Secure Flip 2-Port Keyboard/Mouse (KM)

Switch

User Manual

F1DN102K-3 – Belkin Secure Flip 2-Port KM Switch

Document Number 8820-02498 (A00)

This Belkin product is compliant

with latest NIAP Protection Proﬁle

PSS Ver. 3.0, which exceeds EAL4

and PP PSS Ver. 2.1.

Belkin Advanced Secure 2-port Flip KM Switch

TABLE OF CONTENTS

SECTIONS

1 2 3 4 5 6

Table of Contents

Introduction ..............................................1

Package Contents.........................................1

Overview.................................................2

Security Features .........................................2

Operational Features ......................................3

What is Seamless Cursor Switching? .........................5

Equipment Requirements ...................................6

Safety Precautions ........................................8

User Guidance & Precautions ...............................9

Tamper Evident Labels ....................................10

Product Specifications ....................................11

F1DN102K-3 Features.....................................12

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Before Installation ........................................13

Setup ..................................................14

Operation ...............................................20

Operating the Secure KM Switch............................20

Troubleshooting .........................................22

Information..............................................24

Belkin Advanced Secure 2-port Flip KM Switch

INTRODUCTION

SECTIONS

Table of Contents

2 3 4 5 61

Thank you for purchasing this Belkin Advanced Secure 2-port Flip

Keyboard/Mouse (KM) Switch. This Switch is designed for use in secure

environments comprised of sources with different security levels.

Providing the highest security safeguards and features, this product

meets all required cyber prevention requirements.

This User Manual provides all the details you’ll need to install and

operate your new product and to troubleshoot it in the unlikely event

of a problem.

What is a KM (Keyboard / Mouse) Switch?

A KM switch is essentially a KVM switch without the video switching.

The Belkin Advanced Secure 2-port Flip KM Switch is a winning

combination of cost effectiveness with an exceptionally small footprint

product.

The switch targets environments with 2 sources, where each computer

is connected to separate display/s. It suits scenarios where information

from multiple sources must be viewed simultaneously on the different

displays. Every computer can be connected to up to 4 displays.

The KM switch securely toggles control of keyboard, mouse and

audio from one system to the other. Intuitive navigation is provided by

Seamless Cursor Switching (SCS) - once mouse cursor crosses display

borders, the Mouse, Audio and Keyboard become active on the system

connected to that display. The product can be easily configured by

using the KM presets.

The Belkin Secure KM supports all operating systems, from Windows

to Linux and Mac OS. Multi-Displays are only supported by computers

running Windows based operating systems.

Package Contents

• Belkin Secure Flip KM Switch

• 12V 1A DC Power Supply

• User Manual

Please note: Belkin Secure KM Products cannot be upgraded,

serviced or fixed.

Important Security Note: If you are aware of potential security

vulnerability while installing or operating this product, we encourage

you to contact us immediately at the following email address:

gov_security@belkin.com

Important: This product is equipped within always-on active anti-

tamper system. Any attempt to open the enclosure may activate the

anti-tamper system and render the unit permanently inoperable. If

the unit’s enclosure appears disrupted or if all the port LEDs flash

continuously, please call Belkin Technical Support at 1 (800) 282-2355

Produkspesifikasjoner

Merke:	Belkin
Kategori:	Bryter
Modell:	F1DN102K-3
Innebygd skjerm:	Nei
Vekt:	540 g
Bredde:	109.2 mm
Dybde:	76.2 mm
Høyde:	25.4 mm
Strømkilde:	AC
USB-kontakttype:	USB Type-A
Maksimal oppløsning:	- piksler
Hodetelefonutganger:	2
AC-inngangsfrekvens:	50 - 60 Hz
Antall datamaskiner:	2
Lydtilkoblinger:	Ja
Produktfarge:	Sort
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Lagringsrelativ fuktighet:	0 - 80
Bærekraftsertifikater:	CE, Federal Communications Commission (FCC), RoHS
Kroppsmateriale:	Akrylonitril-butadien-styren (ABS)
Ekstern strømadapter:	Ja
Antall PS/2-porter:	1
Støttede Windows operativsystemer:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 80
Rack-montering:	Nei
Støttede Mac operativsystemer:	Ja
Støttede Linux operativsystemer:	Ja
Innput-strøm:	1 A
Tastatur tilkoblingstype:	USB, PS/2
Mus tilkoblingstype:	USB, PS/2
Konsoll porter:	3.5mm headphone, PS/2, USB A
Antall konsoll USB porter:	2
