Side 1/20

Ethernet Adapter

with 3-Port Hub

Models:

U460-003-3A1G

U460-003-3A1GB

USB 3.2 Gigabit

Español 5

Français 9

Deutsch 13

Italiano 17

Product Features

Package Contents

Optional Accessories

• Combines a USB 3.2 Gigabit Ethernet adapter with 3-port

hub

• Supports data transfer rates up to 5 Gbps

• Backward compatible with previous USB generations

• All 3 USB ports support USB Battery Charging (BC)

specification v1.2

• Gigabit Ethernet port supports true 10/100/1000 Mbps

network speeds

• IEEE 802.3az (Energy Efficient Ethernet) compliant

• Supports IPv4 and IPv6 pack Checksum Offload Engine

(COE) to reduce CPU loading

• Supports full-duplex and half-duplex operations

• Supports Wake-on-LAN, Jumbo Frames and VLAN tagging

• Plug and play—no software or drivers required

• U460-003-3A1G (White) or U460-003-3A1GB (Black)

• Quick Start Guide

• N201-Series Cat6 Gigabit Snagless Patch Cables

• U322-Series USB 3.0 SuperSpeed A/B Device Cables

• U326-Series USB 3.0 SuperSpeed A/Micro-B Device

Cables

Installation

Warranty

1. Connect the USB Type-C™ (USB-C™) plug to the USB-C

port on your tablet, Ultrabook or computer. Upon

connection, the white LED on the unit will illuminate to

indicate the unit is connected and receiving power.

2. Connect the RJ45 port to a network using a UTP cable

(such as N201-Series Cat6 cables).

3. Connect USB devices to the available ports using USB

cables.

USB Type-C™ and USB-C™ are trademarks of USB

Implementers Forum.

3-Year Limited Warranty

We warrant our products to be free from defects in materials and workmanship for a

period of three (3) years from the date of initial purchase. Our obligation under this

warranty is limited to repairing or replacing (at its sole option) any such defective products.

Visit Tripplite.Eaton.com/support/product-returns before sending any equipment back for

repair. This warranty does not apply to equipment which has been damaged by accident,

negligence or misapplication or has been altered or modied in any way.

EXCEPT AS PROVIDED HEREIN, WE MAKE NO WARRANTIES, EXPRESS OR IMPLIED,

INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE. Some states do not permit limitation or exclusion of implied warranties;

therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL WE BE LIABLE FOR DIRECT, INDIRECT,

SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS

PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specically, we are

not liable for any costs, such as lost prots or revenue, loss of equipment, loss of use

of equipment, loss of software, loss of data, costs of substitutes, claims by third parties,

or otherwise.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	interface hub
Modell:	U460-003-3A1GB
Vekt:	40 g
Bredde:	96 mm
Dybde:	30 mm
Høyde:	21 mm
LED-indikatorer:	Kraft indikator
Strømkildetype:	USB
Opprinnelsesland:	China
Pakkevekt:	80 g
Sertifisering:	CE, FCC, RoHS, REACH
Inngangsspenning:	5 V
Nettverksstandard:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Vertsgrensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Auto MDI/MDI-X:	Ja
Antall porter:	4
Produktfarge:	Sort
Pakkedybde:	74.9 mm
Pakkehøyde:	26.9 mm
Pakkebredde:	145 mm
Strømforbruk (vanlig bruk):	0.95 W
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 70 °C
Harmonisert system (HS)-kode:	84719000
Kroppsmateriale:	Akrylonitril-butadien-styren (ABS)
Ethernet-grensesnittype:	Gigabit Ethernet
Relativ luftfuktighet under drift (H-H):	10 - 90
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	3
Plugg inn og spill:	Ja
Guide for hurtiginstallering:	Ja
Grensesnitt (hub):	RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A
Overføringshastighet (Mbps):	5000 Mbit/s
Full tosidig:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332209594
Masterkassens (ytterkassens) bruttovekt:	900 g
Masterkassens (ytterkassens) lengde:	165.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	299 mm
Masterkassens (ytterkassens) høyde:	95 mm
Innput-strøm:	1.5 A
