CyberPower PDU15B6F8R Bruksanvisning

CyberPower grenuttak PDU15B6F8R

Les nedenfor 📖 manual på norsk for CyberPower PDU15B6F8R (24 sider) i kategorien grenuttak. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/24

Power

Distribution

Unit

User’s Manual

Table of Contents

Horizontal Installation. (1U models only).................................4

Vertical Installation with Brackets ............................................5

Vertical Installation - Keyhole Mounts (0U models only) ......6

Cord Retention Tray installation ...............................................6

Meter Configuration ...................................................................6

Locking Power Cord - For IEC Type PDU .................................7

Input Power Cord ..................................................................7

Output Power Cord ...............................................................7

Electrical Installation .................................................................8

Basic Series (1U) .....................................................................9

Basic Series (0U) ................................................................... 13

Metered Series (1U) ..............................................................15

Metered Series (0U) ..............................................................16

Model List ......................................................1

PDU Naming Convention ............................. 1

Package Contents ........................................ 2

Safety Precautions .......................................

Précautions de sécurité ............................... 3

Installation .................................................... 4

Troubleshooting ........................................... 8

Product Features

Technical Specification ................................. 9

Conformance Approvals ..............................19

Customer Service & Warranty .....................20

Model List:

PDU Naming Convention:

1. Amperage:

2. Series:

3. Rack Space:

4. Input Voltage:

5. Plug Type:

6. Outlet Number Front

7. Outlet Number Rear

8. Sales version

PDU XX M V HV T F R A

1 2 3 4 5 6 7 8

15: = 10,12A 20: = 16A 30: = 24A

B: = Basic M: = Metered

NULL: = Horizontal V: = Vertical

NULL: = 100~120V

HV: = High Voltage – 200~240V

NULL: = NEMA 5-15P / 5-20P

T: = Twist (NEMA L5-L6 Plug)

IEC: = (IEC C14/C20)

CEE: = (IEC 309)

Number of Outlets followed by F – Example 8F

Number of Outlets followed by R – Example 8R

Null = 1st SKU, A= 2nd SKU, B = 3rd SKU, etc.

For information on Cyberpower products, visit www.cyberpower.com

Basic Series (0U):

PDU15BV14F

PDU20BVT14F

PDU20BV32F PDU30BVHVT32F

Basic Series (1U):

PDU15B8R

PDU15B10R

PDU15B12R

PDU15B2F8R

PDU15B2F10R

PDU15B2F12R

PDU15B4F12R

PDU15B6F8R

PDU15B6F12R

PDU20B10R

PDU20BHVT8R

PDU20BHVT12R

PDU20BHVIEC8R

PDU20BHVIEC12R

PDU20BHVCEE8R

PDU20BHVCEE12R

PDU30BT8F8R

PDU30BT10F10R

PDU30BHVT2F6R

PDU30BHVT4F8R

Metered Series (1U):

PDU15M2F8R

PDU15M2F10R

PDU15M2F12R

PDU20M2F8R

PDU20M2F10R

PDU20MT2F10R

PDU20M2F12R

Metered Series (0U):

PDU15MV20F

PDU15MV32F

PDU20MV20F

PDU20MV32F

PDU20MVT20F

PDU20MVHVT20F

PDU20MVHVT30F

PDU20MVHVT38F

PDU20MVHVIEC20F

PDU20MVHVIEC30F

PDU20MVHVIEC38F

PDU20MVHVCEE20F

PDU20MVHVCEE30F

PDU20MVHVCEE38F

PDU30MVT24F

PDU30MVT32F

PDU30MVHVT20F

PDU30MVHVT30F

PDU30MVHVT38F

Produkspesifikasjoner

Merke:	CyberPower
Kategori:	grenuttak
Modell:	PDU15B6F8R
Sertifisering:	UL1363 ETL, CSA C22.2
Vekt (imperial):	4 Ibs
AC-inngangsfrekvens:	50 - 60 Hz
Kabellengde:	4.57 m
Produktfarge:	Sort
Driftstemperatur (T-T):	0 - 35 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 45 °C
Bærekraftsertifikater:	RoHS
Montering:	Horisontal/vertikal
Strømbeskyttelsesfunksjoner:	Overbelastning
Driftshøyde:	0 - 3000 m
Rack-kapasitet:	1U
Relativ luftfuktighet under drift (H-H):	0 - 95
Antall AC outlets:	14 AC-utganger
Strøm (maks.):	15 A
AC-utgangstyper:	NEMA 5–15R
Strømuttak:	NEMA 5–15P
Nominell innputspenning:	120 V
PDU types:	Grunnleggende
Dimensjoner (B x D x H) (imperisk):	17.5 x 2.25 x 1.75 "
Høyde når uvirksom:	0 - 15000 m
Nominell outputspenning:	120 V
