Asko DFI564D.AU Bruksanvisning
Asko
Oppvaskmaskin
DFI564D.AU
Les nedenfor 📖 manual på norsk for Asko DFI564D.AU (3 sider) i kategorien Oppvaskmaskin. Denne guiden var nyttig for 2 personer og ble vurdert med 4.6 stjerner i gjennomsnitt av 1.5 brukere
Side 1/3
Dishwasher
DFI564D.AU
Noise level (max): 42 dB(A)
Logic
Number of place settings: 16 pcs
Number of baskets: 3
Upper basket type: Premium - Basket wiring in steel, fixed pin rows and
foldable wine shelves
Size: XL, 820mm
Turbo Combi Drying
Automatic dosing system: No
Installation: Fully integrated
Energy stars: 4.5
Construction and performance
• 8 Steel™ - Vital parts of the dishwasher made in stainless steel: Yes
• No need to rinse the dishes thanks to Super Cleaning System™: Yes
• Automatic water-softener for better washing performance: No
• Number of spray arms: 3 pcs
• Number of spray zones: 9
• Cleaning systems: Adjustable power zones that can be set for cleaning Pots
& Pans or Bottles & Vases. Can also be turned off., Stainless steel spray
arms, Aqua Level™ Sensor, No need to rinse the dishes thanks to Super
Cleaning System™
Use and flexibility
• Number of place settings: 16 pcs
• Number of baskets: 3
• Top tray: Easy height adjustment, Handle, Removable
• Upper basket type: Premium - Basket wiring in steel, fixed pin rows and
foldable wine shelves
• Upper basket system: Switch wheels
• Upper basket: Standard knife stand, Fixed glass support, Fixed pin rows,
Foldable wine shelves to right, Foldable wine shelves to left, Handle with
plastic logotype, Small distance between the basket threads - makes loading
easy and prevents small items to fall through
• Middle basket: Without middle basket
• Lower basket type: Premium - Basket wiring in steel, fixed pin rows
• Automatic dosing system: No
• Interior light: No
Interaction and control
• Wifi: No
• Type of display: LCD display
• Status Light™ - Visual indication of dishwashing progress: Yes, spot on
floor
• Remaining time indication: Yes
• Wash end indication: Displayed with sound and light
• Language settings: Chinese simpified, Chinese traditional, Swedish,
Slovenian, Slovak, Russian, Portuguese, Polish, Norwegian, Dutch, Latvian,
Lithuanian, Japanese, Italian, Croatian, French, Finnish, Spanish, English,
German, Danish, Czech
Functions, programs and modes
• Programs: Anti odour, Self cleaning, Rinse and hold programme, Heavy
wash, Time program, Hygiene wash, ECO wash, Intensive program, Quick
wash
• Main wash temperature (°C): 50/60/65/70
• Delayed start: Possible to delay up to 24 hours
• Options and modes: Night mode - Lower noise level. The program time is
extended., Speed mode - The program time is shortened. More energy is
used., Time set, Super Rinse™ - Two extra rinses, Enable/disable automatic
door opening
Design and integration
• From the front adjustable door spring: Yes
ASKO Appliances Pty Ltd | Phone: 1300 00 2756 | au.asko.com | sales@asko.com.au
• From front adjustable rear foot: Yes
• Installation: Velcro strips for easy mounting and adjustment of the separate
custom door, Integrated anti-siphon - Prevents spontaneous in- and outlet of
water and simplifies elevated installation, Steam protection strip
• Sliding door: No
• Possible to install elevated: Yes
• Custom door size: Custom door size 680-760
• Min. niche width: 600 mm
• Min. niche height: 820 mm
• Depth (incl. wall spacing): 555 mm
• Max Height adjustment: 53 mm
• Adjustable kick plate: No
Safety and maintenance
• Aqua Safe™: Anti Block™ - Self cleaning drain pump, Light and sound
alarm, Maximum time for water intake, Extra durable PEX inlet hose, Stand-by
water protecion - Leakage detection when machine is off, Aqua Level™
Sensor - Ensures an optimized water level, Aqua Detect™ - Instant
recognition of any leakage in the motor compartment, Detection of water
leakage on the bottom plate, Waterproof bottom plate, Extra durable stainless
steel container, Sealing points outside container
• Aqua Safe™ system: Yes
• Child safety: Kid Safe™ - Lockable controls
• Indication of low level of rinse-aid: Notification in display
Technical data
• Water connection: Size 3/4" - Can only be connected to cold water
• Adapter for water connection: No
• Max. temperature of inflow water: 70 °C
• Noise level (max): 42 dB(A)
• Reference programme: 1
• Duration of standard programme: 178 min
• Estimated yearly energy consumption: 216 kWh
• Energy consumption - normal program: 0.571 kWh
• Energy stars: 4.5
• Water stars: 6
• Water consumption: 10.6 l
• Power consumption in standby mode: 0.77 W
• Plug type: AU plug
• Connected load: 2000 W
• Voltage (V): 220-240 V
• Number of phases: 1
• Fuse: 10 A
• Frequency: 50 Hz
• Required inlet water pressure MPa: 0,03-1
• Net weight: 39 kg
Dimensions
• Width: 596 mm
• Height: 819 mm
• Depth: 554 mm
• Maximum product height: 872 mm
• Length of electrical cord: 1730 mm
• Depth with door open: 1191 mm
• Length inlet hose: 163 cm
• Length outlet hose: 200 cm
Logistic information
• Packaging width: 640 mm
• Packaging height: 890 mm
• Packaging depth: 680 mm
• Gross weight: 42 kg
• Product code: 740004
• EAN code: 3838782622854
ASKO Appliances Pty Ltd | Phone: 1300 00 2756 | au.asko.com | sales@asko.com.au
Produkspesifikasjoner
| Merke: | Asko |
| Kategori: | Oppvaskmaskin |
| Modell: | DFI564D.AU |
