Side 1/14
INSTALLATION GUIDE
for the
SLPK-YA-19FXC
SKU# 94670 & 94671
&
SLPK-YA-19FXC-SUB
SKU# 94674
2019-Up Yamaha FX
Thank you for choosing a JL Audio SlamPak™ for your marine sound system.
With proper installation, your new marine audio sound system
will deliver years of listening pleasure.
We strongly recommend that you have your new SlamPak™ installed by your
authorized JL Audio dealer. The installation professionals employed by your
dealer have the necessary tools and experience to disassemble and reassemble
your vessel properly. If you prefer to perform your own installation, please read
this installation guide completely before beginning the process.
If you choose to perform the installation yourself, it is absolutely
vital that the SlamPak™ be properly mounted to the vessel
according to these instructions. Failure to mount the enclosures
properly presents two problems:
1) A loose enclosure presents a serious safety hazard in the event of a
collision, rollover, or sudden deceleration.
2) The sub-bass performance will suffer due to the movement of the
enclosure caused by the force exerted by the woofer(s).
INSTALLATION
DIFFICULTY:
ESTIMATED TIME:
3-4 HOURS
Continued on Next Page
5
5
OUT
OF
SlamPak
™
SLPK-YA-19FXC / SLPK-YA-19FXC-SUB INSTR_SKU# 011531
MX600/3 Amplifier (x1) VEX Speaker Enclosure (x2) 50A Circuit Breaker (x1)
Rear Logo Appliqué (x2)
Port VEX Adaptor (x1)
Starboard VEX Adaptor (x1)
Port VEX Adaptor Gasket (x1)
Starboard VEX Adaptor Gasket (x1) Back Plate (x2) Amplifier Bracket (x1)
7/16 - 14 x 7/8” Stainless Steel
Hex Head Bolt (x4)
7/16” Stainless Steel
Split Lock Washer (x4)
8-32 Stainless Steel
Flat Washer (x3)
8-32 Stainless Steel
Locknut (x3)
1/4 - 20 x 1” Stainless Steel
Hex Cap Screw (x8)
1/4” Stainless Steel
Flat Washer (x10)
1/4” Stainless Steel
Oversized Flat Washer (x6)
1-4 - 20 Stainless Steel
Nylon Insert Locknut (x8) 11” Cable Ties (x10)
INCLUDED HARDWARE
Continued on Next Page
Page 2 • JL Audio, Inc., 2020
SLPK-YA-19FXC / SLPK-YA-19FXC-SUB INSTR_SKU# 011531
SLPK-YA-19FXC Equipment and Hardware
M6 - 1 x 20mm Stainless Steel
Socket Cap Screw (x4)
MBT-CRXv2
Bluetooth Controller (x1)
NOTE: For optimum performance
and reliability, all amplifier controls
have been preset for this SlamPak™
and sealed beneath the control
panel cover. No further adjustment
is necessary.
