HELGI HLG0388PRO Bruksanvisning

HELGI AV ekstender HLG0388PRO

Les nedenfor 📖 manual på norsk for HELGI HLG0388PRO (10 sider) i kategorien AV ekstender. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/10

Important Safety Notice

Please read below safety instructions carefully before installation and

operation:

1. Please pay attention to all the warnings and hints on this device.

2. Do not expose this unit to rain, moisture and liquid.

3. Do not put any stuff into the device.

4. Do not repaire the device or open the enclosure without professional

person guidence to avoid electronic shock.

5. Make sure good ventilation openings to avoid product overheating damage.

6. Shut off power and make sure environment is safe before installation.

7. Do not plug-in/out the network cables and IR cables when it is in using

to avoid cables damage.

8. Use DC5V/3A only. Make sure the specification matched if using 3rd

party DC adapters.

Introduction

This HDbitT HDMI wireless extender includes transmitter unit and

receiver unit, applies the advanced HDbitT transport protocol, allows

to transmit and extend HDMI signal up to 200 meters long away

wirelessly, it’with strong anti-interference ability by running at 5GHz

operation frequency, and supports point to point connection and one

to many connection (up to 1 transmitter to 4 receivers configuration).

IR passback with 20-60KHz frequency helps to remote control the

source device from the receiver side. It is really a very good solution

for transmisson one HDMI source signal to one or more screens in long

distance without running wires, perfect for application of meeting,

conference, home entertainment and education etc.

Note:

1 ) Transmission distance will be different due to the environment.

2 ) Wall, brick or glass will shorten the signal cover range or cause big signal loss.

Features

1. Support 1 transmitter to 4 receivers configuration

2. Highest resolution up to 1080p full HD

3. Strong anti-interference ability by running at 5GHz operation frequency

4. Support IR passback with 20-60KHz frequency, control source device

from RX side easily

5. Support 200m long range transmission distance

6. LED indicator for power and transmission status

7. Metal housing, stable and durable

Package Contents

Transmitter unit ×1pcs Receiver unit ×1pcs DC5V/3A power

adapter x2pcs

Produkspesifikasjoner

Merke:	HELGI
Kategori:	AV ekstender
Modell:	HLG0388PRO
LED-indikatorer:	Ja
Maksimal oppløsning:	1920 x 1080 piksler
Strømforbruk (maks.):	15 W
HDCP:	Ja
Maksimal oppdateringshastighet:	60 Hz
HDMI-versjon:	1.3
Utgangsstrøm:	3 A
HDMI inn:	1
HDCP-versjon:	1.2
Antall HDMI-utganger:	1
Driftsspenning:	5 V
HDCP-gjennomgang:	Ja
Produktfarge:	Sort
Støttede grafikkoppløsninger:	854 x 480 (WVGA), 1024 x 576 (WSVGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Støttede videofunksjoner:	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Modell/Type:	AV-sender og -mottaker
DC-inngangskontakt:	Ja
Lydsystem:	Stereo
Fjern (IR)-utgang:	1
Største båndbredde for port:	10.2 Gbit/s
Fjerninngang (IR):	1
Maksimal overføring avstand:	200 m
Display Data Channel (DDC) inngang:	5 V
Antall antenner:	2
Overgang Minimert Differential Signal (TMDS) inngang:	1.5 V
Innebygd antenne:	Ja
