Side 1/3
Dishwasher
DSD767UXXL.AU
Noise level (max): 38 dB(A)
Style
Number of place settings: 16 pcs
Number of baskets: 3
Upper basket type: Exclusive - Basket wiring in steel, all pin rows foldable,
divisble/foldable wine shelves, Light Lock™ for fastening lightweight
items
Size: XXL, 860 mm high
Auto Door Open Drying™
Residual heat
Automatic dosing system: Yes, integrated
Installation: Fully integrated
Energy stars: 4.5
Construction and performance
• 8 Steel™ - Vital parts of the dishwasher made in stainless steel: Yes
• No need to rinse the dishes thanks to Super Cleaning System™: Yes
• Automatic water-softener for better washing performance: No
• Number of spray arms: 3 pcs
• Number of spray zones: 9
• Cleaning systems: Cutlery Spray™ - Extra dishwashing power for the
cutlery basket, No need to rinse the dishes thanks to Super Cleaning
System™, Aqua Level™ Sensor, Sensi Clean™ Sensor - measures dirtiness
level, Stainless steel spray arms, Adjustable power zones that can be set for
cleaning Pots & Pans or Bottles & Vases. Can also be turned off., The water
pressure is adapted depending on program, type of dishes and dirtiness level.
Use and flexibility
• Number of place settings: 16 pcs
• Number of baskets: 3
• Top tray: Easy height adjustment, With telescopic rails, Handle, Removable,
Guide rails with ball bearings
• Upper basket type: Exclusive - Basket wiring in steel, all pin rows foldable,
divisble/foldable wine shelves, Light Lock™ for fastening lightweight items
• Upper basket system: Easy height adjustable with lever
• Upper basket: Dividable pin rows, Wine glass fixings in TPE, Sliding tines for
easy adaptation to stone ware etc., Perfect ergonomy with easy sliding
telescopic rails, Light Lock™ for fastening lightweight items, China Guard -
Protects fragile load from the rotating spray arm, Extra wide knife stand, Two
foldable glass supports, Divisble/foldable wine shelves to left, Foldable wine
shelves to right, Handle with ASKO logo, Small distance between the basket
threads - makes loading easy and prevents small items to fall through
• Middle basket: Without middle basket
• Lower basket type: Exclusive
• Lower basket: Small distance between the basket threads - makes loading
easy and prevents small items to fall through., Handle with ASKO logo,
Foldable/divisible rear pin row, Foldable/divisible front pin row, Vase/bottle
holder for cleaning vases/baby bottles, Cutlery basket, Sliding tines for easy
adaptation to stone ware etc.
• Automatic dosing system: Yes, integrated
• Interior light: Yes, 4 LED lights
Interaction and control
• Wifi: Yes
• Type of display: Graphic TFT display
• Status Light™ - Visual indication of dishwashing progress: Yes
• Remaining time indication: Yes
• Wash end indication: Displayed with sound and light
• Language settings: Chinese simpified, Chinese traditional, Swedish,
Slovenian, Slovak, Russian, Portuguese, Polish, Norwegian, Dutch, Latvian,
Lithuanian, Japanese, Italian, Croatian, French, Finnish, Estonian, Spanish,
English, German, Danish, Czech
Functions, programs and modes
• Programs: Flexi AU, Preheated, Self cleaning, Quick Pro wash, Crystal
glass, Lower half, Upper half, Heavy wash, Plastic wash, Time program,
Hygiene wash, ECO wash, Auto wash, Intensive program
• Main wash temperature (°C): 45/50/55/60/65/70
• Delayed start: Possible to delay up to 24 hours
• Options and modes: ExtraHygiene with UV Technology, Intensive mode -
The dishwasher uses more heat and water. The program time is extended,
Night mode - Lower noise level. The program time is extended., Speed mode
- The program time is shortened. More energy is used., Green mode - Less
energy and water is used. The program time is extended, Time set, Super
Rinse™ - Two extra rinses, Enable/disable automatic door opening, Light
sabbath mode
Design and integration
• From the front adjustable door spring: Yes
• From front adjustable rear foot: Yes
• Installation: Velcro strips for easy mounting and adjustment of the separate
custom door, Integrated anti-siphon - Prevents spontaneous in- and outlet of
water and simplifies elevated installation, Steam protection strip
• Sliding door: Yes
• Possible to install elevated: Yes
• Custom door size: Custom door size 760-840
• Min. niche width: 600 mm
• Min. niche height: 860 mm
• Depth (incl. wall spacing): 555 mm
• Max Height adjustment: 53 mm
• Adjustable kick plate: No
Safety and maintenance
• Aqua Safe™ system: Anti Block™ - Self cleaning drain pump, Light and
sound alarm, Maximum time for water intake, Extra durable PEX inlet hose,
Stand-by water protecion - Leakage detection when machine is off, Aqua
Level™ Sensor - Ensures an optimized water level, Aqua Detect™ - Instant
recognition of any leakage in the motor compartment, Detection of water
leakage on the bottom plate, Waterproof bottom plate, Extra durable stainless
steel container, Sealing points outside container
• Aqua Safe™ system: Yes
• Child safety: Kid Safe™ - Lockable controls
• Indication of low level of rinse-aid: Notification in display
Technical data
• Water connection: Size 3/4" - Can be connected to cold water
• Adapter for water connection: No
• Max. temperature of inflow water: 70 °C
• Noise level (max): 38 dB(A)
• Reference programme: 1
• Duration of standard programme: 178 min
• Estimated yearly energy consumption: 216 kWh
• Energy consumption - normal program: 0.571 kWh
• Energy stars: 4.5
• Water stars: 6
• Water consumption: 10.6 l
• Power consumption in standby mode: 0.77 W
• Plug type: AU plug
• Connected load: 2000 W
• Voltage (V): 220-240 V
• Number of phases: 1
• Fuse: 10 A
• Frequency: 50 Hz
• Required inlet water pressure MPa: 0,03-1
• Net weight: 43 kg
Dimensions
• Width: 596 mm
• Height: 859 mm
• Depth: 554 mm
• Maximum product height: 912 mm
• Length of electrical cord: 1730 mm
• Depth with door open: 1283 mm
Produkspesifikasjoner
| Merke: | Asko |
| Kategori: | Oppvaskmaskin |
| Modell: | DSD767UXXL.AU |
