Advanced Secure DVI-I KVM Dual-Head

Switch with Audio

User Manual

F1DN104E-3 – Advanced Secure Dual-Head DVI-I KVM Switch; 4-Port, PP3.0

F1DN104F-3 – Advanced Secure Dual-Head DVI-I KVM Switch; 4-Port Plus, PP3.0

Document Number HDC10385 Rev.D

Belkin

Secure DVI-I KVM Dual-Head Switch with Audio User Manual

TABLE OF CONTENTS

SECTIONS

1 2 3 4 5 6 87

Table of Contents

Introduction ..............................................1

Package Contents.........................................1

Safety Precautions ........................................2

User Guidance & Precautions ...............................3

Overview.................................................5

Security Features .........................................5

Tamper Evident Labels .....................................6

Other Features ...........................................7

Equipment Requirements ...................................8

System Requirements......................................9

Unit Display Diagrams ....................................11

Specifications ...........................................13

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Pre-Configuration ........................................14

Connection and Installation ................................15

Operating the KVM Switch ................................18

Common Access Card (CAC) Configuration and Installation ...19

Frequently Asked Questions...............................20

Troubleshooting .........................................21

Information..............................................23

Belkin

Secure DVI-I KVM Dual-Head Switch with Audio User Manual

INTRODUCTION

SECTIONS

Table of Contents

2 3 4 5 6 871

Thank you for purchasing this Belkin Secure DVI-I Dual-Head KVM

Switch (the Switch). This KVM Switch is designed for use in secure

defense and intelligence installations. The Switch offers safe centralized

control, which prevents unintended data transfer between computers

running at different security levels. The Switch provides the highest

security safeguards and features that meet today’s IA (information

assurance) computing requirements.

This User Manual provides all the details you’ll need to install and

operate your new Switch, in addition to expert troubleshooting advice -

in the unlikely event of a problem.

Important: This Switch is equipped with active anti-tamper triggers.

Any attempt to open the enclosure will activate the anti-tamper

triggers and render the unit inoperable. If the unit’s enclosure

appears disrupted or if all the port LE Ds flash continuously, please

call Belkin Technical Support at (800) 282-2355.

Package Contents

• Belkin Secure DVI-I Dual-Head KVM Switch

• 12V 1.5A DC Power Supply

• 1 set Interchangeable Port Color Chips (multiple colors)

• 1 set Port-Naming Labels

• 6 Ft. USB Cable (F1DN104F-3 model only)

• User Manual

Please note: Belkin Secure KVM Products cannot be upgraded,

serviced or fixed.

Revision

A – Initial Release, 23 Feb 2015

B – Updates to User Guidance, 26 April 2015

C – User Guidance changes, 16 June 2015

D – Correction to Features section, 13 August 2015

Produkspesifikasjoner

Merke:	Belkin
Kategori:	Bryter
Modell:	F1DN104F-3
Innebygd skjerm:	Nei
Vekt:	2160 g
Bredde:	320 mm
Dybde:	157.5 mm
Høyde:	44.2 mm
Strømkilde:	AC
LED-indikatorer:	Ja
USB-kontakttype:	USB Type-A
Maksimal oppløsning:	3840 x 2160 piksler
Hodetelefonutganger:	1
Antall skjermer som støttes:	2
AC-inngangsfrekvens:	50 - 60 Hz
Antall datamaskiner:	4
Antall USB 2.0 Type-A hub-porter:	2
Videobåndbredde:	30 Hz
Lydtilkoblinger:	Ja
Produktfarge:	Sort
HD-type:	4K Ultra HD
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Lagringsrelativ fuktighet:	0 - 80
Bærekraftsertifikater:	CE, Federal Communications Commission (FCC), RoHS
Kroppsmateriale:	Aluminium
Ekstern strømadapter:	Ja
Antall PS/2-porter:	2
Antall DVI-I-porter:	10
Relativ luftfuktighet under drift (H-H):	0 - 80
Innput-strøm:	1.5 A
Video tilkoblingstype:	DVI-I
Tastatur tilkoblingstype:	USB, PS/2
Mus tilkoblingstype:	USB, PS/2
Konsoll porter:	3.5mm headphone, PS/2, USB A
Antall konsoll USB porter:	3
Antall USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports:	1
