Dishwasher
DBI565IK.BS.AU
Noise level (max): 40 dB(A)
Logic
Number of place settings: 16 pcs
Number of baskets: 3
Upper basket type: Premium - Basket wiring in steel, fixed pin rows and
foldable wine shelves
Size: XL, 820 mm
Turbo Combi Drying™ ensures dry dishes with fan assisted evacuation of
moisture in combination with Auto Door Opening
Automatic dosing system: No
Installation: Built under work top
Energy stars: 4.5
Construction and performance
• 8 Steel™ - Vital parts of the dishwasher made in stainless steel: Yes
• No need to rinse the dishes thanks to Super Cleaning System™: Yes
• Automatic water-softener for better washing performance: No
• Number of spray arms: 3 pcs
• Number of spray zones: 9
• Cleaning systems: The water pressure is adapted depending on program,
type of dishes and dirtiness level., Adjustable power zones that can be set for
cleaning Pots & Pans or Bottles & Vases. Can also be turned off., Stainless
steel spray arms, Sensi Clean™ Sensor - measures dirtiness level, Aqua
Level™ Sensor, No need to rinse the dishes thanks to Super Cleaning
System™, Cutlery Spray™ - Extra dishwashing power for the cutlery basket
• Exterior handle: Integrated handle with soft closing
Use and flexibility
• Number of place settings: 16 pcs
• Number of baskets: 3
• Top tray: Easy height adjustment, Handle, Removable
• Upper basket type: Premium - Basket wiring in steel, fixed pin rows and
foldable wine shelves
• Upper basket system: Easy height adjustable with lever
• Upper basket: Perfect ergonomy with easy sliding telescopic rails, Standard
knife stand, Fixed glass support, Fixed pin rows, Foldable wine shelves to
right, Foldable wine shelves to left, Handle with plastic logotype, Small
distance between the basket threads - makes loading easy and prevents
small items to fall through
• Middle basket: Without middle basket
• Lower basket type: Premium - Basket wiring in steel, fixed pin rows and
removable cutlery basket
• Lower basket: Small distance between the basket threads - makes loading
easy and prevents small items to fall through., Handle with plastic logotype,
Foldable/divisible rear pin row, Cutlery basket
• Automatic dosing system: No
• Interior light: Yes, 2 LED lights
Interaction and control
• Wifi: Yes
• Type of display: LCD display
• Status Light™ - Visual indication of dishwashing progress: Yes
• Remaining time indication: Yes
• Wash end indication: Displayed with sound and light
• Language settings: Chinese simpified, Chinese traditional, Swedish,
Slovenian, Slovak, Russian, Portuguese, Polish, Norwegian, Dutch, Latvian,
Lithuanian, Japanese, Italian, Croatian, French, Finnish, Estonian, Spanish,
English, German, Danish, Czech
Functions, programs and modes
• Programs: Anti odour, Self cleaning, Quick Pro wash, Rinse and hold
programme, Time program, Hygiene wash, ECO wash, Auto wash, Intensive
program
• Main wash temperature (°C): 50/60/65/70
• Delayed start: Possible to delay up to 24 hours
• Options and modes: Enable/disable automatic door opening, Super Rinse™
- Two extra rinses, Time set, Green mode - Less energy and water is used.
The program time is extended, Speed mode - The program time is shortened.
More energy is used., Night mode - Lower noise level. The program time is
extended., ExtraHygiene with UV Technology, Sensor controlled door
opening - Optimizes the drying process according to the room temperature,
Light sabbath mode
Design and integration
• From the front adjustable door spring: No
• From front adjustable rear foot: Yes
• Installation: Integrated anti-siphon - Prevents spontaneous in- and outlet of
water and simplifies elevated installation, Steam protection strip
• Sliding door: No
• Possible to install elevated: Yes
• Min. niche width: 600 mm
• Min. niche height: 820 mm
• Depth (incl. wall spacing): 555 mm
• Max Height adjustment: 53 mm
• Adjustable kick plate: 30-94/0
Safety and maintenance
• Aqua Safe™ system: Anti Block™ - Self cleaning drain pump, Light and
sound alarm, Maximum time for water intake, Extra durable PEX inlet hose,
Stand-by water protecion - Leakage detection when machine is off, Aqua
Level™ Sensor - Ensures an optimized water level, Aqua Detect™ - Instant
recognition of any leakage in the motor compartment, Detection of water
leakage on the bottom plate, Waterproof bottom plate, Extra durable stainless
steel container, Sealing points outside container
• Aqua Safe™ system: Yes
• Child safety: Kid Safe™ - Lockable controls
• Indication of low level of rinse-aid: Notification in display
Technical data
• Water connection: Size 3/4" - Can be connected to cold water
• Adapter for water connection: No
• Max. temperature of inflow water: 70 °C
• Noise level (max): 40 dB(A)
• Reference programme: 1
• Duration of standard programme: 178 min
• Estimated yearly energy consumption: 216 kWh
• Energy consumption - normal program: 0.571 kWh
• Energy stars: 4.5
• Water stars: 6
• Water consumption: 10.6 l
• Power consumption in standby mode: 0.77 W
• Plug type: AU plug
• Connected load: 2000 W
• Voltage (V): 220-240 V
• Number of phases: 1
• Fuse: 10 A
• Frequency: 50 Hz
• Required inlet water pressure MPa: 0,03-1
• Net weight: 40.5 kg
Dimensions
• Width: 596 mm
• Height: 819 mm
• Depth: 554 mm
• Maximum product height: 872 mm
• Length of electrical cord: 1730 mm
• Depth with door open: 1191 mm
• Length inlet hose: 163 cm
• Length outlet hose: 200 cm
Logistic information
• Packaging width: 640 mm
