Advanced Secure 8-Port

and 16-Port DVI-I KVM

User Manual

F1DN108C--Advanced Secure 8-Port DVI-I KVM

F1DN108F--Advanced Secure 8-Port Dual-Head DVI-I KVM

F1DN116C--Advanced Secure 16-Port DVI-I KVM

8820-01333 Rev. B01

TABLE OF CONTENTS

SECTIONSTable of Contents 1 2 3 4 5 6 7 8SECTIONS 1 2 3 4 5 6 7 8Table of Contents

Advanced Secure 8-Port and 16-Port DVI-I KVM

Operating the KVM Switch ............................... 15

Common Access Card (CAC) Configuration and Operation ... 16

Frequently Asked Questions ............................. 17

Troubleshooting ........................................ 18

Information............................................. 21

Introduction ............................................. 1

Package Contents ..................................... 1

Safety Precautions ..................................... 2

Overview................................................ 3

Security Features ...................................... 3

Other Features ........................................ 5

Equipment Requirements ............................... 6

System Requirements .................................. 7

Unit Display Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Specifications........................................ 10

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Pre-Configuration .................................... 12

Connection and Installation............................. 12

Color Code Chip Installation ............................ 14

INTRODUCTION

SECTIONSTable of Contents 1 2 3 4 5 6 7 8SECTIONSTable of Contents 1 2 3 4 5 6 7 8

Advanced Secure 8-Port and 16-Port DVI-I KVM

Thank you for purchasing this Belkin Advanced Secure DVI-I KVM

Switch. This rack-mountable Switch is designed for use in secure

environment installations. The Switch offers safe centralized control,

which prevents unintended data transfer between computers running

at different security levels. The Switch provides the highest security

safeguards and features that meet today’s Information Assurance (IA)

computing requirements.

This User Manual provides all the details you’ll need to install and

operate your new Switch, in addition to expert troubleshooting

advice—in the unlikely event of a problem.

Package Contents

• Belkin Advanced Secure DVI-I KVM Switch

• 6 Ft. IEC/AC Power Cord

• Interchangeable Port Color Chips

• Port-Naming Labels

• 6 Ft. USB Cable

• Rack-Mount Brackets

• User Manual

Important: This Switch is equipped with active anti-tamper

triggers. Any attempt to open the enclosure will activate the

anti-tamper triggers and render the unit inoperable. If the

unit’s enclosure appears disrupted or if all the port LEDs flash

continuously, please call Belkin Technical Support at

(800) 282-2355.

Important Security Note:

If you are aware of potential security vulnerability while

installing or operating this product, we encourage you to

gov_security@belkin.com
