Side 1/136

PDU31xxx

PDU41xxx

PDU71xxx

PDU81xxx

PDU34xxx

PDU44xxx

PDU74xxx

PDU84xxx

Intelligent PDU/ATS User Guide

K01-E000003-08

Intelligent PDU/ATS User Guide

Table of Contents

Web Interface .............................................................................................................................. 1

Introduction ............................................................................................................................... 1

Advanced Power Management ............................................................................................... 10

Outlet Management ................................................................................................................ 41

Security ................................................................................................................................... 59

Network Service ...................................................................................................................... 69

PDU/ATS Information .............................................................................................................. 82

Command Line Interface ....................................................................................................... 84

Introduction ............................................................................................................................. 84

Command Lists ....................................................................................................................... 86

Save and Restore Configuration Settings ......................................................................... 116

PDU/ATS Network Daisy Chain ...........................................................................................120

Firmware Upgrade ..................................................................................................................125

Intelligent PDU/ATS User Guide

Web Interface

Introduction

CyberPower’s Intelligent Power Distribution Unit (PDU) and Automatic Transfer Switch (ATS) Web

Interface gives users all the features they need to configure, manage, and monitor the Intelligent

PDU/ATS Series via a Web browser. With this easy-to-navigate interface, users can perform real-

time monitoring of each outlet, control individual outlet, set power alerts, and complete many other

tasks in an intuitive manner.

How to Log in

1. Open a Web browser.

2. Enter the IP address of the CyberPower PDU/ATS in the Browser Address Bar, and then

press ENTER.

Note: To look up the IP address, please refer to the LCD screen of the PDU/ATS.

3. Enter the information for the User Name and Password fields.

There are two types of user accounts.

Account Type

Default User

Name

Default

Password

Authorization

Administrator

cyber

View, access, and control all

settings.

Viewer

device

cyber

View all settings.

4. Click LOGIN to open the Summary Tab.

Produkspesifikasjoner

Merke:	CyberPower
Kategori:	grenuttak
Modell:	PDU41004
Vekt:	2100 g
Bredde:	433 mm
Dybde:	112 mm
Høyde:	44 mm
LED-indikatorer:	Link, Status
Pakkevekt:	3900 g
Sertifisering:	FCC Class A, UL60950, UL62368, EN 55032 Class A
Støttede nettverksprotokoller:	IPv4/v6, SNMPv1/v3, HTTP/HTTPs, TCP/IP, UDP, DHCP, NTP, DNS, SMTP, SSH, SSL, TLS, Telnet, FTP, Syslog
Forhåndsinstallert programvare:	PowerPanel Business, PowerPanel Enterprise
AC-inngangsfrekvens:	50 / 60 Hz
Kabellengde:	3.05 m
Produktfarge:	Sort
Antall USB-porter:	1
Pakkedybde:	250 mm
Pakkehøyde:	65 mm
Pakkebredde:	500 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	4
Driftstemperatur (T-T):	0 - 55 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 60 °C
Lagringsrelativ fuktighet:	0 - 95
Bærekraftsertifikater:	RoHS
Modell/Type:	Enkelfaset
Kroppsmateriale:	Stål
Montering:	Horisontal
Driftshøyde:	0 - 3500 m
Oppgraderbar fastvare:	Ja
Rack-kapasitet:	1U
Sikkerhetsalgoritmer:	802.1x RADIUS, HTTPS, SSH, SSL/TLS
Kommunikasjonsserieporter:	1
Relativ luftfuktighet under drift (H-H):	0 - 95
Display:	LCD
Antall AC outlets:	8 AC-utganger
Bærekraftsamsvar:	Ja
Strøm (maks.):	12 A
AC-utgangstyper:	C13 kopling
Strømuttak:	C14 kopling
Nominell innputspenning:	100 - 240 V
PDU types:	Managed, Switched
Fastvare kan oppgraderes via:	USB
Høyde når uvirksom:	0 - 15000 m
Nominell outputspenning:	100 - 240 V
Seriekobling:	Ja
