Side 1/16

Owner’s Manual

USB 3.1 Gen 1 USB-C™

Portable Aluminum Hub

with USB-A Hub and

Memory Card Reader

Model: U460-002-2AM-C1

USB Type-C and USB-C are trademarks of USB Implementers Forum

1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

property of their respective owners.

WARRANTY REGISTRATION

win an ISOBAR surge protector in our monthly drawing!

tripplite.com/warranty

Español 5 • Français 9 • Русский 13

19-07-519-93-3A62.indb 1 10/18/2019 1:54:14 PM

Package Includes

• U460-002-2AM-C1

• Owner’s Manual

Product Features

• Portable design with built-in cable is perfect for

travel and stores easily in a laptop bag

• USB-A and USB-C ports support data transfer rates

up to 5 Gbps and are compatible with previous USB

generations

• MicroSD and SD/MMC memory card slots allow

external memory access via the USB-C port with

speeds up to 480 Mbps

• Plug-and-play – No software or drivers required

Optional Accessories

• U322-Series USB 3.0 A/B Device Cables

• U326-Series USB 3.0 Micro-B Device Cables

• U420-003 USB 3.1 Gen 1 USB-C M/M

Cable – 3 ft.

19-07-519-93-3A62.indb 2 10/18/2019 1:54:14 PM

1. Connect the unit’s USB Type-C connector to the

USB-C port on your laptop, tablet or personal

electronic device.

2. Connect up to three devices to the unit’s USB-A

and USB-C ports.

3. Insert a Micro SD or SD/MMC card into the

corresponding memory card slot to access external

memory.

Note: Both memory card slots can be used at the same time.

Installation

Input Connectors

USB USB-C (Male)

Output Connectors

USB USB-A (Female) p3-x2

USB-C (Female) x1

Memory Card Slots MicroSD p3-x1 and SD/MMC x1

Environmental

Operating Temperature 32 to 104°F (0 to 40°C)

Storage Temperature 14 to 140°F (-10 to 60°C)

Relative Humidity 0% ~ 90% RH, Non-Condensing

Speciﬁcations

19-07-519-93-3A62.indb 3 10/18/2019 1:54:14 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	interface hub
Modell:	U460-002-2AM-C1
Vekt:	70 g
Bredde:	33.3 mm
Dybde:	113.5 mm
Høyde:	13.5 mm
Bruksanvisning:	Ja
Minimum driftstemperatur:	0 °C
Opprinnelsesland:	China
Pakkevekt:	100 g
Sertifisering:	RoHS, REACH, FCC, CE
Vertsgrensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Antall porter:	3
Kabelhylsemateriale:	Polyvinylklorid (PVC)
Kortleser:	2
Kabellengde:	0.15 m
Produktfarge:	Sølv
Type strømforsyning:	USB
Pakkedybde:	80 mm
Pakkehøyde:	20.1 mm
Pakkebredde:	150.1 mm
Minnekortenhet:	MicroSD (TransFlash), SD
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 60 °C
Lagringsrelativ fuktighet:	0 - 90
Innebygd kortleser:	Ja
Harmonisert system (HS)-kode:	8517.62.0090
Kroppsmateriale:	Aluminium
Relativ luftfuktighet under drift (H-H):	0 - 90
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
Plugg inn og spill:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1) Type-C-porter:	1
Grensesnitt (hub):	USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Overføringshastighet (Mbps):	5000 Mbit/s
Maksimal opereringstemperatur:	40 °C
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332218350
Masterkassens (ytterkassens) bruttovekt:	1200 g
Masterkassens (ytterkassens) lengde:	165.1 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	231.1 mm
Masterkassens (ytterkassens) høyde:	100.1 mm
