Side 1/11
DESIGNED FOR
SPECIALLY
POLARIS SLINGSHOT CUSTOMIZABLE MULTI FACING HEADREST PODS
FOR 6.5” SPEAKERS WITH DIGITAL LED LIGHTING
ENGLISH | ESPAÑOL
OWNER’S MANUAL
MANUAL DEL USUARIO
SLG-HD6V2
PODS PARA 4 ALTAVOCES DE 6.5” CON OPCIÓN HACIA ADELANTE Y/O
ATRÁS PARA EL CABECERO DEL POLARIS SLINGSHOT
CON ILUMINACIÓN LED DIGITAL
LC-DRM
APP
DOWNLOAD
REQUIRED
DIGITAL
LED
LIGHTS
• Módulos de altavoz izquierdo y derecho
• Arnés de cables para iluminación LED digital.
INTRODUCTION
Maximize your Polaris Slingshot’s sound with
these exclusive headrest pods from DS18. These
pods allow you to mount one or two 6.5" speak-
ers on each side. These pods feature a unique
cover for either side, which can be removed or
applied to customize your baffle's design. Sold in
pairs for both the driver and passenger sides.
These pods fit perfectly into any Slingshot’s
system, using OEM bolts and location.
• New Exclusive Digital LED lighting Design.
• Pods Sold as a Set for Driver and Passenger
Sides.
• Easy to install using Factory bolts and
location.
• Fits all Slingshots 2015 - to Current
• Matte Black finish.
• Fits 6.5” DS18 Speakers.
• Durable (PE) waterproof Panels with UV
Protection.
• Open Baffle Speaker Pod Design.
• Exclusive removable DS18 speaker cover for
front, rear or both
WHAT’S IN THE BOX
• Left & Right Speaker Pods
• Wire Harness for Digital LED lighting.
SPEAKERS PARAMETERS
• Speaker Mounting hole: 5.7” / 145mm.
• Speaker Mounting Depth: Up to 2.4" / 62mm.
INTRODUCCIÓN
Maximiza el sonido de tu Polaris Slingshot con estos
exclusivos reposacabezas de DS18. Estas cápsulas
le permiten montar uno o dos altavoces de 6.5" en
cada lado. Estas cápsulas cuentan con una cubierta
única para cada lado, que se puede quitar o aplicar
para personalizar el diseño de su deflector. Se
venden en pares para el lado del conductor y del
pasajero. Estas cápsulas encajan perfectamente en
cualquier sistema Slingshot, utilizando pernos y
ubicación OEM.
PARÁMETROS DE LOS ALTAVOCES
• Orificio de montaje del altavoz: 5.7” / 145 mm.
• Profundidad de montaje del altavoz: hasta
2.4”/62 mm.
• Nuevo diseño exclusivo de iluminación LED digital.
• Las cápsulas se venden como un juego para los
lados del conductor y del pasajero.
• Fácil de instalar usando pernos y ubicación
de fábrica.
• Se adapta a todos los Slingshots de 2015
en adelante.
• Acabado Negro Mate.
• Se adapta a los altavoces DS18 de 6.5 pulgadas.
• Paneles impermeables duraderos (PE) con
protección UV.
• Diseño de cápsula de altavoz con deflector abierto.
• Cubierta Exclusiva de DS18 para speaker
delantero, trasero o ambos
QUÉ HAY EN LA CAJA
SLG-HD6V2
POLARIS SLINGSHOT CUSTOMIZABLE MULTI FACING HEADREST PODS
FOR 6.5” SPEAKERS WITH DIGITAL LED LIGHTING
1
PODS PARA 4 ALTAVOCES DE 6.5” CON OPCIÓN HACIA ADELANTE Y/O ATRÁS
PARA EL CABECERO DEL POLARIS SLINGSHOTCON ILUMINACIÓN LED DIGITAL
INSTALLATION / INSTALACIÓN:
Focusing on the passenger side: use a T25 TORX
socket to remove the factory rear deck hump.
Extract the (2) screws located on the front bottom of
the piece, then gently pull towards the front to
detach. (Picture 1)
1
Centrándose en el lado del pasajero: use una llave de
vaso TORX T25 para quitar la joroba de la plataforma
trasera de fábrica. Extraiga los (2) tornillos ubicados
en la parte inferior frontal de la pieza, luego tire
suavemente hacia el frente para separarlos.
(Imagen1)
2
BEFORE BEGINNING INSTALLATION
READ THESE INSTRUCTIONS CAREFULLY
This kit requires an aftermarket amplifier with the
speaker wires routed to this location. Following this
step, install the speakers. Connect the speakers
using the previously installed speaker wires, and in
the same line, attach the tweeters. Additionally,
incorporate a bass blocker filter for the tweeters. If
RGB LED speakers are being used, refer to the RGB
LED module's manual for proper connection.
Secure the speakers using stainless steel screws
and tighten them, be careful not to over-tighten or
the hole may be damaged and not properly secure
the speakers.
Este kit requiere un amplificador adicional con los
cables de los altavoces encaminados a esta
ubicación. Siguiendo este paso, instale los parlantes.
Conecte los altavoces utilizando los cables de altavoz
previamente instalados y, en la misma línea, conecte
los tweeters. Además, incorpora un filtro bloqueador
de graves para los tweeters. Si se utilizan altavoces
de LED RGB, consulte el manual del módulo LED RGB
para conocer la conexión adecuada.
Asegure los parlantes con tornillos de acero
inoxidable y apriételos, tenga cuidado de no
apretarlos demasiado o el orificio podría dañarse y no
asegurar adecuadamente los parlantes.
ANTES DE COMENZAR LA INSTALACIÓN
LEA ESTAS INSTRUCCIONES
CUIDADOSAMENTE
