Side 1/14

Manual IB-DK2106-C

USB Type-C

™

Notebook DockingStation

Handbuch IB-DK2106-C

USB Type-C

™

Notebook DockingStation

Safety information IB-DK2106-C

Please read carefully the following information to prevent injuries, damage to materi-

al and device as well as data loss:

Warning levels

Signal words and safety codes indicate the warning level and provide immediate information in

terms of the probability of occurrence as well as the type and severity of the consequences if the

measures to prevent hazards are not complied with.

Warns of a directly hazardous situation causing death or serious

injury.

Warns of a potentially hazardous situation that may cause death or

serious injury.

Warns of a potentially hazardous situation that may cause minor injury.

Warns of a potential situation that may cause material or environmental

damage and disrupt operative processes.

1. Risk of electrical shock

Contact with parts conducting electricity

Risk of death by electrical shock

• Read the operating instructions prior to use

• Make sure the device has been de-energised prior to working on it

• Do not remove contact protection panels

• Avoid contact with conducting parts

• Do not bring plug contacts in contact with pointed and metal objects

• Use in intended environments only

• Operate the device using a power unit meeting the specifications of the type plate only!

• Keep the device/power unit away from humidity, liquid, vapour and dust

• Do not modify the device

• Do not connect the device during thunderstorms

• Approach specialist retailers if you require repairs

2. Hazards during assembly (if intended)

Sharp components

Potential injuries to fingers or hands during assembly (if intended)

• Read the operating instructions prior to assembly

• Avoid coming into contact with sharp edges or pointed components

• Do not force components together

• Use suitable tools

• Use potentially enclosed accessories and tools only

3. Hazards caused by a development of heat

Insufficient device/power unit ventilation

Overheating and failure of the device/power unit

• Prevent externally heating up components and ensure an exchange of air

• Do not cover the fan outlet and passive cooling elements

• Avoid direct sunlight on the device/power unit

DANGER

WARNING

CAUTION

IMPORTANT

WARNING

CAUTION

IMPORTANT

Safety information IB-DK2106-C

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	datatilbehør
Modell:	IB-DK2106-C
Vekt:	288 g
Bredde:	278 mm
Dybde:	77 mm
Høyde:	18 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	USB
Opprinnelsesland:	China
Pakkevekt:	402 g
Antall HDMI-porter:	2
Hodetelefonutganger:	1
Antall per pakke:	1 stykker
Kombinert hodetelefon/mikrofonport:	Ja
Utgangsstrøm:	5 V
Vertsgrensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Antall skjermer som støttes:	3
UASP-støtte:	Ja
Dataoverføringshastighet:	5 Gbit/s
Kabellengde:	0.5 m
Produktfarge:	Anthracite, Black
HD-type:	4K Ultra HD
Pakkedybde:	25 mm
Pakkehøyde:	340 mm
Pakkebredde:	130 mm
Minnekortenhet:	MicroSD (TransFlash), SD
Hodetelefontilkobling:	3,5 mm
Maksimal digital oppløsning:	3840 x 2160 piksler
Antall VGA (D-Sub)-porter:	1
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Innebygd kortleser:	Ja
Harmonisert system (HS)-kode:	84733020
Kroppsmateriale:	Aluminium, Plastic
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Støttede Windows operativsystemer:	Windows 10
Ethernet/bredbåndsforbindelse:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	3
Antall USB 3.2 Gen 1 (3.1 Gen 1) Type-C-porter:	1
Masterkassens (ytterkassens) bruttovekt:	8860 g
Masterkassens (ytterkassens) lengde:	370 mm
Produkter per masterkasse (ytterkasse):	20 stykker
Masterkassens (ytterkassens) bredde:	280 mm
Masterkassens (ytterkassens) høyde:	300 mm
Gummibein:	Ja
USB Power Delivery:	Ja
USB Power Delivery opp til:	100 W
Maksimal analog oppløsning:	1920 x 1200 piksler
USB Power Delivery-revisjon:	2.0
