Side 1/8

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Dual-Bay USB 3.0

to SATA Hard Drive

RAID Enclosure

Model: U357-002

Package Contents 2

Features 2

System Requirements 2

RAID Mode 3

Setting the RAID Mode 4

Installation Instructions 5

Warranty and Product Registration 6

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

15-07-309-9334C4-EN.indd 1 8/3/2015 11:41:14 AM

Package Contents:

Features:

System Requirements:

• U357-002

• USB 3.0 A/B Device Cable

• External Power Supply with Removable Power Cord

• Screws for Mounting 2.5” Hard Drives

• Owner’s Manual

• Dual-bay enclosure allows you to quickly turn any two 2.5” or 3.5” internal SATA

hard drives into external hard drives.

• Tested with up to 8 TB 3.5” HDD per bay (16 TB total) and up to 2 TB 2.5” HDD per

bay (4 TB total).

• Features RAID 0, RAID 1, JBOD and Normal disk modes, giving you the ﬂexibility to

access your data in whatever way works best for you.

• Supports USB 3.0 data transfer rates up to 5 Gbps. Backwards compatible with

USB 2.0 and 1.1.

• Compatible with SATA I, II and III hard drives.

• Built-in cooling fan keeps drives from overheating during prolonged use.

• Plug and play; no software or drivers required.

• (x2) 2.5” or 3.5” SATA hard drive

• Computer with an available USB port. A USB 3.0 port is required to achieve

maximum speeds.

• Compatible with Windows

, Mac and Linux

15-07-309-9334C4-EN.indd 2 8/3/2015 11:41:14 AM

RAID Mode

The enclosure can be set to function in one of four modes; Normal, JBOD, RAID 0

and , giving you the ﬂexibility to access your data in whatever way works best RAID 1

for you. The available modes are described below with their corresponding dip switch

setting displayed on the left side of the image.

Normal Mode – This mode treats both hard drives as separate disks, allowing them to

be accessed independently of each other. Your computer will recognize them as if they

were ﬂash drives being plugged into separate USB ports, not changing them in any

way.

1 2

2 Disk Volume

SATA1 100 0G SATA2 750G SATA1 100 0G SATA2 750G

2 Disk Volume

1 2

2 Disk Volume

SATA1 100 0G SATA2 750G 10 00G+750G=1750G

1 Disk Volume

1 2

2 Disk Volume

SATA1 100 0G SATA2 750G 750Gx2=1500G

1 Disk Volume

JBOD Mode – This mode combines the two hard drives into one large drive for the

purpose of increased storage space. Data is stored on one drive at a time, so when

the ﬁrst one is full, the next one begins to be used. The computer’s operating system

will recognize them as a single drive.

RAID 0 Mode – This mode combines the two hard drives into one large drive for the

dual purpose of increased storage space and performance. In this mode, data is split

amongst the two drives simultaneously, improving the read/write performance. The risk

in using this mode is that failure of one disk will result in total data loss. When using

this mode, it is recommended that you use hard drives with the same capacities. If

hard drives of different capacities are used, the smaller hard drive will be doubled in

size with the remaining space on the larger hard drive going unused.

15-07-309-9334C4-EN.indd 3 8/3/2015 11:41:15 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	HDD/SSD eske
Modell:	U357-002
Vekt:	1590 g
Bredde:	134.6 mm
Dybde:	226.1 mm
Høyde:	121.9 mm
Opprinnelsesland:	China
Pakkevekt:	2250 g
Kompatible operativsystemer:	Windows, MAC, Linux
Maksimal lagringskapasitet:	8 TB
Hot-swap:	Ja
Dataoverføringshastighet:	5 Gbit/s
Produktfarge:	Sort
Pakkedybde:	195.1 mm
Pakkehøyde:	190 mm
Pakkebredde:	273 mm
Kabler inkludert:	USB
Ekstern strømadapter:	Ja
RAID-nivåer:	0, 1,JBOD
Støttede lagringsgrensesnitt:	Serial ATA, Serial ATA II, Serial ATA III
Antall lagringsdrivere som støttes:	2
Plugg inn og spill:	Ja
Antall vifter:	1 vifter
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332181616
Masterkassens (ytterkassens) bruttovekt:	14500 g
Masterkassens (ytterkassens) lengde:	410 mm
Produkter per masterkasse (ytterkasse):	6 stykker
Masterkassens (ytterkassens) bredde:	599.9 mm
Masterkassens (ytterkassens) høyde:	300 mm
USB 3.2 Gen 1 (3.1 Gen 1) antall porter:	1
Lagringsstasjonens størrelse:	2.5/3.5 "
