Side 1/22

Manual IB-DK2408-C

USB Type-C

Notebook DockingStation

Handbuch IB-DK2408-C

USB Type-C

Notebook DockingStation

Please read carefully the following informa-

tion to prevent injuries, damage to material

and device as well as data loss:

Warning levels

Signal words and safety codes indicate the warning level and

provide immediate information in terms of the probability of oc-

currence as well as the type and severity of the consequences if

the measures to prevent hazards are not complied with.

Warns of a directly hazardous situation

causing death or serious injury.

Warns of a potentially hazardous situation

that may cause death or serious injury.

Warns of a potentially hazardous

situation that may cause minor injury.

Warns of a potential situation that may

cause material or environmental damage

and disrupt operative processes.

1. Risk of electrical shock

Contact with parts conducting electricity

Risk of death by electrical shock

Read the operating instructions prior to use

Make sure the device has been de-energised prior to

working on it

Do not remove contact protection panels

Avoid contact with conducting parts

Do not bring plug contacts in contact with pointed and

metal objects

Use in intended environments only

Operate the device using a power unit meeting the

speciﬁcations of the type plate only!

Keep the device/power unit away from humidity, liquid,

vapour and dust

Do not modify the device

Do not connect the device during thunderstorms

Approach specialist retailers if you require repairs

2. Hazards during assembly (if intended)

Sharp components

Potential injuries to ﬁngers or hands during assembly (if intended)

Read the operating instructions prior to assembl

Avoid coming into contact with sharp edges or pointed

components

Do not force components together

Use suitable tools

Use potentially enclosed accessories and tools only

3. Hazards caused by a development of heat

Insufﬁcient device/power unit ventilation

Overheating and failure of the device/power unit

Prevent externally heating up components and ensure an

exchange of air

Do not cover the fan outlet and passive cooling elements

Avoid direct sunlight on the device/power unit

Guarantee sufﬁcient ambient air for the device/power unit

Do not place objects on the device/power unit

4. Hazards caused by very small parts and packaging

Risk of suffocation

Risk of death by suffocation or swallowing

Keep small parts and accessories away from children

Store/dispose of plastic bags and packaging in an area

that is inaccessible to children

Do not hand over small parts and packaging to children

5. Potential data loss

Data lost during commissioning

Potentially irreversible data loss

Always comply with the information in the operating instruc

tions/quick installation guide

Exclusively use the product once the speciﬁcations have

been met

Back up data prior to commissioning

Back up data prior to connecting new hardware

Use accessories enclosed with the product

6. Cleaning the device

Harmful cleaning agents

Scratches, discolouration, damage caused by moisture

or short circuit in the device

Disconnect the device prior to cleaning

Aggressive or intense cleaning agents and solvents are

unsuitable

Make sure there is no residual moisture after cleaning

We recommend cleaning devices using a dry, anti-static cloth

7. Disposing of the device

Environmental pollution, unsuitable for recycling

Potential environmental pollution caused by compo-

nents, recycling circle interrupted

This icon on product and packaging indicates that this

product must not be disposed of as part of domestic

waste. In compliance with the Waste Electrical and Electronic

Equipment Directive (WEEE) this electrical device and poten

tially included batteries must not be disposed of in conven-

tional, domestic waste or recycling waste. If you would like

to dispose of this product and potentially included batteries,

please return it to the retailer or your local waste disposal and

recycling point.

If you have any questions, please do not hesitate to contact

our support at support@raidsonic.de or visit our website at

www.icybox.de.

WARNING

DANGER

CAUTION

IMPORTANT

•

Safety Instructions

Produkspesifikasjoner

Merke:	Icy Box
Kategori:	datatilbehør
Modell:	IB-DK2408-C
Vekt:	438 g
Bredde:	200 mm
Dybde:	98 mm
Høyde:	18 mm
LED-indikatorer:	Kraft indikator
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	DC
Opprinnelsesland:	China
Pakkevekt:	1147 g
Antall HDMI-porter:	1
Innebygde høyttalere:	Nei
Hodetelefonutganger:	1
Maksimal oppdateringshastighet:	60 Hz
Antall DisplayPorts:	1
Antall per pakke:	1 stykker
Kombinert hodetelefon/mikrofonport:	Ja
Utgangsstrøm:	5 A
Vertsgrensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Antall skjermer som støttes:	2
AC-inngangsspenning:	100-240 V
AC-inngangsfrekvens:	50 - 60 Hz
UASP-støtte:	Ja
Dataoverføringshastighet:	10 Gbit/s
Innebygd SSD:	Nei
Kabellengde:	1 m
Produktfarge:	Sort, sølv
HD-type:	4K Ultra HD
Pakkedybde:	80 mm
Pakkehøyde:	240 mm
Pakkebredde:	140 mm
Minnekortenhet:	MicroSD (TransFlash), SD
Hodetelefontilkobling:	3,5 mm
Kabler inkludert:	DC, USB Type-C to USB Type-C
Maksimal digital oppløsning:	3840 x 2160 piksler
Mikrofon, linje-inn-støpsel:	Nei
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Innebygd kortleser:	Ja
Andre støttede operativsystemer:	ChromeOS
Kroppsmateriale:	Aluminium, Plastic
DC-inngangskontakt:	Ja
Av/på-bryter:	Ja
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Støttede Windows operativsystemer:	Ja
USB-kabellengde:	1 m
Ethernet/bredbåndsforbindelse:	Ja
Krav til strømforsyning:	100 W
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	3
Kabellåsport:	Ja
Kabellåstype:	Kensington
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Støttede Mac operativsystemer:	Ja
Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter:	1
Antall USB 3.2 Gen 1 (3.1 Gen 1) Type-C-porter:	1
Antall USB 3.2 Gen 2 (3.1 Gen 2) Type-A-porter:	1
Masterkassens (ytterkassens) bruttovekt:	12170 g
Masterkassens (ytterkassens) lengde:	260 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	310 mm
Masterkassens (ytterkassens) høyde:	440 mm
Gummibein:	Ja
Kompatible strømkontakt typer:	EU
USB Power Delivery:	Ja
USB Type-C DisplayPort Alternate Mode:	Ja
