Tripp Lite batteribank UPB-20K0-2U1C

Les nedenfor 📖 manual på norsk for Tripp Lite UPB-20K0-2U1C (28 sider) i kategorien batteribank. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/28

Owner’s Manual

20,100mAh 3-Port

Mobile Power Bank,

USB-IF Certiﬁed

Model: UPB-20K0-2U1C

USB Type-C and USB-C are trademarks of USB Implementers Forum

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Español 8 • Français 15 • Русский 22

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

General Safety Instructions

• Make sure the power bank is fully charged prior to use.

• Use a cable suitable for your device when charging from the power bank.

• When charging the power bank, it is recommended you use the included

USB Type-C cable.

• Under condition of low battery, the LEDs will turn off while charging a

device. Recharge the power bank as soon as possible to avoid shortening

the battery life.

• The battery should be charged at least every three months to avoid

shortening the battery life.

• It is recommended to disconnect the charging device upon being fully

charged in order to avoid further battery use.

• When the power bank enters protection mode (LEDs turn off and power

bank will not charge) caused by issues such as a short circuit, use an

external charger to charge the power bank so it can resume normal

operation.

• Keep the power bank away from ﬁre and avoid temperatures above 113°F

(45°C) when in use and 140°F (60°C) when not in use.

• Do not expose the power bank to moisture or immerse it in water.

• Do not use a corrosive cleaner on the power bank.

• Do not squeeze or puncture the power bank. Doing so may may allow

electrolyte leakage of the lithium-ion battery.

• Do not attempt to disassemble, modify or ﬁx the power bank.

• Do not use a damaged cable or power charger to charge the power bank.

• Please recycle this device at an appointed disposal location for Lithium

Ion batteries.

Product Features

Package Includes

System Requirements

• Simultaneously charge up to 3 phones, tablets or other mobile devices

on-the-go, without the need for a power outlet

• USB-A and USB-C ports provide 57W maximum simultaneous charging

power

• Dual USB-A ports provide 5V 2.4A (12W) of total power per port*

• USB-A ports are BC 1.2 compliant, providing up to 1.5A of fast charging

power to Apple-compliant devices

• USB-C port supports PD Charging up to 5V 3A (15W), 9V 3A (27W),

12V 3A (36W), 15V 3A (45W) and 20V 2.25A (45W)

• 20,100mAh capacity lets you charge at maximum power draw for hours

• Includes short circuit, over-voltage, over-current, over-charge and over-

discharge protection for safe and reliable charging

• USB-IF certiﬁed

• Four battery power LED indicators show remaining battery capacity

• Automatic power off turns off LED indicators when not in use

• Sleek, portable design is perfect for on-the-go use

*When used simultaneously, the total power per port will be negotiated by device.

• UPB-20K0-2U1C

• USB-C to USB-C Cable (M/M), 3 ft. (0.9 m)

• Owner’s Manual

• Smartphone, tablet or other mobile USB device

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	batteribank
Modell:	UPB-20K0-2U1C
Vekt:	360 g
Bredde:	80 mm
Dybde:	162.4 mm
Høyde:	22 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Batterikapasitet:	20100 mAh
Opprinnelsesland:	China
Pakkevekt:	600 g
Sertifisering:	CE, FCC, REACH, USB-IF
Ladekilde:	USB
Antall samtidig tilkoblede enheter (maks.):	2
Batteriteknologi:	Lithium-Ion (Li-Ion)
Port 1 utgangsstrøm:	2.25 A
Port 2 utgangsstrøm:	2.4 A
Total utgangseffekt:	57 W
Produktfarge:	Sort
Pakkedybde:	118.1 mm
Pakkehøyde:	46 mm
Pakkebredde:	235 mm
Kabler inkludert:	USB Type-C
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Lagringsrelativ fuktighet:	5 - 45
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	85078000
Kroppsmateriale:	ABS
Strømbeskyttelsesfunksjoner:	Overstrøm
Relativ luftfuktighet under drift (H-H):	20 - 90
Laderkompabilitet:	Universell
Hurtiglading:	Nei
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332214215
Masterkassens (ytterkassens) bruttovekt:	3200 g
Masterkassens (ytterkassens) lengde:	249.9 mm
Produkter per masterkasse (ytterkasse):	5 stykker
Masterkassens (ytterkassens) bredde:	249.9 mm
Masterkassens (ytterkassens) høyde:	140 mm
Inngangsgrensesnitt:	USB Type-C
USB A utgang:	2
