Side 1/3
Dishwasher
DBI766IQ.S.AU
Noise level (max): 39 dB(A)
Style
Number of place settings: 16 pcs
Number of baskets: 3
Upper basket type: Exclusive - Basket wiring in steel, all pin rows foldable,
divisble/foldable wine shelves, Light Lock™ for fastening lightweight
items
Size: XL, 820mm
Turbo Combi Drying
Automatic dosing system: Yes, integrated
Installation: Built under work top
Energy stars: 4.5
Construction and performance
• 8 Steel™ - Vital parts of the dishwasher made in stainless steel: Yes
• No need to rinse the dishes thanks to Super Cleaning System™: Yes
• Automatic water-softener for better washing performance: No
• Number of spray arms: 3 pcs
• Number of spray zones: 9
• Cleaning systems: Cutlery Spray™ - Extra dishwashing power for the
cutlery basket, No need to rinse the dishes thanks to Super Cleaning
System™, Aqua Level™ Sensor, Sensi Clean™ Sensor - measures dirtiness
level, Stainless steel spray arms, Adjustable power zones that can be set for
cleaning Pots & Pans or Bottles & Vases. Can also be turned off., The water
pressure is adapted depending on program, type of dishes and dirtiness level.
• Exterior handle: Integrated handle with soft closing
Use and flexibility
• Number of place settings: 16 pcs
• Number of baskets: 3
• Top tray: Easy height adjustment, With telescopic rails, Handle, Removable,
Guide rails with ball bearings
• Upper basket type: Exclusive - Basket wiring in steel, all pin rows foldable,
divisble/foldable wine shelves, Light Lock™ for fastening lightweight items
• Upper basket system: Easy height adjustable with lever
• Upper basket: Dividable pin rows, Wine glass fixings in TPE, Sliding tines for
easy adaptation to stone ware etc., Perfect ergonomy with easy sliding
telescopic rails, Light Lock™ for fastening lightweight items, China Guard -
Protects fragile load from the rotating spray arm, Extra wide knife stand, Two
foldable glass supports, Divisble/foldable wine shelves to left, Foldable wine
shelves to right, Handle with ASKO logo, Small distance between the basket
threads - makes loading easy and prevents small items to fall through
• Middle basket: Without middle basket
• Lower basket type: Exclusive
• Automatic dosing system: Yes, integrated
• Interior light: Yes, 2 LED lights
Interaction and control
• Wifi: Yes
• Type of display: Graphic TFT display
• Status Light™ - Visual indication of dishwashing progress: Yes
• Remaining time indication: Yes
• Wash end indication: Displayed with sound and light
• Language settings: Chinese simpified, Chinese traditional, Swedish,
Slovenian, Slovak, Russian, Portuguese, Polish, Norwegian, Dutch, Latvian,
Lithuanian, Japanese, Italian, Croatian, French, Finnish, Estonian, Spanish,
English, German, Danish, Czech
Functions, programs and modes
• Programs: Anti odour, Flexi AU, Preheated, Self cleaning, Quick Pro wash,
Crystal glass, Lower half, Upper half, Rinse and hold programme, Heavy
wash, Plastic wash, Time program, Hygiene wash, ECO wash, Auto wash,
Intensive program
• Main wash temperature (°C): 45/50/55/60/65/70
• Delayed start: Possible to delay up to 24 hours
ASKO Appliances Pty Ltd | Phone: 1300 00 2756 | au.asko.com | sales@asko.com.au
• Options and modes: Enable/disable automatic door opening, Super Rinse™
- Two extra rinses, Time set, Green mode - Less energy and water is used.
The program time is extended, Speed mode - The program time is shortened.
More energy is used., Night mode - Lower noise level. The program time is
extended., Intensive mode - The dishwasher uses more heat and water. The
program time is extended, ExtraHygiene with UV Technology, Sensor
controlled door opening - Optimizes the drying process according to the
room temperature, Light sabbath mode
Design and integration
• From the front adjustable door spring: No
• From front adjustable rear foot: Yes
• Installation: Integrated anti-siphon - Prevents spontaneous in- and outlet of
water and simplifies elevated installation, Steam protection strip
• Sliding door: No
• Possible to install elevated: Yes
• Min. niche width: 600 mm
• Min. niche height: 820 mm
• Depth (incl. wall spacing): 555 mm
• Max Height adjustment: 53 mm
• Adjustable kick plate: 30-94/0
Safety and maintenance
• Aqua Safe™: Anti Block™ - Self cleaning drain pump, Light and sound
alarm, Maximum time for water intake, Extra durable PEX inlet hose, Stand-by
water protecion - Leakage detection when machine is off, Aqua Level™
Sensor - Ensures an optimized water level, Aqua Detect™ - Instant
recognition of any leakage in the motor compartment, Detection of water
leakage on the bottom plate, Waterproof bottom plate, Extra durable stainless
steel container, Sealing points outside container
• Aqua Safe™ system: Yes
• Child safety: Kid Safe™ - Lockable controls
• Indication of low level of rinse-aid: Notification in display
Technical data
• Water connection: Size 3/4" - Can only be connected to cold water
• Adapter for water connection: No
• Max. temperature of inflow water: 70 °C
• Noise level (max): 39 dB(A)
• Reference programme: 1
• Duration of standard programme: 178 min
• Estimated yearly energy consumption: 216 kWh
• Energy consumption - normal program: 0.571 kWh
• Energy stars: 4.5
• Water stars: 6
• Water consumption: 10.6 l
• Power consumption in standby mode: 0.77 W
• Plug type: AU plug
• Connected load: 2000 W
• Voltage (V): 220-240 V
• Number of phases: 1
• Fuse: 10 A
• Frequency: 50 Hz
• Required inlet water pressure MPa: 0,03-1
• Net weight: 42.5 kg
Dimensions
• Width: 596 mm
• Height: 819 mm
• Depth: 554 mm
• Maximum product height: 872 mm
• Length of electrical cord: 1730 mm
• Depth with door open: 1191 mm
• Length inlet hose: 163 cm
• Length outlet hose: 200 cm
Logistic information
• Packaging width: 640 mm
ASKO Appliances Pty Ltd | Phone: 1300 00 2756 | au.asko.com | sales@asko.com.au
