Side 1/8
TUBO DE MONTAJE PARA TORRES CON
ALTAVOCES / CAN-AM X3 (2018-2024)
MOUNTING TUBE FOR TOWERS
SPEAKERS / CAN-AM X3 (2018-2024)
CA-X34TUBE
OWNER’S MANUAL
MANUAL DEL USUARIO
ENGLISH | ESPAÑOL
SPECIALLY
DESIGNED
FOR
CAN-AM X3
CA-X34TUBE
TUBO DE MONTAJE PARA TORRES CON ALTAVOCES /
CAN-AM X3
(2018-2024)
MOUNTING TUBE FOR TOWERS SPEAKERS /
CAN-AM X3 (2018-2024)
Specially Designed For The CAN-AM X3
CNC Cutting Stainless Steel Extra Heavy-Duty Construction
2” Diameter Tube For Any DS18 Speaker Tower Mounting
Stainless Mounting Hardware Included
Buried Wire or Open Wire Mounting Optional
Mounting Distance 46.46” (Higher Position)
UV-Compliant Sand Texture Black Finish
ESPECIFICACIONES
Especialmente diseñado para el CAN-AM X3
Construcción de servicio extra pesado de acero inoxidable con corte CNC
Tubo de 2” de diámetro para cualquier montaje de torre de altavoz DS18
Accesorios de montaje de acero inoxidable incluidos
Opción de montaje del cable oculto o por fuera
Distancia de montaje 46.46” (Posición más alta)
Acabado negro con textura arena resistente a los rayos UV
SPECIFICATIONS
WHAT'S IN THE BOX:
Tube for Tower Speakers
User's Manual
TOOLS REQUIRED:
T40 Torx Bit
13mm Socket or Wrench
QUÉ HAY EN LA CAJA:
Tubo para Altavoces de Torre
Manual de usuario
HERRAMIENTAS NECESARIAS:
T40 Torx
Dado o Llave de 13mm
INSTALLATION / INSTALACIÓN
2. Coloque el CA-X34TUBE en el interior de
la jaula antivuelco, asegurándose de que el
arco mire hacia afuera como se muestra.
2. Position the CA-X34TUBE on the
inside of the roll cage, ensuring the
arch faces outward as shown.
1. Con una llave Torx T40 y un copa o
llave de 13 mm, comience quitando
los 2 pernos de fábrica ubicados en la
parte posterior de la jaula antivuelco.
Hay 2 pernos a cada lado. Mantenga
estos pernos cerca p3-ya que se
reutilizarán más adelante.
2
1
1. Using a T40 Torx and 13mm
Socket or Wrench, begin by
removing the 2 factory bolts
located on the rear of the roll
cage. There are 2 bolts on each
side. Keep these bolts close as
they will be reused later.
