Side 1/11
DESIGNED FOR
SPECIALLY
SLINGSHOT
OWNER’S MANUAL
MANUAL DEL USUARIO
ENGLISH | ESPAÑOL
POLARIS SLINGSHOT FRONT KICK PANEL PODS FOR
6.5" SPEAKERS & 3.8" BULLET TWEETERS
PODS PARA ALTAVOCES DE 6.5” Y TWEETERS BALA
DE 3.8” PARA EL PANEL FRONTAL DE LOS PIES DEL
POLARIS SLINGSHOT
SLG-FKP6V2
LC-DRM
APP
DOWNLOAD
REQUIRED
DIGITAL
LED
LIGHTS
2015
TO CURRENT
POLARIS SLINGSHOT FRONT KICK PANEL PODS FOR
6.5" SPEAKERS & 3.8" BULLET TWEETERS
PODS PARA ALTAVOCES DE 6.5” Y TWEETERS BALA DE 3.8” PARA
EL PANEL FRONTAL DE LOS PIES DEL POLARIS SLINGSHOT
INTRODUCTION
Maximize the sound in your Polaris Slingshot
with these upgraded Front Kick Panel Pods by
DS18! These pods come in pairs and allow you to
mount one 6.5” speaker and one 3.8” Bullet
Tweeter on each side of your Slingshot. They
match the factory look of the Polaris Slingshot
and are very easy to install using factory bolts
that fit perfectly.
FEATURES
New Exclusive Digital LED Lighting Design.
Pods Sold as a Set (Driver and Passenger).
Easy to Install - All Hardware and Wiring
Included.
OFC Wiring, Tinned for More Power Handling
and Durability.
9 Core 0.6M Input Wires for Speaker, RGB LED
and Digital Badge LED.
Fits Slingshot Models from 2015 to Current.
Coated Metal Bracket for Better Resistance to
the Elements.
Fits Most 6.5” DS18 Speakers (Not Included)
Fits Most 3.8” Bullet Tweeters (Not Included)
Durable (PE) Waterproof Pod with
UV Protection.
Sealed Type Waterproof Pods.
Damping Material for Better Speaker
Performance.
Black OEM Finish.
CARACTERÍSTICAS
Nuevo diseño exclusivo de iluminación LED digital.
Cápsulas vendidas como un juego para los lados del
conductor y del pasajero.
Fácil de instalar con todo el hardware y cableado
incluidos.
Cableado de cobre libre de oxígeno (OFC), estañado para
mayor manejo de potencia y durabilidad.
Cables de entrada de 6 núcleos de 0.6m para altavoz LED
RGB y LED del logo digital.
Se adapta a los modelos Slingshot de 2015 en adelante.
Soporte de metal revestido para una mejor resistencia a
los elementos.
Se adapta a varios altavoces DS18 de 6.5” (no incluido).
Se adapta a varios tweeters de bala de 3.8” (no incluido).
Cápsula resistente al agua (PE) con protección UV.
Cápsula sellada impermeable.
Material reductor de vibraciones para obtener un mejor
rendimiento del altavoz.
Acabado negro OEM.
SPEAKERS PARAMETERS
Speaker Mounting Hole: 5.7” / 145mm.
Speaker Mounting Depth: Up to 4.3” / 110mm.
Tweeter Mounting Hole: 2.9” / 74mm.
Tweeter Mounting Depth: Up to 2.5” / 66mm.
PARÁMETROS DE LOS ALTAVOCES
Orificio de montaje del altavoz: 5.7” / 145 mm.
Profundidad de montaje del altavoz: hasta 4.3”/110 mm.
Orificio de montaje del tweeter: 2.9” / 74 mm.
Profundidad de montaje del tweeter: hasta 2.5”/66 mm.
WHAT’S IN THE BOX
Left & Right Speaker Pods.
Mounting Brackets.
Screws and Washers.
Speaker + RGB LED + Badge DRGB Lights Wiring.
QUÉ HAY EN LA CAJA
Cápsulas de altavoz izquierdo y derecho.
Soportes de montaje.
Tornillos y arandelas.
Cableado para el altavoz y luces LED digitales.
INTRODUCCIÓN
Maximice el sonido en su Polaris Slingshot con estas
cápsulas mejoradas para el panel delantero de los pies
de DS18! Estas cápsulas vienen en pares y le permiten
montar un altavoz de 6,5" y un tweeter tipo bala de
3,8" en cada lado del Slingshot. Coinciden con el
aspecto de fábrica del Polaris Slingshot y son muy
fáciles de instalar usando los tornillos de fábrica que
se ajustan perfectamente.
SLG-FKP6V2
1
INSTALLATION / INSTALACIÓN:
1
Remove the factory speaker enclosures using a T40
TORX socket to extract the three screws securing
each enclosure. Disconnect the factory connector
and remove the speaker enclosure. If your vehicle
did not come with a factory speaker, you will need to
remove one T40 TORX screw on both the driver and
passenger sides. These screws secure the factory
plastic side panel to a bracket welded to the chassis
tube. (Picture 1)
Retire las cajas de los altavoces de fábrica utilizando
una punta TORX T40 para extraer los (3) tornillos que
sujetan cada caja de los altavoces. Desconecte el
conector de fábrica y retire la caja del altavoz. Si su
vehículo no viene con un altavoz de fábrica, deberá
quitar (1) tornillo TORX T40 en el lado del conductor y
del pasajero del vehículo. El tornillo asegura el panel
lateral de plástico de fábrica del vehículo a un
soporte soldado al tubo del chasis. (Imagen 1)
BEFORE BEGINNING INSTALLATION,
READ THESE INSTRUCTIONS CAREFULLY
This kit requires an aftermarket amplifier with the
speaker wires routed to this location. After
completing this step, proceed to install the speak-
ers. Connect the speakers using the previously
installed speaker wires, and in the same process,
attach the tweeters. Additionally, incorporate a
bass blocker filter for the tweeters. If RGB LED
speakers are being used, refer to the RGB LED
module's manual for proper connection.
Secure the speakers using stainless steel screws
and tighten them. Be careful not to over-tighten, as
the hole may be damaged and not properly secure
the speakers.
Este kit requiere un amplificador del mercado de
accesorios con los cables de los altavoces
encaminados a esta ubicación. Después de
completar este paso, proceda a instalar los
altavoces. Conecte los altavoces utilizando los cables
de altavoz previamente instalados y, en el mismo
proceso, conecte los tweeters. Además, incorpore un
filtro bloqueador de graves para los tweeters. Si se
utilizan altavoces LED RGB, consulte el manual del
módulo LED RGB para conocer la conexión adecuada.
Asegure los altavoces con tornillos de acero
inoxidable y apriételos. Tenga cuidado de no
apretarlos demasiado o el orificio podría dañarse y
no asegurar adecuadamente los altavoces.
ANTES DE COMENZAR LA INSTALACIÓN
LEA ESTAS INSTRUCCIONES
CUIDADOSAMENTE
2
