Owner’s Manual

12,000mAh Dual-Port

Mobile Power Bank

Model: UPB-12K0-2U

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $50 value!

www.tripplite.com/warranty

15-06-040-93346B-EN.indd 1 6/16/2015 11:13:00 AM

Product Features

Package Includes

System Requirements

Optional Accessories

• Charge multiple phones, tablets or other mobile devices without the need

for a power outlet

• Sleek, low-proﬁle design is perfect for portable use

• Dual USB ports provide up to 5V, 1A and 5V, 2A of power for

simultaneous charging of mobile devices

• 12,000mAh capacity charges devices at maximum power draw for hours

• Four battery-power LED indicators show remaining battery capacity

• Automatic power saving turns off LED indicators when not in use

• Includes a built-in LED ﬂashlight

• Features short circuit, over-voltage, over-current, over-charge and over-

discharge protection for safe and reliable charging

• UPB-12K0-2U

• USB Micro-B Cable, 3 ft.

• Owner’s Manual

• A smartphone, tablet or other mobile USB device

• U030-Series USB 2.0 A to 5-Pin Mini-B Cables

• U038-Series USB 2.0 A to USB Type-C Cables

• UR05C-Series Micro-B Charge-Only Cables

• M100-Series USB 2.0 A to Lightning™ Cables

15-06-040-93346B-EN.indd 2 6/16/2015 11:13:00 AM

USB Device Charging

Note:

• A button is located on the Mobile Power Bank next to the 5V, 2A USB-A port. When

the button is pressed once, the LED indicators will illuminate to show how much

battery capacity is left. When held down, the button turns off the LED indicators and

stops any device charging taking place. When pressed twice, the button turns the

built-in LED ﬂashlight on/off.

• When charging a USB device, the LED indicators on the Mobile Power Bank will

illuminate in one of four combinations to indicate the following battery capacity

levels:

• 75-100% Capacity – 4 LEDs illuminated solid

• 50-75% Capacity – 3 LEDs illuminated solid

• 25-50% Capacity – 2 LEDs illuminated solid

• 5-25% Capacity – 1 LED illuminated solid

• 0-5% Capacity – 0 LEDs illuminated

1. Connect your mobile devices to the USB-A ports on the Mobile Power

Bank using the included USB Micro-B cable or a USB cable suitable for

your device.

2. The device will begin charging with the LED indicator light(s) illuminating

according to the combinations listed above.

15-06-040-93346B-EN.indd 3 6/16/2015 11:13:00 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	batteribank
Modell:	UPB-12K0-2U
Vekt:	317.5 g
Bredde:	81.28 mm
Dybde:	142.24 mm
Høyde:	22.86 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Batterikapasitet:	12000 mAh
Opprinnelsesland:	China
Pakkevekt:	520 g
Ladekilde:	USB
Antall samtidig tilkoblede enheter (maks.):	2
Batteriteknologi:	Lithium-Ion (Li-Ion)
Produktfarge:	Sort
Pakkedybde:	236.2 mm
Pakkehøyde:	45.7 mm
Pakkebredde:	116.8 mm
Kabler inkludert:	Micro-USB
Driftstemperatur (T-T):	0 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 60 °C
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	85078000
Strømbeskyttelsesfunksjoner:	Over current, Over voltage, Overcharge, Overdischarge, Short circuit
Laderkompabilitet:	Universell
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332189391
Masterkassens (ytterkassens) bruttovekt:	4760 g
Masterkassens (ytterkassens) lengde:	254 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	256.5 mm
Masterkassens (ytterkassens) høyde:	259.1 mm
Innebygget lommelykt:	Ja
Inngangsgrensesnitt:	Micro-USB
USB A utgang:	2
Generell ladetid for enhet:	4 timer
