Les nedenfor 📖 manual på norsk for Tripp Lite U457-025-G1-WPG (16 sider) i kategorien HDD/SSD eske. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/16

Quick Start Guide
USB-C 3.1 SATA SSD/HDD
Water-Resistant Enclosure with
Built-In Cable for 2.5-Inch Drives
Models: U457-025-G1-WPG (USB 3.1 Gen 1, 5 Gbps),
U457-025-G2-WPB (USB 3.1 Gen 2, 10 Gbps)
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
tripplite.com/warranty
Español 5 • Français 9 • Русский 13

2
Product Features
Package Contents
System Requirements
• U457-025-G1-WPG (SuperSpeed USB 3.1 Gen 1, 5 Gbps) or
U457-025-G2-WPB (SuperSpeed USB 3.1 Gen 2, 10 Gbps)
• Mini Screwdriver
• Screws (x10)
• Washers (x10)
• Quick Start Guide
• USB 3.1 Gen 1 (5 Gbps) port required to achieve maximum speeds for
U457-025-G1-WPG
• USB 3.1 Gen 2 (10 Gbps) port required to achieve maximum speeds
for U457-025-G2-WPB
• UASP-enabled host controller required to achieve UASP performance
• 2.5 in. SATA HDD or SSD with maximum height of 9.5 mm
• Converts any 2.5 in. internal SATA SSD (solid state drive) or HDD
(hard disk drive) into an external hard drive for storing data
• Designed for 2.5 in. SATA drive heights between 7 mm and 9.5 mm
• Supports SATA III (6 Gbps), II (3 Gbps) and I (1.5 Gbps) drives
• Backward compatible with USB 3.0, 2.0 and 1.1 devices
• Water-resistant and dust-tight to comply with IP66 standards
• UASP-compatible for enhanced performance
• Bus-powered plug-and-play operation with no software or external
power required

3
Installation
1
Remove the back cover (side with the screw holes) of the SSD/HDD
enclosure.
2
Connect your 2.5 in. SATA SSD/HDD to the SATA connector.
3
Once the SATA SSD/HDD is securely in place, replace the back cover,
ensuring the screw holes line up with one another.
4
Using the included screwdriver, screws and washers, fasten the 10
screws and washers securely to the enclosure.
In order to comply with IP66 standards, screws need to be properly Note:
tightened to the enclosure.
5
Connect the built-in USB 3.1 Type-C cable to an available USB port on
your computer.
Drive Connection 22-Pin SATA Data + Power
USB Connection USB Type-C (Male)
Maximum Data Transfer Rate 10 Gbps (U457-025-G2-WPB)
5 Gbps (U457-025-G1-WPG)
SSD/HDD Supported 2.5 in. SATA I/II/III HDD/SSD
Operating Temperature 50° to 122°F (10° to 50°C)
Relative Humidity 10% to 80% RH, Non-Condensing
Dimensions 0.94 x 3.7 x 5.8 in. (24 x 94 x 148 mm)
Specifications
Produkspesifikasjoner
Merke: | Tripp Lite |
Kategori: | HDD/SSD eske |
Modell: | U457-025-G1-WPG |
Produkttype: | HDD/SSD-kabinett |
Vekt: | 230 g |
USB-kontakttype: | USB Type-C |
Strømkildetype: | USB |
Opprinnelsesland: | China |
Pakkevekt: | 230 g |
Sertifisering: | CE, FCC, REACH |
USB-versjon: | 3.2 Gen 1 (3.1 Gen 1) |
Materiale: | Akrylonitril-butadien-styren (ABS) |
USB-tilkobling: | Ja |
Maksimal lagringskapasitet: | 2 TB |
Støttede lagringsstasjonshøyder: | 9.5 mm |
UASP-støtte: | Ja |
Dataoverføringshastighet: | 5 Gbit/s |
Kabellengde: | 0.185 m |
Produktfarge: | Grå |
Pakkedybde: | 140 mm |
Pakkehøyde: | 34.8 mm |
Pakkebredde: | 180.1 mm |
Pakketype: | Boks |
Driftstemperatur (T-T): | 10 - 50 °C |
Oppbevaringstemperaturomåde (Celsius): | 0 - 65 °C |
Lagringsrelativ fuktighet: | 10 - 80 |
Bærekraftsertifikater: | RoHS |
Skruer inkludert: | Ja |
Støttede lagringsgrensesnitt: | Serial ATA, Serial ATA II, Serial ATA III |
Antall lagringsdrivere som støttes: | 1 |
Relativ luftfuktighet under drift (H-H): | 10 - 80 |
Plugg inn og spill: | Ja |
Masterkassens (ytterkassens) GTIN (EAN/UPC): | 10037332250145 |
Masterkassens (ytterkassens) bruttovekt: | 2490 g |
Masterkassens (ytterkassens) lengde: | 192 mm |
Produkter per masterkasse (ytterkasse): | 10 stykker |
Masterkassens (ytterkassens) bredde: | 367 mm |
Masterkassens (ytterkassens) høyde: | 146 mm |
Kjønn på USB-kontakt: | Hankjønn |
Lagringsstasjonens størrelse: | 2.5 " |
Skrutrekker inkludert: | Ja |
