Tripp Lite UPB-10K0-2U1C Bruksanvisning

Tripp Lite batteribank UPB-10K0-2U1C

Les nedenfor 📖 manual på norsk for Tripp Lite UPB-10K0-2U1C (32 sider) i kategorien batteribank. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/32

Owner’s Manual

10,050mAh 3-Port

Mobile Power Bank,

USB-IF Certiﬁed

Model: UPB-10K0-2U1C

USB Type-C and USB-C are trademarks of USB Implementers Forum

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

ISOBAR surge protector in our monthly drawing!

tripplite.com/warranty

Español 9 • Français 17 • Русский 25

General Safety Instructions

• Make sure the power bank is fully charged prior to use.

• Use a cable suitable for your device when charging from the

power bank.

• When charging the power bank, it is recommended you use the

included USB Type-C cable.

• Under condition of low battery, the LEDs will turn off while charging

a device. Recharge the power bank as soon as possible to avoid

shortening the battery life.

• The battery should be charged at least every three months to avoid

shortening the battery life.

• It is recommended to disconnect the charging device upon being

fully charged in order to avoid further battery use.

• When the power bank enters protection mode (LEDs turn off and

power bank will not charge) caused by issues such as a short

circuit, use an external charger to charge the power bank so it can

resume normal operation.

• Keep the power bank away from ﬁre and avoid temperatures above

113°F (45°C) when in use and 140°F (60°C) when not in use.

• Do not expose the power bank to moisture or immerse it in water.

• Do not use a corrosive cleaner on the power bank.

• Do not squeeze or puncture the power bank. Doing so may allow

electrolyte leakage of the lithium-ion battery.

• Do not attempt to disassemble, modify or ﬁx the power bank.

• Do not use a damaged cable or power charger to charge the

power bank.

• Please recycle this device at an appointed disposal location for

lithium ion batteries.

Product Features

Package Includes

• Simultaneously charge up to 3 phones, tablets or other mobile

devices without the need for a power outlet

• USB-A and USB-C ports provide 30W maximum simultaneous

charging power

• Dual USB-A ports provide 5V 2.4A (12W) of total power per port*

• USB-A ports are BC 1.2 compliant, providing up to 1.5A of fast

charging power to Apple-compliant devices

• USB-C port supports PD charging up to 5V 3A (15W),

9V 2A (18W) and 12V 1.5A (18W)

• 10,050mAh capacity lets you charge at maximum power draw

for hours

• Includes short circuit, overvoltage, overcurrent, overcharge and

overdischarge protection for safe and reliable charging

• USB-IF certiﬁed

• Four battery power LED indicators show remaining battery capacity

• Automatic power off turns off LED indicators when not in use

• Sleek, portable design is perfect for on-the-go use

*When used simultaneously, the total power per port will be negotiated by device.

• UPB-10K0-2U1C

• USB-C to USB-C Cable (M/M), 3 ft. (0.9 m)

• Owner’s Manual

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	batteribank
Modell:	UPB-10K0-2U1C
Vekt:	180 g
Bredde:	198 mm
Dybde:	25 mm
Høyde:	124 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Batterikapasitet:	10050 mAh
Opprinnelsesland:	China
Pakkevekt:	330 g
Sertifisering:	CE, FCC, REACH, USB-IF
Ladekilde:	USB
Antall samtidig tilkoblede enheter (maks.):	3
Batteriteknologi:	Lithium-Ion (Li-Ion)
Port 1 utgangsstrøm:	2.4 A
Port 2 utgangsstrøm:	2.4 A
Total utgangseffekt:	30 W
Kabellengde:	0.91 m
Produktfarge:	Sort
Pakkedybde:	118.1 mm
Pakkehøyde:	46 mm
Pakkebredde:	235 mm
Kabler inkludert:	USB Type-C
Pakketype:	Boks
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Lagringsrelativ fuktighet:	5 - 95
Bærekraftsertifikater:	RoHS
Kroppsmateriale:	Akrylonitril-butadien-styren (ABS)
Strømbeskyttelsesfunksjoner:	Overstrøm
Relativ luftfuktighet under drift (H-H):	20 - 90
Laderkompabilitet:	Universell
Hurtiglading:	Ja
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332214208
Masterkassens (ytterkassens) bruttovekt:	3700 g
Masterkassens (ytterkassens) lengde:	255 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	260.1 mm
Masterkassens (ytterkassens) høyde:	255 mm
USB Power Delivery:	Ja
Inngangsgrensesnitt:	USB Type-C
USB A utgang:	2
Port 3 utgangs-strøm:	3 A
