Side 1/11
ENGLISH | ESPAÑOL
OWNER’S MANUAL
MANUAL DEL USUARIO
DESIGNED FOR
SPECIALLY
SLINGSHOT
POLARIS SLINGSHOT FRONT & REAR FACING HEADREST
PODS WITH 4 X NXL-6BK SPEAKERS INCLUDED
PODS PARA ALTAVOCES HACIA ADELANTE Y ATRAS EN EL
CABECERO DEL POLARIS SLINGSHOT CON 4X NXL-6BK INCLUIDOS
8 core 0.6M Input Wires for RGB Lighting
and Speakers.
Pods Sold as a Set for Driver and
Passenger Sides.
NXL-6BK Waterproof RGB LED Speakers
Included.
Easy to install using OEM bolts and
location.
Fits Slingshot Models from 2015 or later
Durable (PE) waterproof Panels with UV
Protection.
Open Baffle Speaker Pod design.
Black Finish
Cables de entrada de 8 núcleos de 0.6 M para
iluminación RGB y altavoces.
Pods vendidos como un juego para los lados del
conductor y del pasajero.
NXL-6BK Altavoces LED RGB a prueba de agua
incluidos.
Fácil de instalar con pernos y ubicación de fábrica.
Se adapta a los modelos Slingshot de 2015 en
adelante.
Paneles resistentes al agua (PE) duradera con
protección UV.
Diseño de capsula de altavoz con bafle abierto.
Acabado en Negro
Pods para Altavoces izquierda y derecha
4 altavoces NXL-6BK
Cable de Altavoces
Left & Right Speaker Pods
4 x NXL-6BK Speakers
Speaker Wiring
INTRODUCTION
FEATURES
POLARIS SLINGSHOT FRONT & REAR FACING HEADREST PODS
WITH 4X NXL-6BK SPEAKERS INCLUDED
PODS PARA ALTAVOCES HACIA ADELANTE Y ATRAS EN EL CABECERO DEL
POLARIS SLINGSHOT CON NXL-6BK INCLUIDO
If you're looking to maximize sound in your
Polaris Slingshot, you may consider adding
these durable Polyethylene headrest Pods by
DS18. These pods include two 6.5” Waterproof
Speakers with RGB LED lights (NXL-6BK) facing
forward and back on each side that your stereo
system deserves. These pods come in pairs
(Driver & Passenger) and they are very easy to
Install using factory bolts that fits directly into
place.
WHAT’S IN THE BOX
QUÉ HAY EN LA CAJA
Si está buscando maximizar el sonido en su Polaris
Slingshot, puede considerar agregar este duradero
pod de polietileno para reposacabezas de DS18.
este panel incluye dos parlantes a prueba de agua
de 6.5” con luces LED RGB (NXL-6BK) mirando hacia
adelante y hacia atrás en cada lado que su sistema
estéreo merece. Estos Pods vienen en pares
(conductor y pasajero) y son muy fácil de instalar
usando los tornillos de fabrica que encajan
directamente en su lugar.
INTRODUCCIÓN
CARACTERÍSTICAS
INSTALLATION / INSTALACIÓN:
Starting with the passenger side, Remove the
factory rear deck hump using a T25 TORX socket to
extract the (2) screws on front bottom of the piece
and pull it to the front. (Picture 1)
Remove the factory rear hoop accent using a T40
TORX socket to extract the (2) screws on bottom of
the piece and a T25 TORX to extract the (2) screws
on top of the piece and pull it to the font, then
using the T40 TORX to extract the (2) screws in the
back of the piece and pull it to the back. (Picture 2)
Install the new speaker pod in the same way
that factory was pulled out and secure it using
the factory T25 bolts on front bottom of the
piece. (Picture 3)
Instale la nueva cápsula de altavoz de la misma
manera que se extrajo de fábrica y asegúrela con
los pernos T25 de fábrica en la parte inferior
delantera de la pieza. (Imagen 3)
Retire el acento del aro trasero de fábrica con una punta
TORX T40 para extraer los (2) tornillos en la parte inferior
de la pieza y un TORX T25 para extraer los (2) tornillos en
la parte superior de la pieza y jálelo hacia la fuente, luego
use el T40 TORX para extraer los (2) tornillos de la parte
trasera de la pieza y tirar de ella hacia atrás. (Imagen 2)
Comenzando por el lado del pasajero, retire la joroba de
la plataforma trasera de fábrica con una punta TORX T25
para extraer los (2) tornillos en la parte inferior delantera
de la pieza y tire de ella hacia el frente. (Imagen 1)
1
2
3
