Tripp Lite UPB-02K6-1U Bruksanvisning

Tripp Lite batteribank UPB-02K6-1U

Les nedenfor 📖 manual på norsk for Tripp Lite UPB-02K6-1U (8 sider) i kategorien batteribank. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/8

Owner’s Manual

2600mAh

Mobile Power Bank

Model: UPB-02K6-1U

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $50 value!

www.tripplite.com/warranty

15-06-038-933468-EN.indd 1 6/16/2015 11:09:45 AM

Product Features

Package Includes

System Requirements

Optional Accessories

• Charge your phone, tablet or other mobile device without the need for a

power outlet

• Pocket-size design is perfect for portable use

• USB port provides up to 5V, 1A of power for charging your mobile devices

• 2600mAh capacity charges devices at maximum power draw for hours

• Battery-power LED indicator shows when the battery is full or getting low*

• Features short circuit, over-voltage, over-current, over-charge and over-

discharge protection for safe and reliable charging

*The Mobile Power Bank contains openings for LEDs on the top left of the housing

and right side of the USB-A port, but only one is currently being used. The unit’s LED

indicator is located on the top right side of the USB-A port.

• UPB-02K6-1U

• USB Micro-B Cable, 3 ft.

• Owner’s Manual

• A smartphone, tablet or other mobile USB device

• U030-Series USB 2.0 A to 5-Pin Mini-B Cables

• U038-Series USB 2.0 A to USB Type-C Cables

• UR05C-Series Micro-B Charge-Only Cables

• M100-Series USB 2.0 A to Lightning™ Cables

15-06-038-933468-EN.indd 2 6/16/2015 11:09:45 AM

USB Device Charging

Note:

• When the Mobile Power Bank’s battery is less than 5% during a device charge, the

LED indicator light will turn off.

• When the Mobile Power Bank’s battery is between 5% and 100% during a device

charge, the LED indicator light will blink.

1. Connect your mobile device to the USB-A port on the Mobile Power

Bank using the included USB Micro-B cable or a USB cable suitable for

your device.

2. The device will begin charging with the LED indicator light illuminating,

as listed above.

Mobile Power Bank Charging

Note:

• When charging the Mobile Power Bank, the LED indicator light will blink when the

battery is between 0 and 99%.

• When the Mobile Power Bank is charged to 100%, the LED indicator light will

illuminate solid.

1. Using the included USB Micro-B cable, connect the Micro-B port located

on the Mobile Power Bank to the USB-A port on a computer or USB

Charger.

2. The Mobile Power Bank will begin charging with the LED indicator light

illuminating, as listed above.

15-06-038-933468-EN.indd 3 6/16/2015 11:09:45 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	batteribank
Modell:	UPB-02K6-1U
Vekt:	68 g
Bredde:	30.48 mm
Dybde:	88.9 mm
Høyde:	20.32 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Batterikapasitet:	2600 mAh
Opprinnelsesland:	China
Pakkevekt:	190 g
Ladekilde:	USB
Utgangsstrøm:	5 V
Antall samtidig tilkoblede enheter (maks.):	1
Batteriteknologi:	Lithium-Ion (Li-Ion)
Produktfarge:	Sort
Pakkedybde:	149.9 mm
Pakkehøyde:	45.7 mm
Pakkebredde:	134.6 mm
Kabler inkludert:	Micro-USB
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 60 °C
Bærekraftsertifikater:	RoHS
Strømbeskyttelsesfunksjoner:	Over current, Over voltage, Overcharge, Overdischarge, Short circuit
Laderkompabilitet:	Universell
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332189360
Masterkassens (ytterkassens) bruttovekt:	2090 g
Masterkassens (ytterkassens) lengde:	287 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	248.9 mm
Masterkassens (ytterkassens) høyde:	172.7 mm
Inngangsgrensesnitt:	Micro-USB
USB A utgang:	1
Generell ladetid for enhet:	2.6 timer
