Tripp Lite U457-1M2-NVMEG2 Bruksanvisning

Tripp Lite HDD/SSD eske U457-1M2-NVMEG2

Les nedenfor 📖 manual på norsk for Tripp Lite U457-1M2-NVMEG2 (32 sider) i kategorien HDD/SSD eske. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/32

Owner’s Manual

USB 3.1 Gen 2 (10 Gbps)

Type-C to NVMe PCIe M.2

SSD M-Key Enclosure

Model: U457-1M2-NVMEG2

1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

WARRANTY REGISTRATION

win an ISOBAR surge protector in our monthly drawing!

tripplite.com/warranty

Español 9 • Français 17 • Русский 25

Product Features

• Read, write or transfer ﬁles to and from your

computer by adding the speed of an M.2 NVMe SSD

• Supports M.2 drive sizes of 2230, 2242, 2260, 2280

• Supports USB 3.1 Gen 2 data transfer rates up to

10 Gbps and is backwards compatible with USB

3.0, 2.0 and 1.1.

• UASP compatible for up to 70% faster read and

40% faster write performance

• Slim aluminum enclosure is durable and perfect

for travel

• Plug-and-play design—no software, drivers or

external power required

Package Includes

• U457-1M2-NVMEG2 USB-C to M.2 Enclosure

• USB 3.1 Gen 2 Type-C Cable, 2 ft. (0.6 m)

• Mini Screwdriver

• Mounting Hardware

• Owner’s Manual

Optional Accessories

• U420-003-G2 USB 3.1 Gen 2 Type-C (10 Gbps) to

Type-C Cable, 3 ft. (0.9 m)

• U428-003-G2 USB 3.1 Gen 2 Type-C (10 Gbps) to

USB-A Cable, 3 ft. (0.9 m)

Notes:

•

HDD/SSD drives are sensitive to static electricity and must

be handled properly to prevent the risk of data loss. Always

handle your HDD/SSD drive with caution by wearing an anti-

static strap (such as Tripp Lite’s P999-000) when transporting

it or by touching a grounded metal surface to discharge

yourself of static electricity prior to picking up the drive.

• When disconnecting the drive, make sure to go through

the proper disconnection steps of your operating system.

Removing the drive with proper disconnection can result in

data loss or corruption.

Using the included mini-screwdriver, remove the two

screws located on either side of the USB-C port.

2. Remove the USB-C cover plate and slide out the

PCBA board.

3. Place your SSD next to the M.2 NVMe M-Key

connector, matching up the mounting holes.

Position the included nut underneath the mounting

hole that matches the length of your SSD.

Standard Installation

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	HDD/SSD eske
Modell:	U457-1M2-NVMEG2
Produkttype:	SSD-kabinett
Vekt:	70 g
LED-indikatorer:	Ja
Bruksanvisning:	Ja
USB-kontakttype:	USB Type-C
Strømkildetype:	USB
Opprinnelsesland:	China
Pakkevekt:	70 g
Sertifisering:	CE, FCC, REACH
USB-versjon:	Thunderbolt 3
Materiale:	Metall
USB-tilkobling:	Ja
UASP-støtte:	Ja
Dataoverføringshastighet:	20 Gbit/s
Produktfarge:	Sort
Antall USB-porter:	1
Pakkedybde:	130 mm
Pakkehøyde:	35.1 mm
Pakkebredde:	145 mm
Kabler inkludert:	USB Type-C
Pakketype:	Boks
Driftstemperatur (T-T):	10 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	0 - 65 °C
Lagringsrelativ fuktighet:	10 - 80
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	84733080
Skruer inkludert:	Ja
Støttede lagringsgrensesnitt:	M.2
Antall lagringsdrivere som støttes:	1
Relativ luftfuktighet under drift (H-H):	10 - 80
Plugg inn og spill:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332247916
Masterkassens (ytterkassens) bruttovekt:	1930 g
Masterkassens (ytterkassens) lengde:	199.9 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	275.1 mm
Masterkassens (ytterkassens) høyde:	165.1 mm
Kjønn på USB-kontakt:	Hunkjønn
Installert lagringsdrivertype:	Nei
Lagringsstasjonens størrelse:	M.2 "
Skrutrekker inkludert:	Ja
