:	7300 g
Masterkassens (ytterkassens) lengde:	652.8 mm
Produkter per masterkasse (ytterkasse):	20 stykker
Masterkassens (ytterkassens) bredde:	337.8 mm
Masterkassens (ytterkassens) høyde:	236.2 mm
Baud-hastighet:	460 Kbit/s
