Les nedenfor 📖 manual på norsk for Asko DBI343ID.S.AU (3 sider) i kategorien Oppvaskmaskin. Denne guiden var nyttig for 4 personer og ble vurdert med 4.6 stjerner i gjennomsnitt av 2.5 brukere
Side 1/3
Dishwasher
DBI343ID.S.AU
Noise level (max): 44 dB(A)
Classic
Number of place settings: 14 pcs
Number of baskets: 2
Upper basket type: Installation
Size: XL, 820 mm
Turbo Combi Drying™ ensures dry dishes with fan assisted evacuation of
moisture in combination with Auto Door Opening
Automatic dosing system: No
Installation: Built under work top
Energy stars: 4
Construction and performance
• 8 Steel™ - Vital parts of the dishwasher made in stainless steel: Yes
• No need to rinse the dishes thanks to Super Cleaning System™: Yes
• Automatic water-softener for better washing performance: No
• Number of spray arms: 2 pcs
• Number of spray zones: 6
• Cleaning systems: Stainless steel spray arms, Aqua Level™ Sensor, No
need to rinse the dishes thanks to Super Cleaning System™, Cutlery Spray™
- Extra dishwashing power for the cutlery basket
• Exterior handle: Integrated handle with soft closing
Use and flexibility
• Number of place settings: 14 pcs
• Number of baskets: 2
• Top tray: Without top tray
• Upper basket type: Installation
• Upper basket system: Switch wheels
• Upper basket: Standard knife stand, Fixed glass support, Fixed pin rows,
Foldable wine shelves to left, Small distance between the basket threads -
makes loading easy and prevents small items to fall through
• Middle basket: Without middle basket
• Lower basket type: Installation
• Lower basket: Small distance between the basket threads - makes loading
easy and prevents small items to fall through., Fixed pin rows, Cutlery basket
• Automatic dosing system: No
• Interior light: No
Interaction and control
• Wifi: No
• Type of display: LCD display
• Status Light™ - Visual indication of dishwashing progress: No
• Remaining time indication: Yes, front display
• Wash end indication: Displayed with sound and light
• Language settings: Chinese simpified, Chinese traditional, Swedish,
Slovenian, Russian, Portuguese, Polish, Norwegian, Dutch, Latvian,
Lithuanian, Japanese, Italian, Croatian, French, Finnish, Estonian, Spanish,
English, German, Danish, Czech, Slovak
Functions, programs and modes
• Programs: Anti odour, Self cleaning, Rinse and hold programme, Heavy
wash, Time program, Hygiene wash, ECO wash, Intensive program, Quick
wash
• Main wash temperature (°C): 50/60/65/70
• Delayed start: Possible to delay up to 24 hours
• Options and modes: Night mode - Lower noise level. The program time is
extended., Speed mode - The program time is shortened. More energy is
used., Time set, Super Rinse™ - Two extra rinses, Enable/disable automatic
door opening
Design and integration
• From the front adjustable door spring: No
• From front adjustable rear foot: Yes
• Installation: Integrated anti-siphon - Prevents spontaneous in- and outlet of
water and simplifies elevated installation, Steam protection strip
• Sliding door: No
• Possible to install elevated: Yes
• Min. niche width: 600 mm
• Min. niche height: 820 mm
• Depth (incl. wall spacing): 555 mm
• Max Height adjustment: 53 mm
• Adjustable kick plate: 30-94/0
Safety and maintenance
• Aqua Safe™ system: Anti Block™ - Self cleaning drain pump, Light and
sound alarm, Maximum time for water intake, Extra durable PEX inlet hose,
Stand-by water protecion - Leakage detection when machine is off, Aqua
Level™ Sensor - Ensures an optimized water level, Aqua Detect™ - Instant
recognition of any leakage in the motor compartment, Detection of water
leakage on the bottom plate, Waterproof bottom plate, Extra durable stainless
steel container, Sealing points outside container
• Aqua Safe™ system: Yes
• Child safety: Kid Safe™ - Lockable controls
• Indication of low level of rinse-aid: Notification in display
Technical data
• Water connection: Size 3/4" - Can be connected to cold water
• Adapter for water connection: No
• Max. temperature of inflow water: 70 °C
• Noise level (max): 44 dB(A)
• Reference programme: 1
• Duration of standard programme: 168 min
• Estimated yearly energy consumption: 222 kWh
• Energy consumption - normal program: 0.59 kWh
• Energy stars: 4
• Water stars: 5.5
• Water consumption: 10.1 l
• Power consumption in standby mode: 0.78 W
• Plug type: AU plug
• Connected load: 2000 W
• Voltage (V): 220-240 V
• Number of phases: 1
• Fuse: 10 A
• Frequency: 50 Hz
• Required inlet water pressure MPa: 0,03-1
• Net weight: 37 kg
Dimensions
• Width: 596 mm
• Height: 819 mm
• Depth: 554 mm
• Maximum product height: 872 mm
• Length of electrical cord: 1730 mm
• Depth with door open: 1191 mm
• Length inlet hose: 163 cm
• Length outlet hose: 200 cm
Logistic information
• Packaging width: 640 mm
• Packaging height: 890 mm
• Packaging depth: 680 mm
• Gross weight: 40 kg
• Product code: 740000
• EAN code: 3838782619717
Produkspesifikasjoner
| Merke: | Asko |
| Kategori: | Oppvaskmaskin |
| Modell: | DBI343ID.S.AU |
