Side 1/2

CONGRATULATIONS ON YOUR PURCHASE

Thank you for selecting the CyberPower

CSB604/CSB606/CSB606W Surge Protector. This

manual explains the features and operation of the

CSB604/CSB606/CSB606W. Please take a few moments

to read this manual.

FEATURES

1. ON/OFF Reset Control Switch and Circuit Breaker

Controls power to all outlets. The switch is also a 15 A

breaker. When an overload occurs, it will automatically

switch o. To resume operation, ensure the overload

condition is removed and reset the surge protector by

switching the unit ON.

2. Six Standard Outlets

SURGE PROTECTOR INSTRUCTIONS

1. Set power switch into the “OFF” position. Plug the

surge protector into a standard grounding wall

receptacle by fully inserting the plug and ensure that

there are no exposed conductors.

2. Make sure electronic equipment is turned o before

plugging into the surge protector outlets. Do not use

extension cords to connect equipment to the

surge protector.

3. Set the power switch into the “RESET” position. The

surge protector will now be providing power and

surge protection.

4. Connected equipment can now be turned on.

SPECIFICATIONS

• Model Number: CSB604/CSB606/CSB606W

• Outlets: 6 Standard Outlets

• Surge Protection: 900 Joules

• Electrical Rating: 125 V/15 A/1875 W

• UL Clamping Voltage: UL 1449 3rd/500 V (H-N, H-G, N-G)

• 3 AC Lines Protected: H-N: 15,000 A, H-G: 15,000 A,

N-G: 15,000 A

• Response Time: Less than 1 nanosecond

• Attenuation: Up to 32 dB

• Circuit Breaker: Resettable 15 Amp

• EMI/RFI Filtration: 150 kHz to 100 MHz

CAUTION

TO REDUCE THE RISK OF ELECTRIC SHOCK - Use only

in dry locations and only indoors. DO NOT plug into

another relocatable power tap. DO NOT “daisy chain”

surge protectors. use with any aquarium DO NOT

equipment. DO NOT use if properly grounded outlets are

not available. DO NOT install this device if there is less

than 10 meters (30 feet) or more of wire between the

electrical outlet and electrical service panel. DO NOT use

for medical or life support equipment. This device

features an internal protection that will disconnect the

surge protective component at the end of its useful life,

but it will maintain unprotected power to the load.

TROUBLESHOOTING

▪ If the ON/OFF is switched OFF, the 15 Amp circuit

breaker may have tripped. Examine your connected

equipment and remove the device that is overloading the

circuit. Then, turn the ON/OFF switch back to RESET.

TECHNICAL SUPPORT

Please contact our Tech Support Department with

installation, troubleshooting, or general product questions.

• Phone: 1-877-297-6937

• Email: tech@cpsww.com

• Hours of Operation:

Monday – Friday 7:00am – 6:00pm CST

USER MANUAL

6-Outlet Surge Protector

CSB604/CSB606/CSB606W

6-Outlet Surge Protector

CSB604/CSB606/CSB606W

Produkspesifikasjoner

Merke:	CyberPower
Kategori:	grenuttak
Modell:	Essential CSB606W
Bredde:	52.83 mm
Dybde:	266.95 mm
Høyde:	37.85 mm
Sertifisering:	UL1449, cUL
Materiale:	Akrylonitril-butadien-styren (ABS)
Klemmespenning:	400 V
Kabellengde:	2 m
Produktfarge:	Hvit
Pakkedybde:	331.98 mm
Pakkehøyde:	52.83 mm
Pakkebredde:	115.06 mm
Bærekraftsertifikater:	RoHS
Av/på-bryter:	Ja
Antall AC outlets:	6 AC-utganger
AC-utgangstyper:	NEMA 5-15R
Strømuttak:	NEMA 5–15P
Nominell innputspenning:	125 V
Farge etui:	Hvit
Strømstøt energivurdering:	900 J
EMI/RFI-lydfiltrering:	Ja
